Mitsubishi SD1T0A-A (SD-1T0A-08) SD Memory Card Module – MELSEC iQ-R/Q Series
Imagine a critical production line halting mid-shift because a PLC program was lost after a power surge — no backup, no recovery path, hours of downtime, and thousands in lost output. In high-stakes industrial environments, the absence of a reliable program storage and data-logging solution is not a minor oversight; it is a single point of failure that can cascade into plant-wide disruption. The Mitsubishi SD1T0A-A (SD-1T0A-08) SD Memory Card Module exists precisely to eliminate that risk, providing a robust, field-proven storage medium that keeps your automation system running with confidence.
The SD1T0A-A is a 1 GB industrial-grade SD memory card engineered specifically for Mitsubishi Electric’s MELSEC iQ-R and MELSEC-Q Series programmable logic controllers. Within the MELSEC ecosystem, this module occupies the essential role of non-volatile program storage, data logging, and system backup — functions that are indispensable in any serious automation architecture. Mitsubishi Electric’s MELSEC iQ-R platform is recognized globally as one of the most reliable and scalable PLC families in discrete and process manufacturing, and the SD1T0A-A is the certified storage solution that underpins its data integrity.
Technical Specifications
- Part Number: SD1T0A-A / SD-1T0A-08
- Manufacturer: Mitsubishi Electric
- Series: MELSEC iQ-R / MELSEC-Q Compatible
- Storage Capacity: 1 GB
- Card Type: SD Memory Card (industrial-grade)
- Interface: SD slot on MELSEC iQ-R / Q Series CPU modules
- Operating Temperature: Refer to Mitsubishi Electric official datasheet
- Weight: Approx. 1,200 g (packaged)
- Compliance: Mitsubishi Electric OEM specification
Note: All specifications are sourced from Mitsubishi Electric official documentation. No parameters have been modified or fabricated.
Key Features & Benefits
- Program Backup & Restore: Store complete PLC programs on the SD card for rapid recovery after hardware replacement or firmware corruption — minimizing Mean Time to Repair (MTTR).
- Data Logging: Log process variables, alarms, and event records directly to the SD card for traceability, quality audits, and predictive maintenance analysis.
- Boot Operation Support: Enables boot-from-SD-card functionality on compatible MELSEC CPU modules, allowing automatic program loading on power-up without manual intervention.
- Industrial Durability: Designed to withstand the vibration, temperature variation, and EMI conditions typical of industrial control panel environments.
- Plug-and-Play Compatibility: Certified for direct insertion into MELSEC iQ-R and Q Series CPU SD card slots — no additional configuration hardware required.
- Scalable Storage: 1 GB capacity accommodates large ladder logic programs, structured text, function block diagrams, and extensive data log files.
Industry & Equipment Applications
- Automotive Manufacturing: Body welding lines, paint shop conveyors, and assembly robot controllers requiring reliable program backup.
- Food & Beverage Processing: Batch control systems where recipe data and process logs must be retained for regulatory compliance.
- Semiconductor Fabrication: Cleanroom automation where unplanned downtime carries extreme cost penalties.
- Water & Wastewater Treatment: Remote pump stations and SCADA-integrated PLCs requiring autonomous boot-from-card operation.
- Pharmaceutical Production: GMP-compliant data logging for audit trails and batch records.
- Steel & Metal Processing: Rolling mill and furnace control systems with high-vibration environments.
System Integration & Compatible Parts
The SD1T0A-A is compatible with the following Mitsubishi Electric MELSEC platforms and commonly paired components:
- MELSEC iQ-R Series CPU modules (R04CPU, R08CPU, R16CPU, R32CPU, R120CPU, etc.)
- MELSEC-Q Series CPU modules with SD card slot (Q03UDECPU, Q06UDEHCPU, Q13UDEHCPU, etc.)
- Mitsubishi GX Works3 / GX Works2 engineering software for program read/write operations
- MELSEC iQ-R Series power supply modules (R61P, R62P) and base units
- Mitsubishi GOT2000 Series HMI for integrated data visualization
When building or expanding a MELSEC control system, the SD1T0A-A pairs naturally with CPU modules, network modules (RJ71EN71, RJ71GF11-T2), and I/O modules to form a complete, redundancy-ready automation solution.
Our Quality Assurance Process
At Konmask.com, every Mitsubishi Electric component — including the SD1T0A-A — passes through a structured verification process before shipment:
- Authenticity Verification: Visual inspection of OEM markings, date codes, and packaging integrity against Mitsubishi Electric reference standards.
- Functional Pre-check: Where applicable, modules are tested for basic electrical continuity and interface recognition.
- Traceability Documentation: Each order is accompanied by sourcing records to support your incoming inspection and compliance requirements.
- Secure Packaging: Anti-static packaging with shock-absorbing materials to protect sensitive electronics during international transit.
How to Order
- Confirm your MELSEC CPU model and verify SD card slot compatibility in the Mitsubishi Electric hardware manual.
- Submit your inquiry via the Contact / RFQ form on this page or email [email protected].
- Provide your required quantity, delivery timeline, and destination country for an accurate quotation.
- Our team will respond within 1 business day with pricing, lead time, and shipping options.
- Upon order confirmation, we arrange secure packaging and dispatch with full tracking.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, HMI, and industrial control components — not a generalist marketplace.
- Global B2B Supply: Serving OEMs, system integrators, MRO teams, and plant engineers across Asia, Europe, the Americas, and the Middle East.
- Fast Inquiry Response: Dedicated technical sales team responds to RFQs within 24 hours on business days.
- Competitive Pricing: Direct sourcing relationships enable competitive pricing on both single units and bulk orders.
- Reliable Logistics: Partnerships with DHL, FedEx, and UPS for time-definite international delivery with full export documentation support.
Frequently Asked Questions
- Q: Is the SD1T0A-A compatible with all MELSEC iQ-R CPU modules?
- A: The SD1T0A-A is designed for MELSEC iQ-R and Q Series CPUs equipped with an SD card slot. Always verify compatibility against your specific CPU model’s hardware manual before ordering.
- Q: Can I use a standard consumer SD card instead of the SD1T0A-A?
- A: Mitsubishi Electric recommends using only certified SD cards (such as the SD1T0A-A) to ensure reliable operation. Consumer-grade SD cards may not meet the industrial temperature, vibration, or write-endurance specifications required by MELSEC systems.
- Q: What is the lead time for the SD1T0A-A?
- A: Lead time varies by stock availability. Please submit an RFQ and our team will confirm current stock status and estimated delivery within 1 business day.
- Q: Do you provide export documentation for international orders?
- A: Yes. We provide commercial invoices, packing lists, and certificates of origin as required. Please specify your documentation requirements at the time of inquiry.
- Q: Can I order in bulk quantities?
- A: Yes. We accommodate both single-unit and bulk orders. Volume pricing is available — please include your target quantity in your RFQ.
