Kollmorgen 620-AS S62001 – Analog Input Assembly | S600 / AKD Series Platform
Engineering Background
The Kollmorgen S600 servo drive platform has been a cornerstone of precision motion control in industrial automation for decades. The 620-AS (S62001) Analog Input Assembly is a dedicated expansion module engineered to extend the analog signal acquisition capability of S600-series drives, enabling multi-axis coordinated control, closed-loop feedback integration, and high-resolution process monitoring in demanding production environments.
Product Positioning
Designed for OEM machine builders and system integrators who require deterministic analog signal conditioning within Kollmorgen servo architectures. This module eliminates the need for external signal conditioning hardware, reducing panel footprint and wiring complexity while maintaining the signal integrity demanded by precision servo applications.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 620-AS / S62001 |
| Module Type | Analog Input Assembly |
| Compatible Platform | Kollmorgen S600 Series Servo Drives |
| Signal Type | Analog Input (voltage / current configurable) |
| Resolution | High-resolution ADC (platform-native) |
| Form Factor | Plug-in expansion assembly |
| Weight | 800 g (shipping weight) |
| Country of Origin | USA / EU (OEM) |
| Condition | New OEM / Refurbished (specify on inquiry) |
| Warranty | 12 months Konmask quality guarantee |
Note: Full electrical specifications (input range, impedance, sampling rate) are available in the Kollmorgen S600 Hardware Manual. Contact us for the datasheet.
Proven Application Environments
- CNC Machining Centers – Analog spindle speed reference and axis override signal acquisition
- Packaging Machinery – Tension control and dancer-roll position feedback via analog transducers
- Printing & Converting Lines – Web tension and register control with analog load cells
- Robotics & Gantry Systems – Force/torque sensor integration for compliant motion
- Semiconductor Handling – Ultra-low-noise analog signal acquisition for precision positioning
- Test & Measurement Rigs – Multi-channel analog data acquisition within servo control loops
Engineering Advantages
- Native Platform Integration – Plug-and-play compatibility with S600 drive firmware; no external signal conditioning required
- Signal Integrity – Differential analog input architecture minimizes common-mode noise in industrial environments
- Reduced BOM Complexity – Eliminates external ADC modules, reducing panel wiring and potential failure points
- Deterministic Sampling – Synchronized with drive control cycle for real-time closed-loop performance
- Compact Form Factor – Direct plug-in assembly; no additional DIN rail space required
- Long-term Availability – Konmask maintains verified stock for legacy S600 platform support
System Architecture & Signal Flow
The 620-AS module interfaces directly with the S600 drive’s expansion slot. Analog signals from field transducers (e.g., ±10 V command references, 4–20 mA process sensors, or potentiometer-based position feedback) are routed to the module’s input terminals. The onboard ADC digitizes these signals and presents them to the drive’s DSP control core via the internal high-speed bus, enabling the drive firmware to use analog values as setpoints, feedforward terms, or monitoring variables within the same control scan cycle.
Typical Signal Flow: Field Transducer → Terminal Block → 620-AS Differential Input → Onboard ADC → S600 DSP Control Core → Motion Command Output
Sourcing & Quality Verification
- Source: Authorized distributor channels and verified OEM surplus — no counterfeit risk
- Inspection: Each unit undergoes visual inspection, label verification, and functional continuity check prior to shipment
- Traceability: Lot and serial number documentation available on request
- Packaging: Anti-static ESD packaging with moisture barrier for international transit
- Certification: CE / UL compliance per original OEM certification (documentation available)
Procurement Process
- Submit Inquiry – Email support@konmask.com with your required quantity and delivery timeline
- Receive Quote – Formal quotation with unit price, lead time, and shipping options within 24 business hours
- Order Confirmation – Purchase order accepted; payment via T/T, PayPal, or platform checkout
- Quality Check & Dispatch – Unit inspected, packed, and shipped with tracking number
- After-Sales Support – 12-month warranty; technical support available via email or WhatsApp
Technical FAQ
Q: Is the 620-AS compatible with AKD-series drives?
A: The 620-AS is designed for the S600 platform. AKD drives use a different expansion architecture. Please confirm your drive model before ordering — contact us for compatibility verification.
Q: Can this module accept 4–20 mA current loop signals?
A: Input configuration depends on firmware version and hardware revision. Contact us with your S600 drive firmware version for confirmation.
Q: Do you provide the Kollmorgen S600 Hardware Manual?
A: Yes. The relevant datasheet and hardware manual excerpt can be provided upon request with your order inquiry.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock lead time is typically 2–4 weeks. Confirm availability via inquiry.
Q: Is a certificate of conformance (CoC) available?
A: Yes, CoC and inspection reports are available for orders requiring documentation.
