MITSUBISHI AY22 Transistor Output Local Unit Module – MELSEC-A Series
When a critical output module fails on the production line, every second of downtime translates directly into lost revenue, missed delivery windows, and cascading equipment faults. The MITSUBISHI AY22 is the transistor output local unit module that keeps your MELSEC-A Series PLC system running without interruption — delivering fast, reliable NPN transistor switching for discrete output control in demanding industrial environments.
Within the MELSEC-A Series family, the AY22 occupies a foundational role as a 16-point NPN transistor output local unit, designed for direct integration with A-Series CPU base units. Its solid-state switching architecture, compact footprint, and proven compatibility with Mitsubishi’s A-Series ecosystem have made it a trusted component in manufacturing plants, process control systems, and machine automation applications worldwide.
Technical Specifications
- Model: AY22
- Series: MELSEC-A Series
- Module Type: Transistor Output Local Unit Module
- Output Points: 16 points
- Output Type: NPN (sink) transistor
- Rated Load Voltage: 12–24 VDC
- Max Load Current: 0.1 A per point
- Isolation Method: Photocoupler isolation
- Response Time (OFF→ON): 1 ms or less
- Response Time (ON→OFF): 1 ms or less
- External Power Supply: 12–24 VDC
- Applicable CPU: MELSEC-A Series CPU modules
- Mounting: Local unit (base-mounted)
- Operating Temperature: 0–55°C
- Storage Temperature: -20–75°C
- Weight: Approx. 250 g
Key Features & Benefits
- Solid-State Reliability: Transistor output eliminates mechanical wear, extending service life in high-cycle applications.
- Fast Switching: ≤1 ms response time ensures precise timing control for high-speed machinery.
- Photocoupler Isolation: Protects the CPU from load-side voltage spikes and electrical noise.
- 16-Point Density: Maximizes I/O capacity per slot, reducing overall panel footprint.
- Direct MELSEC-A Compatibility: Plug-and-play integration with A-Series base units — no adapter required.
- Wide Voltage Range: 12–24 VDC load voltage accommodates diverse field device requirements.
- Proven Longevity: Manufactured to Mitsubishi Electric’s industrial-grade quality standards for long-term availability.
Industry & Equipment Applications
- Automotive Manufacturing: Body assembly lines, welding robots, conveyor indexing systems
- Food & Beverage Processing: Filling machines, packaging lines, conveyor control
- Semiconductor & Electronics: Pick-and-place equipment, test handlers, wafer processing
- Textile Machinery: Loom control, yarn tension systems, fabric inspection lines
- Material Handling: Palletizers, sorters, automated storage and retrieval systems (ASRS)
- Water Treatment: Pump control panels, valve actuation, dosing systems
System Integration & Compatible Parts
The AY22 is designed for use within the MELSEC-A Series architecture. Compatible and commonly paired components include:
- MELSEC-A Series CPU modules (e.g., A1CPU, A2CPU, A3CPU)
- MELSEC-A Series base units (A1S38B, A1S55B, A1S65B)
- Complementary input modules: AX40, AX80, AX10
- Power supply modules: A1S61P, A1S62P
- Programming tools: GX Developer, GX Works2 (with A-Series support)
For system design assistance or compatibility verification, contact our technical team at support@konmask.com.
Our Quality Assurance Process
Every MITSUBISHI AY22 module sourced through Konmask.com undergoes a rigorous multi-stage verification process:
- Authenticity Verification: Cross-referenced against Mitsubishi Electric’s official part numbering and labeling standards.
- Visual Inspection: Checked for physical damage, connector integrity, and label authenticity.
- Functional Pre-check: Where applicable, modules are bench-tested prior to dispatch.
- Secure Packaging: Anti-static packaging with moisture barrier protection for safe international shipping.
- Documentation: Certificate of conformity and packing list provided with every order.
How to Order
- Submit your inquiry via the Contact / RFQ form on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond with availability, lead time, and a formal quotation within 24 hours.
- Upon order confirmation, we arrange secure packaging and international logistics.
- Tracking information and shipping documents are provided upon dispatch.
📧 support@konmask.com | 📞 +0086 19859288691
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: Focused exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- ✅ Global B2B Supply: Serving engineering teams, MRO buyers, and system integrators across 30+ countries.
- ✅ Competitive Lead Times: Extensive supplier network enables fast sourcing of both current and legacy parts.
- ✅ Technical Support: Our team includes experienced automation engineers who can assist with compatibility and integration questions.
- ✅ Transparent Quotation: No hidden fees. Clear pricing, lead time, and shipping terms in every quote.
Frequently Asked Questions
Q: Is the MITSUBISHI AY22 still in production?
A: The AY22 is part of the legacy MELSEC-A Series. While Mitsubishi Electric has transitioned to newer platforms (MELSEC-Q, iQ-R), the AY22 remains available as a replacement/spare part through authorized distributors and specialist suppliers like Konmask.com.
Q: What is the difference between AY22 and AY22E?
A: The AY22E is an enhanced variant with extended output specifications. Please contact us to confirm the exact variant required for your application.
Q: Can the AY22 be used with MELSEC-Q Series base units?
A: No. The AY22 is designed exclusively for MELSEC-A Series base units and is not compatible with Q-Series or iQ-R Series hardware without an adapter unit.
Q: What is the minimum order quantity?
A: We supply from single units upward. Contact us with your quantity requirement for the best available pricing.
Q: Do you provide a warranty?
A: Yes. All modules are covered by our standard quality guarantee. Terms are confirmed at the time of quotation.
