ICS TRIPLEX T9831 – 16-Channel Analogue Input TA Module | Trusted Series Simplex Platform
Engineering Background
The ICS TRIPLEX T9831 is a high-integrity analogue input module designed for the Trusted Series safety and control platform. ICS TRIPLEX (now part of Rockwell Automation) engineered the Trusted Series to meet the most demanding process safety and continuous control requirements in oil & gas, petrochemical, power generation, and critical infrastructure sectors. The T9831 operates as a simplex analogue input termination assembly (TA), providing 16 commoned channels for field signal acquisition with high accuracy and reliability.
Product Positioning
The T9831 is the field-side termination assembly paired with the Trusted Series analogue input processor modules. It serves as the physical interface between field instrumentation (transmitters, sensors) and the Trusted controller backplane. Procurement engineers specifying replacement or expansion modules for existing Trusted Series installations will find the T9831 a direct, specification-matched solution. Konmask.com maintains verified stock sourced from authorized channels and reputable industrial distributors globally.
Complete Technical Specifications
| Part Number | T9831 |
| Manufacturer | ICS TRIPLEX (Rockwell Automation) |
| Module Type | Analogue Input Termination Assembly (TA) |
| Platform | Trusted Series |
| Channel Count | 16 Channels |
| Configuration | Simplex |
| Input Common | Commoned (common return) |
| Signal Type | Analogue (4–20 mA / voltage, per field wiring) |
| Termination Style | Field-side terminal assembly |
| Weight | 400 g (approx.) |
| Compatibility | ICS TRIPLEX Trusted Series controller chassis |
| Condition Available | New / Refurbished / Tested |
Note: Full electrical specifications (input impedance, resolution, isolation voltage) are available in the ICS TRIPLEX Trusted Series hardware manual. Contact Konmask for datasheet access.
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA, downstream refinery DCS/SIS integration
- Petrochemical & Chemical: Reactor temperature/pressure monitoring, batch process control
- Power Generation: Turbine control systems, boiler management, substation automation
- Water & Wastewater: Treatment plant process monitoring, pump station telemetry
- Offshore Platforms: Safety instrumented systems (SIS) requiring high-availability analogue acquisition
- Pulp & Paper / Mining: Continuous process analogue signal termination in harsh environments
Engineering Advantages
- 16-Channel Density: High channel count per TA reduces cabinet footprint and wiring complexity in large-scale installations.
- Commoned Architecture: Simplifies field wiring design for installations where a common signal return is acceptable, reducing cable count.
- Trusted Series Ecosystem: Seamless integration with ICS TRIPLEX Trusted Series processor and I/O modules — no cross-compatibility engineering required.
- Robust Industrial Design: Built to ICS TRIPLEX’s industrial-grade standards for vibration, temperature, and EMI tolerance in process plant environments.
- Direct Replacement: Drop-in replacement for existing T9831 TAs in the field — minimizes maintenance downtime and re-engineering costs.
System Architecture & Signal Flow
In a Trusted Series architecture, the T9831 TA mounts in the field termination panel and connects via a dedicated cable to the corresponding analogue input processor module seated in the Trusted controller chassis. Field instruments wire directly to the T9831’s screw terminals. The TA conditions and routes the 16 analogue signals to the processor module, which performs A/D conversion, diagnostics, and data transfer to the controller backplane. The simplex configuration means a single signal path per channel — suitable for non-redundant analogue acquisition loops where the SIL/availability requirement is met by system-level redundancy or the process risk profile permits simplex I/O.
Sourcing & Quality Verification
- All T9831 units offered by Konmask.com are sourced from traceable industrial supply chains including authorized distributors, OEM surplus, and certified refurbishers.
- Each unit undergoes visual inspection and functional verification prior to dispatch.
- Certificates of conformance (CoC) and test reports available upon request for critical SIS applications.
- Original manufacturer packaging preserved where available; securely repackaged for transit where not.
- Anti-static handling and ESD-safe packaging standard on all shipments.
Procurement Process
- Submit RFQ: Contact Konmask via email or phone with your required quantity, condition preference (new/refurbished), and delivery timeline.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options.
- Order Confirmation: Purchase order accepted via email. Pro-forma invoice issued for prepayment or net terms (qualified accounts).
- Quality Check & Dispatch: Unit inspected, documented, and shipped with tracking. ESD-safe packaging standard.
- Post-Sale Support: Technical documentation, installation guidance, and warranty claims handled by Konmask technical team.
Technical FAQ
Q: Is the T9831 compatible with all Trusted Series chassis versions?
A: The T9831 is designed for the ICS TRIPLEX Trusted Series platform. Compatibility with specific chassis revisions should be confirmed against your system’s hardware revision. Contact Konmask for compatibility verification support.
Q: Can the T9831 be used in a TMR (Triple Modular Redundant) configuration?
A: The T9831 is a simplex TA. TMR analogue input configurations require the corresponding TMR termination assembly. Konmask can advise on the correct TA variant for your redundancy architecture.
Q: What signal types are supported on the 16 channels?
A: The T9831 supports standard industrial analogue signals (typically 4–20 mA current loop). Voltage input capability depends on the paired processor module configuration. Refer to the Trusted Series hardware manual or contact Konmask for the datasheet.
Q: Is a warranty provided?
A: Yes. Konmask provides a standard warranty on all units. Warranty period and terms are specified on the quotation. Extended warranty options available on request.
Q: What is the typical lead time?
A: Lead time varies by stock availability. In-stock units typically ship within 2–5 business days. Contact Konmask for current availability and expedited options.
