KUKA 00-207-218-C4-GA12 Robot Controller | KR C4 GA12 Series Platform
Engineering Background: The KUKA KR C4 controller platform represents KUKA Robotics’ fourth-generation unified control architecture, engineered to consolidate robot control, PLC logic, motion planning, and safety functions into a single cabinet. The GA12 variant (part number 00-207-218-C4-GA12) is purpose-built for KUKA KR AGILUS, KR 6, KR 10, and compatible small-to-medium payload robot arms operating in high-cycle industrial environments.
Product Positioning: Designed for procurement engineers and system integrators sourcing verified OEM replacement or expansion controllers for KUKA robotic cells. This unit supports KUKA WorkVisual commissioning software, KUKA.SafeOperation, and standard PROFINET/EtherNet/IP fieldbus integration — making it a drop-in fit for existing KR C4 infrastructure without re-engineering the cell architecture.
Complete Technical Specifications
- Part Number / SKU: 00-207-218-C4-GA12
- Manufacturer: KUKA Robotics (KUKA Deutschland GmbH)
- Controller Series: KR C4 (4th Generation)
- Variant Designation: GA12
- Compatible Robot Families: KR AGILUS, KR 6 R700/R900, KR 10 R900/R1100, KR 16 (select variants)
- Control Architecture: PC-based open architecture (Windows Embedded Standard 7)
- Operating System: KUKA System Software (KSS) 8.x
- Safety System: Integrated KUKA.SafeOperation / SIL 2 / PLd compliant
- Fieldbus Interfaces: PROFINET, EtherNet/IP, DeviceNet, EtherCAT (option-dependent)
- Programming Interface: KRL (KUKA Robot Language), KUKA.PLC mxAutomation
- Cabinet Dimensions: Compact footprint, GA12 small cabinet format
- Power Supply: 3-phase AC, 200–480 V, 50/60 Hz
- Weight: Approx. 420 g (controller board assembly)
- Country of Origin: Germany
- Cooling: Active air cooling with filtered intake
- Protection Class: IP 54 (cabinet)
- Ambient Temperature: 5°C to 45°C (operating); -25°C to 60°C (storage)
- Certifications: CE, UL, cUL
Proven Application Environments
- Automotive body-in-white welding and assembly lines
- Electronics manufacturing — PCB handling, pick-and-place, soldering
- Pharmaceutical and medical device packaging (cleanroom-compatible configurations)
- Food & beverage palletizing and secondary packaging
- Machine tending and CNC cell integration
- Collaborative and human-robot cooperation (HRC) cells with SafeOperation
- Laboratory automation and high-throughput testing systems
Engineering Advantages
- Unified Control Platform: Single KR C4 cabinet handles robot motion, PLC, safety, and process control — eliminating external PLC hardware in many cell designs.
- Open PC Architecture: Standard x86 hardware enables third-party software integration, OPC-UA connectivity, and Industry 4.0 data collection without proprietary middleware.
- Hot-Swap Serviceability: Modular drive and control boards support in-field replacement without full cabinet swap, minimizing unplanned downtime.
- Scalable Safety: KUKA.SafeOperation and SafeRangeMonitoring configurable via WorkVisual — no additional safety PLC required for most SIL 2 / PLd applications.
- Multi-Robot Coordination: Native support for RoboTeam multi-robot synchronization over standard Ethernet infrastructure.
- Energy Efficiency: Regenerative energy recovery fed back to the supply network, reducing cell energy consumption by up to 25% vs. previous generation.
System Architecture & Signal Flow
The KR C4 GA12 controller operates on a real-time EtherCAT backplane connecting the KPC (controller PC), KPP (power pack), and KSP (servo pack) modules. The KPC runs KSS on a real-time Windows kernel partition, executing KRL motion programs and PLC logic simultaneously at 12 ms cycle times. Safety-relevant signals are processed on a dedicated KUKA.SafetyController hardware channel, physically isolated from the standard control bus. External fieldbus communication (PROFINET/EtherNet/IP) is handled by a dedicated interface card, ensuring deterministic I/O response independent of HMI load.
Sourcing & Quality Verification
- OEM Authenticity: All units sourced through verified KUKA authorized distribution channels or directly from certified KUKA system integrators.
- Inspection Protocol: Each unit undergoes visual inspection, firmware version verification, and functional power-on test prior to shipment.
- Documentation Provided: Original KUKA part label, serial number record, and test report included with shipment.
- Warranty: 90-day functional warranty against manufacturing defects. Extended warranty available upon request.
- Traceability: Full supply chain traceability maintained — batch records available for regulated industry customers.
Procurement Process
- Submit your inquiry with robot serial number and KSS version to [email protected] for compatibility confirmation.
- Receive formal quotation with lead time and shipping options within 1 business day.
- Place order via Konmask.com checkout or request a proforma invoice for bank transfer.
- Unit ships with full documentation; tracking provided within 24 hours of dispatch.
- Post-delivery technical support available via email and phone for commissioning assistance.
Technical FAQ
Q: Is 00-207-218-C4-GA12 compatible with KR C4 compact controllers?
A: This part number is specific to the standard KR C4 GA12 cabinet format. For KR C4 compact, please contact us with your robot model for cross-reference verification.
Q: Which KSS firmware version does this unit ship with?
A: Units are supplied with the firmware version as received from the OEM channel. Firmware upgrade to KSS 8.6+ is available — please specify your target version at time of order.
Q: Can this controller be used as a replacement for a failed KR C4 unit without re-teaching the robot?
A: Yes, provided the robot configuration archive (WorkVisual project) is backed up from the original controller. The archive can be restored to the replacement unit, preserving all taught positions and cell configurations.
Q: Do you provide export documentation for international shipments?
A: Yes. Commercial invoice, packing list, and certificate of origin are provided as standard. ECCN classification and export license support available for controlled destinations.
Q: What is the lead time for this part?
A: Typically 3–7 business days for in-stock units. For urgent requirements, contact us directly for expedited options.
