LENZE 8400 PROTEC E84DEPCE7514C5CNRR – Decentralised Frequency Inverter | 8400 PROTEC Platform
Engineering Background
The LENZE 8400 PROTEC series represents Lenze’s flagship decentralised drive solution, engineered for direct machine-mounting in demanding industrial environments. Eliminating centralised control cabinet requirements, the 8400 PROTEC reduces installation complexity and cable runs while delivering precise motor control at the point of load.
Product Positioning
The E84DEPCE7514C5CNRR is a 0.75 kW three-phase decentralised frequency inverter rated IP65, designed for procurement engineers specifying distributed drive architectures in conveyor systems, material handling, and factory automation. It integrates seamlessly into Lenze’s L-force automation ecosystem and supports multiple fieldbus protocols for Industry 4.0 connectivity.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | E84DEPCE7514C5CNRR |
| Series | 8400 PROTEC |
| Manufacturer | LENZE SE (Germany) |
| Output Power | 0.75 kW (1.0 HP) |
| Input Voltage | 3-phase AC 380–480 V ±10% |
| Output Frequency Range | 0–650 Hz |
| Control Mode | V/f, Sensorless Vector (SLVC) |
| Protection Rating | IP65 (dust-tight, jet-proof) |
| Mounting Style | Decentralised / Machine-mounted |
| Communication Interface | CANopen / EtherCAT / PROFIBUS (suffix-dependent) |
| Braking | Built-in DC braking; external brake resistor compatible |
| Ambient Temperature | -10 °C to +40 °C (operating); -25 °C to +70 °C (storage) |
| Relative Humidity | ≤ 95% non-condensing |
| Weight | Approx. 1.43 kg |
| Country of Origin | Germany |
| Certifications | CE, UL, cUL |
Proven Application Environments
- Conveyor & Intralogistics: Belt conveyors, roller conveyors, sortation systems requiring distributed drive nodes
- Packaging Machinery: Filling, sealing, and labelling lines with tight synchronisation requirements
- Material Handling: Automated storage and retrieval systems (AS/RS), pallet transfer units
- Food & Beverage: Washdown-tolerant installations leveraging IP65 enclosure rating
- Automotive Assembly: Body-in-white transfer lines and powertrain assembly conveyors
- Textile & Printing: Web tension control and winding applications
Engineering Advantages
- Decentralised Architecture: Mounts directly on or near the motor, eliminating long motor cables and reducing EMC interference
- IP65 Enclosure: Suitable for harsh environments with dust, moisture, and occasional water jets without additional enclosure
- Plug-and-Play Motor Integration: Compatible with Lenze MF/MH motor series via direct connector coupling
- Fieldbus Flexibility: Supports CANopen, EtherCAT, and PROFIBUS DP for seamless PLC/SCADA integration
- Energy Efficiency: IE2-equivalent drive efficiency with integrated energy recovery capability
- Compact Footprint: Reduces control cabinet size and associated cooling costs
- Parameterisation via L-force Engineer: Unified software environment for commissioning, diagnostics, and firmware updates
System Architecture & Signal Flow
The E84DEPCE7514C5CNRR operates within the Lenze L-force automation platform. The signal flow is as follows:
- PLC / Motion Controller → Fieldbus command (speed setpoint, enable, direction)
- 8400 PROTEC Inverter → PWM modulation → Motor control output
- Motor Feedback (encoder optional) → Closed-loop speed/torque regulation
- Diagnostics → Status word transmitted back to PLC via fieldbus; accessible via L-force Engineer software
The decentralised topology eliminates the central drive cabinet, distributing intelligence to each drive node and enabling modular machine design with simplified wiring harnesses.
Sourcing & Quality Verification
- All units sourced through authorised industrial distribution channels with full traceability
- Each unit inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Original manufacturer packaging preserved where available; repackaged units clearly identified
- Batch documentation and country-of-origin certificates available upon request
- Anti-counterfeit verification: holographic labels and serial number cross-check against Lenze production records
Procurement Process
- Confirm Part Number: Verify E84DEPCE7514C5CNRR matches your BOM and application voltage/power requirements
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation
- Place Order: Purchase via Konmask.com checkout or issue a PO for B2B accounts
- Shipping: DHL Express / FedEx International Priority; export documentation included for cross-border shipments
- Incoming Inspection: Recommended 100% visual and functional check upon receipt; Konmask provides 30-day return window for DOA units
Technical FAQ
Q: Is the E84DEPCE7514C5CNRR compatible with third-party motors?
A: Yes. While optimised for Lenze MF/MH motors, it supports any standard three-phase induction motor within the rated power range via standard IEC connector.
Q: What fieldbus protocol does the suffix “C5” indicate?
A: The “C5” suffix in the Lenze 8400 PROTEC naming convention denotes CANopen communication interface. Confirm your network topology before ordering.
Q: Can this inverter be used in a STO (Safe Torque Off) safety application?
A: The base E84DEPCE7514C5CNRR supports STO via the integrated safety input. Verify SIL/PLe certification requirements with your safety engineer and consult the Lenze 8400 PROTEC safety manual.
Q: What is the minimum order quantity?
A: Single units available. Volume discounts apply for orders of 5+ units. Contact us for project pricing.
Q: Do you provide a warranty?
A: 12-month warranty against manufacturing defects. Extended warranty options available for OEM/system integrator accounts.
