LAFERT XD101/452 (LAF.B7132Z-03270) Servo Driver | Replacement, Equivalent & Selection Guide
The LAFERT XD101/452 (part number LAF.B7132Z-03270) is a high-performance AC servo driver engineered for precision motion control in demanding industrial automation environments. This page provides full technical specifications, verified compatible replacements, a structured selection guide, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Brand | LAFERT |
| Model / SKU | XD101/452 |
| Part Number | LAF.B7132Z-03270 |
| Product Type | AC Servo Driver / Servo Amplifier |
| Series | XD101 |
| Rated Output | Refer to nameplate / datasheet |
| Input Voltage | 3-phase AC (confirm with nameplate) |
| Weight | 5.9 kg (approx.) |
| Condition | New / Surplus |
| Compliance | CE (confirm with datasheet) |
Note: Always verify specifications against the original nameplate and LAFERT documentation before installation.
Compatible Replacement & Equivalent Models
When the original LAFERT XD101/452 is unavailable or discontinued, the following alternatives may be considered. Compatibility must be verified against your system’s motor, encoder, and bus requirements:
- LAFERT XD101 series variants — same platform, different power ratings; confirm current and voltage match
- Lenze i700 / 9400 series — comparable servo drive architecture for European OEM machinery
- Siemens SINAMICS S120 — widely used replacement in multi-axis servo systems
- Bosch Rexroth IndraDrive Cs/Mi — suitable for high-dynamic servo applications
- Yaskawa Sigma-7 (SGDV/SGDH) — cost-effective equivalent for Asian-market retrofits
- Mitsubishi MR-J4 / MR-J5 series — compatible in many CNC and robotics retrofit scenarios
⚠ Important: Cross-brand replacements require re-parameterization and motor re-tuning. Contact our engineers for a compatibility assessment before ordering.
Why Choose the Original LAFERT XD101/452
- OEM-matched performance — drop-in replacement with zero re-engineering for LAFERT-equipped machines
- Proven reliability — field-tested in European industrial machinery with long MTBF records
- Exact encoder & bus compatibility — no firmware adaptation required for original motor pairing
- Reduced commissioning time — retain existing parameters and wiring schematics
- Warranty & traceability — genuine part with full documentation and serial traceability
Typical Applications
- CNC machining centers and turning lathes
- Packaging and labeling machinery
- Textile and winding equipment
- Printing and converting lines
- Robotics and multi-axis motion systems
- Injection molding machines
- Material handling and conveyor automation
System Compatibility
The LAFERT XD101/452 is designed to operate with LAFERT XD-series servo motors. Key compatibility checkpoints:
- Motor pairing: Verify motor frame size, rated current, and encoder type (incremental / absolute)
- Fieldbus / communication: Confirm supported protocols (CANopen, EtherCAT, PROFIBUS, or analog ±10 V)
- Power supply: Match input voltage and phase configuration to site supply
- Regenerative braking: Check if external braking resistor is required for your duty cycle
- Cooling: Ensure adequate panel ventilation or forced-air cooling per LAFERT installation guidelines
Selection Guide
Use the following criteria to confirm the XD101/452 is the right choice — or to identify the best alternative:
- Rated motor power & current — match drive output current to motor nameplate
- Supply voltage — single-phase vs. three-phase; 200 V vs. 400 V class
- Encoder interface — incremental TTL, EnDat 2.1/2.2, Hiperface, or resolver
- Communication protocol — standalone analog, CANopen DS402, EtherCAT CoE, or PROFINET
- Dynamic requirements — bandwidth, torque ripple, and positioning accuracy targets
- Environmental rating — IP class, ambient temperature, and humidity range
- Safety functions — STO (Safe Torque Off), SS1, SLS requirements per IEC 61800-5-2
Not sure which model fits your application? Contact our selection engineers with your motor nameplate data and we will recommend the optimal solution.
Quality Assurance & Sourcing
- Source: Authorized distributors, OEM surplus, and verified secondary market channels
- Inspection: Each unit undergoes visual inspection and functional verification before shipment
- Documentation: Certificate of conformity, test report, and packing list provided on request
- Traceability: Serial number and batch records maintained for full supply-chain transparency
- Warranty: 12-month warranty against manufacturing defects (terms apply)
How to Order
- Add the LAFERT XD101/452 (LAF.B7132Z-03270) to your cart and proceed to checkout, or
- Email support@konmask.com with your PO, delivery address, and required quantity
- For urgent requirements, call / WhatsApp: +0086 19859288691
- Lead time: In-stock units ship within 1–3 business days; sourced units typically 5–15 business days
- Export documentation (commercial invoice, packing list, COO) available for international shipments
Replacement & Compatibility FAQ
Q: Can I use a Siemens SINAMICS S120 to replace the LAFERT XD101/452?
A: Potentially yes, but it requires motor re-parameterization, new encoder cabling, and PLC program adjustments. We recommend consulting our engineers first.
Q: Is the XD101/452 still in production?
A: LAFERT’s XD101 series has been superseded in some markets. Contact us to confirm current availability and recommended successors.
Q: Do you supply the matching LAFERT servo motor?
A: Yes. We can source matched LAFERT XD-series motors. Provide your motor nameplate data for a complete drive-motor package quote.
Q: What is the difference between XD101/452 and other XD101 variants?
A: The suffix (e.g., /452) typically denotes the power rating or configuration option. Contact us with your full part number for a precise comparison.
Q: Can you provide a test report before shipment?
A: Yes. Functional test reports are available upon request for all units.
