Mitsubishi FX0N-60MR-001 Programmable Logic Controller | Replacement, Equivalent & Selection Guide
The Mitsubishi FX0N-60MR-001 is a compact, high-performance PLC from Mitsubishi Electric’s FX0N series, featuring 60 I/O points with relay output. Widely deployed in industrial automation, machine control, and process management applications, this controller delivers reliable performance in demanding environments. Whether you are sourcing an original unit, evaluating compatible replacements, or selecting the right model for your system, this guide covers everything you need.
Technical Specifications
- Model: FX0N-60MR-001
- Brand: Mitsubishi Electric
- Series: FX0N
- I/O Points: 60 (36 inputs / 24 outputs)
- Output Type: Relay (MR)
- Power Supply: AC 100–240V
- Program Memory: 2,000 steps
- Scan Time: 0.08 ms/step (basic instructions)
- Communication: RS-422 (built-in programming port)
- Dimensions (W×H×D): 220 × 90 × 87 mm (approx.)
- Weight: Approx. 1,600 g
- Operating Temperature: 0–55°C
- Protection Rating: IP20
- Certifications: CE, UL
Compatible Replacement & Equivalent Models
When the FX0N-60MR-001 is discontinued or unavailable, the following models offer functional compatibility or direct replacement options:
- Mitsubishi FX1N-60MR-001 – Upgraded successor with expanded memory (8,000 steps) and enhanced communication; direct I/O pin-compatible drop-in replacement.
- Mitsubishi FX3G-60MR/ES – Next-generation FX3G series with USB programming port, built-in analog I/O option, and improved processing speed.
- Mitsubishi FX2N-64MR-001 – Higher-end model with 64 I/O, suitable for applications requiring more I/O expansion.
- Mitsubishi FX0N-60MT-001 – Transistor output variant of the same model; select when high-speed pulse output is required.
- Siemens SIMATIC S7-1200 CPU 1214C – Cross-brand alternative for new designs; requires reprogramming but offers modern Ethernet connectivity.
Note: Always verify I/O wiring, power supply voltage, and program compatibility before substituting any replacement model.
Why Choose the Original Model
- Proven Reliability: The FX0N-60MR-001 has a long track record in industrial environments with MTBF exceeding 100,000 hours.
- Seamless Integration: Fully compatible with existing FX0N expansion modules, special function modules, and GX Developer / GX Works2 programming software.
- Relay Output Durability: Relay outputs handle resistive loads up to 2A per point, ideal for direct control of contactors, solenoids, and indicator lamps.
- Cost-Effective Maintenance: Retaining the original model eliminates reprogramming costs and minimizes downtime during replacement.
- Spare Parts Availability: Konmask.com maintains stock of genuine and equivalent units to support long-term maintenance contracts.
Typical Applications
- Conveyor and material handling systems
- Packaging and labeling machinery
- Injection molding machine control
- HVAC and building automation
- Water treatment and pump control
- Assembly line sequencing and interlocking
- Textile and printing machine control
System Compatibility
- Expansion Modules: FX0N-8EX, FX0N-8EYR, FX0N-8EYT, FX0N-3A, FX0N-16EX, FX0N-16EYR
- Special Function Modules: FX0N-3A (analog I/O), FX2N-2AD, FX2N-2DA (with adapter)
- Communication Adapters: FX0N-232ADP, FX0N-485ADP
- Programming Software: GX Developer 8.x+, GX Works2
- HMI Compatibility: Mitsubishi GOT1000/GOT2000 series, third-party HMIs via RS-422/RS-232 protocol
Selection Guide
Use the following criteria to determine whether the FX0N-60MR-001 is the right choice for your application:
- I/O Count: Requires exactly 60 I/O points (36 DI / 24 DO)? → FX0N-60MR-001 is optimal. Need more? → Consider FX1N-60MR-001 or FX3G-60MR/ES.
- Output Type: Controlling contactors or lamps (resistive/inductive loads)? → Relay output (MR) is correct. Need high-speed pulse output for servo/stepper? → Select FX0N-60MT-001 (transistor output).
- Program Complexity: Program < 2,000 steps? → FX0N-60MR-001 is sufficient. Larger programs? → Upgrade to FX1N or FX3G series.
- Communication Needs: RS-422 only? → FX0N-60MR-001. Need USB or Ethernet? → FX3G-60MR/ES or FX5U series.
- Budget: Maintenance replacement of existing system → Original model preferred. New design with flexibility → Evaluate FX3G or FX5U for future-proofing.
Quality Assurance & Sourcing
- Genuine Units: Sourced directly from authorized Mitsubishi Electric distributors and verified supply chains.
- Inspection: Every unit undergoes visual inspection, label verification, and functional power-on testing before shipment.
- Warranty: 12-month warranty against manufacturing defects on all units shipped from Konmask.com.
- Traceability: Batch records and certificates of conformity available upon request for OEM and MRO customers.
- Anti-Counterfeit: We do not source from gray-market channels. All units include original Mitsubishi Electric packaging and documentation where available.
How to Order
- Confirm your required model number: FX0N-60MR-001
- Specify quantity and required delivery timeline.
- Contact us via email or phone for bulk pricing, lead time confirmation, and shipping options.
- Receive proforma invoice → confirm payment → dispatch within 1–3 business days for in-stock units.
- Track your shipment via the provided waybill number.
📧 Email: [email protected]
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Is the FX1N-60MR-001 a direct drop-in replacement for the FX0N-60MR-001?
A: Yes, the FX1N-60MR-001 is I/O-pin compatible and uses the same wiring layout. However, the program must be re-verified as the FX1N has expanded instruction sets and memory.
Q: Can I use FX0N expansion modules with the FX1N or FX3G?
A: FX0N expansion modules (FX0N-8EX, FX0N-8EYR, etc.) are compatible with FX1N. FX3G uses its own expansion bus; an adapter may be required.
Q: What programming cable do I need for the FX0N-60MR-001?
A: Use the SC-09 RS-422 programming cable or a USB-SC09-FX USB adapter for connection to a PC running GX Developer or GX Works2.
Q: Is the FX0N-60MR-001 still in production?
A: The FX0N series has been discontinued by Mitsubishi Electric. Konmask.com supplies genuine new-old-stock (NOS) and refurbished units. Contact us for current availability.
Q: Can I mix relay and transistor output modules in the same FX0N system?
A: The main unit output type is fixed (relay for MR, transistor for MT). You can add transistor output expansion modules (FX0N-8EYT) alongside a relay-output main unit.
