Mitsubishi FX2N-16MR-001 Relay Output PLC Module | Replacement, Equivalent & Selection Guide
The Mitsubishi FX2N-16MR-001 is a compact, high-performance programmable logic controller (PLC) from Mitsubishi Electric’s FX2N series. Designed for industrial automation, it features 8 DC inputs and 8 relay outputs, powered by 100–240VAC. At Konmask.com, we supply genuine FX2N-16MR-001 units and help engineers identify compatible replacements and equivalent models for seamless system integration.
Technical Specifications
- Model: FX2N-16MR-001
- Series: Mitsubishi FX2N
- I/O Points: 16 (8 inputs / 8 relay outputs)
- Input Type: DC 24V sink/source
- Output Type: Relay (MR)
- Power Supply: 100–240VAC, 50/60Hz
- Program Memory: 8,000 steps (expandable to 16,000 with memory cassette)
- Max I/O Expansion: Up to 256 I/O points
- Communication: RS-422 (built-in), supports FX2N-232-BD / 485-BD expansion
- Weight: Approx. 1,140 g
- Standards: CE, UL, cUL compliant
Compatible Replacement & Equivalent Models
If the FX2N-16MR-001 is discontinued or unavailable, the following models offer compatible or equivalent functionality:
- Mitsubishi FX3U-16MR/ES — Direct upgrade; same relay output, enhanced processing speed and memory. Recommended drop-in replacement.
- Mitsubishi FX3G-14MR/ES — Compact alternative with 14 I/O; suitable for space-constrained panels.
- Mitsubishi FX2N-16MT-001 — Same I/O count but transistor (NPN) output; use when high-speed switching is required.
- Mitsubishi FX1N-14MR-001 — Entry-level alternative; fewer features but cost-effective for simple applications.
- Mitsubishi FX5U-32MR/ES — Advanced iQ-F series; ideal for new projects requiring Ethernet and high-speed I/O.
Note: Always verify I/O count, output type, and power supply compatibility before substitution. Contact our engineers for a free compatibility check.
Why Choose the Original FX2N-16MR-001
- Proven reliability in millions of industrial installations worldwide
- Extensive FX2N ecosystem: wide range of expansion modules, communication adapters, and memory cassettes
- Supported by GX Developer and GX Works2 programming software
- Long field service history — spare parts and documentation readily available
- Relay output handles AC/DC loads without additional interface relays
Typical Applications
- Machine tool automation and CNC auxiliary control
- Conveyor and material handling systems
- Packaging and labeling machinery
- HVAC and building automation panels
- Water treatment and pump control stations
- Small-scale process control and OEM equipment
System Compatibility
- Expansion Modules: FX2N-8EX, FX2N-8EYR, FX2N-4AD, FX2N-4DA, FX2N-1PG, and all FX2N-series I/O blocks
- Communication Boards: FX2N-232-BD, FX2N-485-BD, FX2N-CNV-BD
- Programming Software: GX Developer 8.x+, GX Works2
- HMI: Compatible with Mitsubishi GOT1000/GOT2000 series and most third-party HMIs via RS-422/485
- Upgrade Path: Programs can be migrated to FX3U/FX5U with minor modifications using GX Works3 conversion tools
Selection Guide
Use the table below to select the right FX2N or equivalent model for your application:
- Need relay output + AC power + 16 I/O? → FX2N-16MR-001 (this model) or FX3U-16MR/ES
- Need transistor output for high-speed pulses? → FX2N-16MT-001 or FX3U-16MT/ES
- Need more I/O in same footprint? → FX2N-32MR-001 (32 I/O) or FX3U-32MR/ES
- Budget-sensitive small project? → FX1N-14MR-001
- New project with Ethernet & advanced features? → FX5U-32MR/ES (iQ-F series)
- Replacing a failed unit in existing panel? → FX2N-16MR-001 (original) for zero-modification swap
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Each module inspected and function-tested before shipment
- Genuine Mitsubishi Electric product — no counterfeit or refurbished units without disclosure
- Traceable batch documentation available on request
- Warranty: 12 months from date of shipment
How to Order
- Add the FX2N-16MR-001 to your cart and proceed to checkout, or
- Contact us directly for bulk pricing, lead time confirmation, or custom sourcing
- Provide your application details for a free compatibility and selection consultation
- We ship worldwide — DHL, FedEx, UPS express options available
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Is the FX2N-16MR-001 still in production?
A: The FX2N series has been phased out by Mitsubishi Electric. Stock is available from surplus and authorized channels. The FX3U-16MR/ES is the recommended current-production replacement.
Q: Can I use FX3U expansion modules with the FX2N-16MR-001?
A: No. FX2N and FX3U expansion buses are not cross-compatible. Use only FX2N-series expansion modules.
Q: Will my existing FX2N ladder program run on an FX3U?
A: In most cases yes, with minor adjustments. Use GX Works2/3 migration tools and verify special relay/register assignments.
Q: What is the difference between FX2N-16MR and FX2N-16MT?
A: MR = relay output (handles AC/DC loads, slower switching). MT = transistor output (NPN, high-speed, DC loads only).
Q: Do you provide a certificate of conformance?
A: Yes, available upon request for all orders.
