Kollmorgen S70362-NANANA – High-Performance AC Servo Drive | AKD Series Platform
Engineering Background
Kollmorgen has been a global leader in motion control engineering for over 100 years. The AKD series servo drives represent the company’s flagship platform for precision industrial automation, combining advanced current-loop control with EtherCAT and CANopen fieldbus integration. The S70362-NANANA is a production-grade unit engineered for demanding servo axis applications where dynamic response, thermal stability, and deterministic control are non-negotiable.
Product Positioning
The Kollmorgen S70362-NANANA is designed for procurement engineers and system integrators sourcing a verified, OEM-grade AC servo amplifier for machine tool, robotics, packaging, and semiconductor handling applications. This unit is stocked and dispatched from Konmask.com with full traceability documentation available upon request.
Complete Technical Specifications
| Manufacturer | Kollmorgen |
| Part Number / SKU | S70362-NANANA |
| Series / Platform | AKD Series AC Servo Drive |
| Drive Type | AC Servo Amplifier (Brushless) |
| Continuous Output Current | 3 A (RMS) |
| Peak Output Current | 6 A (RMS) |
| Supply Voltage | 120–240 VAC, Single or Three Phase |
| DC Bus Voltage | 170–340 VDC |
| Feedback Interface | SFD3 / EnDat 2.2 / Resolver / Incremental Encoder |
| Fieldbus / Communication | EtherCAT (CoE), CANopen, Modbus TCP |
| Control Modes | Position, Velocity, Torque (CSP/CSV/CST) |
| Current Loop Bandwidth | Up to 2,000 Hz |
| Velocity Loop Bandwidth | Up to 800 Hz |
| Operating Temperature | 0 °C to +40 °C (ambient) |
| Storage Temperature | -25 °C to +70 °C |
| Protection Rating | IP20 |
| Certifications | CE, UL, cUL, RoHS |
| Weight | 1.5 kg (approx.) |
| Form Factor | Panel-mount, DIN-rail compatible |
Proven Application Environments
- CNC Machine Tools – Precision axis control for milling, turning, and grinding centers requiring sub-micron positioning repeatability.
- Industrial Robotics – Multi-axis coordinated motion in articulated and SCARA robot platforms with EtherCAT synchronization.
- Packaging Machinery – High-speed pick-and-place, form-fill-seal, and labeling lines demanding fast torque response.
- Semiconductor Handling – Ultra-clean, vibration-sensitive wafer transport and inspection stages.
- Printing & Converting – Web tension control and register correction in high-speed printing lines.
- Medical Equipment – Surgical robot joints and diagnostic imaging positioners requiring smooth, low-noise motion.
Engineering Advantages
- 2 kHz Current Loop – Industry-leading bandwidth eliminates torque ripple and enables ultra-smooth velocity profiles at all speeds.
- Auto-Tuning (PDMM) – Kollmorgen’s proprietary auto-tuning algorithm reduces commissioning time from hours to minutes.
- Safe Torque Off (STO) – Integrated SIL 2 / PLd safety function eliminates external safety relays in most machine designs.
- Multi-Feedback Compatibility – Supports SFD3, EnDat 2.2, Hiperface, resolver, and incremental encoders from a single hardware platform.
- Compact Footprint – Slim panel-mount housing reduces cabinet space by up to 30% versus previous-generation drives.
- WorkBench GUI – Intuitive PC-based commissioning software with oscilloscope, Bode plot, and motion task editor included at no cost.
System Architecture & Signal Flow
The S70362-NANANA operates within a closed-loop servo architecture. The host controller (PLC or motion controller) issues position/velocity/torque setpoints via EtherCAT or CANopen at cycle times as low as 250 µs. The AKD’s internal DSP executes the current loop at 16 kHz, comparing motor feedback (encoder/resolver) against the commanded reference and generating PWM gate signals to the IGBT power stage. The regenerative energy path feeds back to the DC bus, with an optional external braking resistor for high-inertia deceleration cycles. I/O signals (digital inputs/outputs, analog reference) are routed through the X7/X8 connectors, while the STO safety channel connects directly to the safety PLC via X13.
Sourcing & Quality Verification
- OEM Traceability – Each unit ships with manufacturer label, date code, and serial number intact. Counterfeit-free supply chain guaranteed.
- Functional Test – All units undergo power-on verification and communication handshake testing before dispatch.
- Packaging – Anti-static ESD bag + foam-lined carton. Suitable for air freight and sea freight.
- Documentation – Datasheet, installation manual, and WorkBench software download links provided with every order.
- Warranty – 12-month warranty against manufacturing defects. RMA process initiated within 24 hours of confirmed fault report.
Procurement Process
- Inquiry – Submit your BOM or part number via email to support@konmask.com or WhatsApp +0086 19859288691.
- Quote – Receive a formal quotation with lead time, unit price, and shipping options within 4 business hours.
- Order Confirmation – Purchase order or online checkout accepted. Proforma invoice issued immediately.
- Payment – T/T bank transfer, PayPal, or credit card. No hidden fees.
- Dispatch – Ships within 1–3 business days. DHL / FedEx / UPS express available. Full tracking provided.
- After-Sales – Technical support and warranty claims handled directly by Konmask engineering team.
Technical FAQ
Q: Is the S70362-NANANA compatible with Kollmorgen AKM servo motors?
A: Yes. The AKD platform is optimized for Kollmorgen AKM and AKM2G motor families. SFD3 feedback cable plug-and-play with no parameter entry required.
Q: Can this drive operate in standalone motion mode without a PLC?
A: Yes. The AKD supports up to 128 programmable motion tasks stored in non-volatile memory, executable via digital I/O triggers without a host controller.
Q: What is the minimum EtherCAT cycle time?
A: 250 µs (4 kHz) in CSP/CSV/CST modes, fully compliant with IEC 61800-7 CiA 402 drive profile.
Q: Does the unit include a built-in braking resistor?
A: The S70362-NANANA includes an internal braking resistor rated for light regenerative loads. For high-inertia applications, an external resistor (Kollmorgen AKD-REGEN series) is recommended.
Q: What certifications does this drive carry?
A: CE (LVD + EMC), UL 508C, cUL, and RoHS 2 compliant. STO function certified to SIL 2 (IEC 62061) and PLd Cat. 3 (ISO 13849-1).
