Mitsubishi FX2N-16EX-ES/UL 16-Point Digital Input Module | Replacement, Equivalent & Selection Guide
The Mitsubishi FX2N-16EX-ES/UL is a 16-point digital input expansion module designed for the FX2N series programmable logic controller (PLC) platform. It extends the I/O capacity of FX2N base units, making it a critical component in industrial automation, machine control, and process monitoring applications. This page provides full technical specifications, compatible replacement options, equivalent models, and a practical selection guide for engineers and procurement teams.
Technical Specifications
- Model: FX2N-16EX-ES/UL
- Manufacturer: Mitsubishi Electric
- Series: MELSEC FX2N
- Module Type: Digital Input Expansion Module
- Number of Input Points: 16 points
- Input Type: DC sink/source (24 VDC)
- Input Voltage: 24 VDC (±10%)
- Input Current: Approx. 7 mA per point
- Response Time: 10 ms (default); adjustable 0–60 ms
- Isolation: Photocoupler isolation
- Connection Method: Terminal block (M3 screws)
- Power Consumption: 5 VDC, 90 mA (from base unit bus)
- Weight: Approx. 160 g
- Certifications: UL Listed, CE Marked
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -25°C to 75°C
- Humidity: 5% to 95% RH (non-condensing)
- Dimensions (W×H×D): 55 × 90 × 87 mm
Compatible Replacement & Equivalent Models
When the FX2N-16EX-ES/UL is discontinued, unavailable, or requires a cost-effective alternative, the following models offer functional compatibility or direct replacement capability:
- Mitsubishi FX2N-16EX — Standard 16-point input module for FX2N; identical I/O count, without ES/UL certification markings. Direct functional equivalent for non-UL applications.
- Mitsubishi FX3U-16EX — FX3U-series 16-point input expansion; backward-compatible with FX2N base units via FX2N-CNV-BC adapter. Recommended upgrade path.
- Mitsubishi FX3G-16EX/ES-L — Compact FX3G-series equivalent; suitable for space-constrained panel designs.
- Mitsubishi FX5U-16EX/ES — FX5U-series high-speed input module; requires FX5 base unit. Ideal for new system designs replacing legacy FX2N.
- Mitsubishi FX2N-32EX — 32-point input expansion; use when additional I/O consolidation is required in a single slot.
Note: Always verify bus compatibility and power budget before substituting expansion modules. Contact Konmask for cross-reference verification.
Why Choose the Original FX2N-16EX-ES/UL
- Certified Compliance: UL Listed and CE Marked for North American and European market requirements.
- Proven Reliability: Mitsubishi Electric FX2N platform has a decades-long track record in demanding industrial environments.
- Seamless Integration: Plug-and-play expansion with all FX2N base units — no additional configuration required.
- Photocoupler Isolation: Protects the CPU from field-side voltage transients and noise.
- Flexible Input Wiring: Supports both sink and source wiring configurations for maximum field device compatibility.
- Genuine OEM Part: Sourced directly from authorized Mitsubishi Electric distribution channels, ensuring full warranty and traceability.
Typical Applications
- Machine tool control and CNC auxiliary I/O expansion
- Conveyor and material handling systems
- Packaging and labeling machinery
- HVAC and building automation panels
- Water treatment and pump station monitoring
- Automotive assembly line control
- Food and beverage processing equipment
- Textile and printing machinery
System Compatibility
The FX2N-16EX-ES/UL is compatible with the following Mitsubishi FX2N base units and system configurations:
- Base Units: FX2N-16MR, FX2N-32MR, FX2N-48MR, FX2N-64MR, FX2N-80MR, FX2N-128MR (and MT/ES/UL variants)
- Maximum Expansion: Up to 8 expansion modules per FX2N base unit (subject to I/O point and power budget limits)
- Special Adapters: Compatible with FX2N-CNV-BD for communication board integration
- Not Compatible With: FX1S, FX1N series (different bus architecture); FX5U series (requires FX5 expansion bus)
Selection Guide
Use the following criteria to select the correct expansion module for your application:
- I/O Count: Choose FX2N-16EX-ES/UL for 16 additional input points. For 32 points, consider FX2N-32EX.
- Certification Requirement: ES/UL suffix indicates UL Listing — required for North American installations. Standard FX2N-16EX is sufficient for non-UL markets.
- Input Voltage: Confirm field devices operate at 24 VDC. For AC input applications, consider FX2N-16EX-A1 (100–120 VAC input).
- Response Time: Default 10 ms suits most applications. For high-speed counting or encoder inputs, use dedicated FX2N-1HC or FX2N-4HSX modules instead.
- Future Expansion: If migrating to FX3U or FX5U platform, select FX3U-16EX or FX5U-16EX/ES for forward compatibility.
- Power Budget: Each FX2N-16EX-ES/UL consumes 90 mA from the 5 VDC bus. Verify total expansion current does not exceed base unit supply rating.
Quality Assurance & Sourcing
All Mitsubishi Electric products supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes the following quality checks before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Verification of serial number and date code against manufacturer records
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Certificate of conformance available upon request
We do not supply counterfeit, refurbished-as-new, or unverified grey-market components. All products carry the original manufacturer warranty.
How to Order
- Part Number: FX2N-16EX-ES/UL
- Manufacturer: Mitsubishi Electric
- Lead Time: In-stock items ship within 1–3 business days; ex-stock orders subject to availability confirmation
- Minimum Order Quantity: 1 piece
- Bulk Pricing: Available for orders of 5+ units — contact us for a quote
- Payment: T/T, PayPal, credit card, and trade credit (approved accounts)
- Shipping: DHL, FedEx, UPS, SF Express — worldwide delivery
- RFQ / Inquiry: support@konmask.com | +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I use FX2N-16EX-ES/UL with an FX3U base unit?
A: Yes, with the FX2N-CNV-BC adapter, FX2N expansion modules can be connected to FX3U base units. However, Mitsubishi recommends using native FX3U expansion modules for new designs.
Q: What is the difference between FX2N-16EX and FX2N-16EX-ES/UL?
A: The ES/UL variant carries UL Listing certification, required for installations in North America. Functionally, both modules are identical.
Q: Is the FX2N-16EX-ES/UL still in production?
A: The FX2N series has reached end-of-life status with Mitsubishi Electric. Konmask maintains stock of genuine new-old-stock (NOS) and sourced units. Contact us for current availability.
Q: Can this module handle 120 VAC inputs?
A: No. The FX2N-16EX-ES/UL accepts 24 VDC inputs only. For AC input requirements, use the FX2N-16EX-A1 (100–120 VAC) variant.
Q: How many FX2N-16EX-ES/UL modules can I connect to one base unit?
A: Up to 8 expansion modules total (combined input and output), subject to the base unit’s 5 VDC bus current limit. Always calculate total expansion current before finalizing the configuration.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com to request the official Mitsubishi FX2N-16EX-ES/UL hardware manual and wiring diagrams.
