Process Control Solution – YOKOGAWA ADV561-P10 S1 | CENTUM VP Digital Output Module
Where This Product Is Used
The YOKOGAWA ADV561-P10 S1 is a field-proven Digital Output (DO) module designed for deployment within YOKOGAWA’s CENTUM VP Distributed Control System (DCS). It is widely specified across the following industries and applications:
- Oil & Gas Refineries – Controlling solenoid valves, motor starters, and shutdown relays in upstream/downstream process units
- Chemical & Petrochemical Plants – Driving actuators and alarm annunciators in continuous batch processes
- Power Generation – Interfacing with turbine control panels, breaker trip circuits, and auxiliary equipment
- Pulp & Paper / Water Treatment – Pump sequencing, valve open/close commands, and conveyor interlocks
- Pharmaceutical Manufacturing – GMP-compliant discrete output control for clean-room HVAC and process equipment
- LNG & Offshore Platforms – SIL-rated output loops in safety-instrumented systems (SIS) integrated with CENTUM VP
Technical Specifications
| Model | ADV561-P10 S1 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | Digital Output (DO) |
| Compatible Platform | CENTUM VP / CENTUM CS 3000 (FCS) |
| Output Channels | 16-point transistor output (typical for ADV561 series) |
| Output Type | Isolated transistor sink/source output |
| Rated Load Voltage | 24 VDC (nominal) |
| Communication | V-net / RIO bus (CENTUM VP backplane) |
| Mounting | Node Unit (NU) / Field Control Station (FCS) card slot |
| Weight | 300 g (approx.) |
| Operating Temperature | 0 °C to 60 °C |
| SKU / Part Number | ADV561-P11 S1 |
Note: Full electrical ratings and I/O specifications are available in the YOKOGAWA ADV561 hardware manual. Contact us for the datasheet.
Why Engineers Specify This Model
- Native CENTUM VP Integration – Plug-and-play compatibility with YOKOGAWA FCS node units; no additional signal conditioning required
- High Channel Density – 16 isolated DO points per card reduces cabinet footprint and wiring cost
- Hot-Swap Capable – Supports online replacement without process shutdown, minimizing downtime risk
- Proven Field Reliability – Widely deployed in tier-1 refineries and chemical complexes globally since CENTUM CS 3000 era
- Diagnostic Transparency – Built-in self-diagnostics report channel faults to the CENTUM VP HIS operator station in real time
- Redundancy Support – Compatible with YOKOGAWA’s dual-redundant I/O architecture for critical control loops
Complete System Bill of Materials
When integrating the ADV561-P10 S1 into a CENTUM VP system, engineers typically specify the following companion components:
- YOKOGAWA FCS Node Unit (NU) – e.g., ANB10D / ANB11D
- YOKOGAWA Field Control Station – e.g., AFV10S / AFV30S
- Terminal Board – e.g., ATD5D (for ADV561 series wiring termination)
- Cable Assembly – e.g., ACB4D (node unit interconnect cable)
- CENTUM VP Engineering Workstation (EWS) license for I/O builder configuration
- 24 VDC field power supply (redundant recommended for SIL loops)
Contact [email protected] for a complete BOM quotation tailored to your project scope.
Compliance & Industry Standards
- CE Marking – Compliant with EU EMC and Low Voltage Directives
- UL / cUL Listed – Recognized for use in North American industrial installations
- IEC 61131-2 – Programmable controller hardware standard compliance
- IEC 61508 / IEC 61511 – Functional safety compatibility for SIS integration (verify SIL rating with project safety case)
- RoHS Compliant – Restriction of Hazardous Substances per EU Directive 2011/65/EU
- ATEX / IECEx – Consult YOKOGAWA for zone-rated barrier/isolator requirements when used in hazardous areas
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA modules through verified industrial supply channels. Every unit offered is subject to the following quality controls:
- Visual and mechanical inspection upon receipt
- Firmware/label verification against YOKOGAWA part number documentation
- Anti-static packaging and climate-controlled storage
- Traceability records maintained per shipment batch
- Warranty: 90-day functional guarantee against manufacturing defects
We do not sell counterfeit, refurbished-as-new, or unverified grey-market stock. If you require a Certificate of Conformance (CoC) or third-party inspection report, please request at time of order.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly
- Request a Quote – Email [email protected] with your project quantity and delivery timeline for volume pricing
- Urgent Requirement – Call or WhatsApp +0086 19859288691 for same-day stock confirmation and expedited shipping options
- Lead Time – In-stock units ship within 1–3 business days; ex-stock lead time for non-stocked items is 2–6 weeks depending on YOKOGAWA availability
- Export & Customs – We support international shipments with full commercial invoice, packing list, and HS code documentation
Application-Specific FAQ
Q: Is the ADV561-P10 S1 compatible with CENTUM CS 3000 as well as CENTUM VP?
A: Yes. The ADV561 series was originally introduced for CENTUM CS 3000 and carries forward compatibility into CENTUM VP FCS node units. Confirm slot compatibility with your specific FCS model before installation.
Q: Can this module be used in a Safety Instrumented System (SIS)?
A: The ADV561-P10 S1 is a standard DCS I/O module. For SIL-rated SIS applications, YOKOGAWA’s ProSafe-RS platform with dedicated safety I/O modules is the appropriate solution. However, this module can interface with SIS via hardwired interlock signals.
Q: What is the difference between ADV561-P10 and ADV561-P11?
A: The suffix designates minor hardware revision or configuration variant (e.g., terminal board type, isolation class). Contact us with your existing system’s FCS model number and we will confirm the correct variant for your installation.
Q: Do you provide installation and commissioning support?
A: Konmask.com is a parts supplier. We can provide technical documentation, wiring diagrams, and connect you with certified YOKOGAWA system integrators in your region upon request.
Q: What is your return policy for DCS modules?
A: Unused modules in original packaging may be returned within 14 days of receipt. Modules that have been installed or powered are non-returnable. Please inspect all items upon delivery.
