Mitsubishi MR-J3-200AN – 2kW AC Servo Amplifier | MELSERVO-J3 Series
Engineering Background
The MR-J3-200AN is a high-performance AC servo amplifier from Mitsubishi Electric’s MELSERVO-J3 platform — one of the most widely deployed servo families in precision manufacturing, semiconductor equipment, and automated assembly lines across Asia, Europe, and North America. Designed for demanding motion control applications, the J3 series introduced advanced auto-tuning, full closed-loop control, and seamless integration with Mitsubishi’s SSCNET III fiber-optic network.
Product Positioning
The MR-J3-200AN targets procurement engineers and system integrators who require a proven, specification-accurate 2kW servo amplifier for retrofit, OEM build, or spare-parts inventory. As an authorized-grade sourcing partner, Konmask.com supplies this unit with full traceability documentation and pre-shipment verification.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | MR-J3-200AN |
| Manufacturer | Mitsubishi Electric Corporation |
| Series / Platform | MELSERVO-J3 |
| Rated Output Power | 2.0 kW |
| Input Voltage | 3-phase / Single-phase 200–230 V AC, 50/60 Hz |
| Rated Output Current | 11.0 A |
| Control Mode | Position / Speed / Torque (switchable) |
| Encoder Interface | 17-bit absolute / incremental encoder |
| Communication | SSCNET III (fiber optic, 150 Mbps) / Analog / Pulse train |
| Max Speed | 4,500 rpm (motor dependent) |
| Frequency Response | 900 Hz (with auto-tuning) |
| Regenerative Braking | Built-in resistor + external option |
| Protection Class | IP20 |
| Ambient Temperature | 0–55 °C (operating), -20–65 °C (storage) |
| Humidity | 5–90% RH (non-condensing) |
| Dimensions (W×H×D) | Approx. 55 × 170 × 168 mm |
| Weight | Approx. 0.7 kg |
| Country of Origin | Japan |
| Part / Lot Reference | 1910680 |
| Compliance | CE, UL, RoHS |
Proven Application Environments
- CNC Machining Centers — Axis feed and spindle orientation control requiring sub-micron repeatability
- Semiconductor Wafer Handling — Ultra-low vibration positioning with full closed-loop encoder feedback
- Automated Assembly Lines — High-cycle pick-and-place with rapid acceleration/deceleration profiles
- Injection Molding Machines — Precise screw-position and clamp-force control
- Laser Cutting & Engraving Systems — Synchronized multi-axis motion via SSCNET III
- Packaging & Labeling Equipment — Continuous registration control at high throughput
- Retrofit & Spare Parts Inventory — Direct drop-in replacement for existing MR-J3-200A / MR-J3-200AN installations
Engineering Advantages
- One-Touch Auto-Tuning — Adaptive gain tuning eliminates manual parameter iteration; reduces commissioning time by up to 60%
- Advanced Vibration Suppression — Dual-mode notch filter and machine resonance suppression for rigid and flexible load structures
- Full Closed-Loop Ready — Supports external linear/rotary encoder for direct load-side position feedback (eliminates backlash error)
- SSCNET III Fiber Optic Bus — Noise-immune, 150 Mbps synchronous communication; eliminates wiring complexity in multi-axis systems
- Absolute Position System — 17-bit absolute encoder retains position data through power cycles; no homing required on restart
- Compact Form Factor — 55 mm width enables high-density panel mounting in space-constrained control cabinets
- Seamless MR Configurator2 Integration — Full parameter management, oscilloscope, and diagnostics via USB/RS-422
System Architecture & Signal Flow
The MR-J3-200AN operates within Mitsubishi’s Motion Control ecosystem as follows:
- Controller Layer: Mitsubishi Q-series / L-series PLC or Motion Controller (e.g., Q172DCPU, LD77MS) issues position commands via SSCNET III fiber link
- Amplifier Layer: MR-J3-200AN receives commands, executes real-time current/velocity/position loops at 62.5 µs cycle time
- Motor Layer: Paired with HF-SP202 / HF-KP series servo motors (2kW, 200V class); encoder feedback closes the position loop
- Safety Layer: Hardware base-block (EM1/EM2), dynamic brake, and over-current/over-voltage protection circuits
- Diagnostics Layer: MR Configurator2 software provides real-time waveform monitoring, alarm history, and parameter backup
Sourcing & Quality Verification
- Traceability: Each unit ships with lot/date code documentation (Lot Ref: 1910680) and original manufacturer labeling intact
- Pre-Shipment Inspection: Power-on functional test, encoder communication verification, and visual inspection per IPC-A-610 workmanship standards
- Packaging: Anti-static ESD bag + foam-lined carton; meets ISTA 2A transit testing requirements
- Warranty: 12-month Konmask warranty covering manufacturing defects and functional failure under normal operating conditions
- Counterfeit Mitigation: All units sourced through verified supply channels; serial number cross-referenced against manufacturer records where available
Procurement Process
- Inquiry — Submit RFQ via Konmask.com product page or email [email protected] with quantity and delivery requirements
- Quotation — Receive formal quotation with unit price, lead time, and shipping options within 24 business hours
- Order Confirmation — Purchase order accepted; payment via T/T, PayPal, or credit card
- Pre-Shipment Inspection — Functional test completed; inspection report issued upon request
- Shipping — DHL / FedEx / UPS express worldwide; EXW Xiamen or CIF destination available
- After-Sales Support — Technical support via email/WhatsApp; replacement or refund within warranty terms
Technical FAQ
Q: Is the MR-J3-200AN compatible with MR-J3-200A motors?
A: Yes. The MR-J3-200AN is the analog/pulse-train variant of the MR-J3-200A. It is fully compatible with HF-SP202, HF-KP23, and equivalent 2kW J3-series servo motors.
Q: Can this drive operate on single-phase 200V input?
A: Yes, single-phase 200–230V AC input is supported for the 2kW class, though 3-phase input is recommended for continuous high-load operation to avoid derating.
Q: What is the difference between MR-J3-200AN and MR-J3-200B?
A: The MR-J3-200AN uses analog/pulse command interface; the MR-J3-200B uses SSCNET III fiber-optic bus exclusively. Selection depends on your controller’s communication capability.
Q: Does Konmask provide MR Configurator2 setup assistance?
A: Yes. Our technical team can provide parameter templates, wiring diagrams, and remote commissioning guidance for standard applications.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock lead time is typically 2–4 weeks depending on sourcing channel.
