NSK EXEA1-0010A01-03 AC Servo Drive | Megatorque Motor System Controller | EXEA1 Series
Engineering Background: The NSK EXEA1 Series represents NSK’s dedicated servo drive platform engineered specifically for the Megatorque Motor direct-drive system — a high-torque, zero-backlash rotary actuator widely deployed in precision indexing, semiconductor handling, and multi-axis robotic applications. The EXEA1-0010A01-03 is the 1.0 kW rated controller variant within this series, providing closed-loop torque, velocity, and position control with full digital parameter management.
Product Positioning: Designed for OEM machine builders and system integrators requiring deterministic motion performance without mechanical transmission losses. This drive pairs exclusively with NSK Megatorque Motor assemblies and communicates via NSK’s proprietary serial interface, making it the authoritative replacement or expansion unit for existing EXEA1-based installations.
Complete Technical Specifications
- Part Number: EXEA1-0010A01-03
- Series: EXEA1 (Megatorque Motor Servo Driver)
- Manufacturer: NSK Ltd. (Nippon Seiko K.K.)
- Rated Output Power: 1.0 kW
- Input Voltage: 3-phase / Single-phase 200–230 V AC, 50/60 Hz
- Control Method: Full digital closed-loop (torque / velocity / position)
- Feedback: Incremental / Absolute encoder interface (motor-integrated)
- Communication Interface: NSK proprietary serial (RS-422 compatible)
- Command Input: Pulse train, analog ±10 V, serial command
- Protection Class: Overcurrent, overvoltage, undervoltage, overtemperature, encoder fault
- Cooling Method: Forced air (internal fan)
- Ambient Operating Temperature: 0–55 °C
- Storage Temperature: −20–65 °C
- Humidity: 20–90% RH (non-condensing)
- Weight: Approx. 560 g
- Compliance: CE, RoHS
Proven Application Environments
- Semiconductor wafer handling and front-end process equipment
- Precision rotary indexing tables and dial plates
- LCD / FPD panel alignment and transfer systems
- Multi-axis robotic end-effector positioning
- Optical inspection and laser processing stages
- Medical imaging gantry and sample positioning systems
Engineering Advantages
- Direct-Drive Architecture: Eliminates gearbox backlash and mechanical wear, achieving sub-arcsecond repeatability when paired with NSK Megatorque Motors.
- Full Digital Parameter Management: All gain tuning, limit settings, and I/O mapping are stored in non-volatile memory — no potentiometer drift over service life.
- Compact Drive Footprint: Panel-mount form factor minimizes control cabinet space while delivering 1.0 kW continuous output.
- Integrated Safety Logic: Hardware-level STO (Safe Torque Off) compatible design supports IEC 62061 / ISO 13849 machine safety architectures.
- Multi-Mode Command Flexibility: Accepts pulse train, analog velocity/torque reference, and serial position commands — compatible with major PLC and motion controller brands.
System Architecture & Signal Flow
The EXEA1-0010A01-03 operates as the central motion node in an NSK Megatorque Motor system. The host controller (PLC / motion card) issues position or velocity commands via pulse train or serial link → the EXEA1 drive executes real-time current loop control at the power stage → encoder feedback from the Megatorque Motor rotor closes the position loop → fault and status signals are returned to the host via dedicated I/O or serial status frames. Regenerative braking energy is dissipated through the internal resistor circuit (external resistor option available for high-duty-cycle applications).
Sourcing & Quality Verification
- Origin: Sourced from authorized NSK distribution channels and verified OEM surplus inventories.
- Inspection: Each unit undergoes visual inspection, label authenticity verification, and functional power-on check prior to shipment.
- Packaging: Anti-static bag + foam-lined export carton; humidity indicator card included.
- Warranty: 90-day operational warranty against manufacturing defects.
- Counterfeit Policy: Konmask.com maintains a zero-tolerance counterfeit policy. All units are traceable to documented supply chain records.
Procurement Process
- Confirm part number EXEA1-0010A01-03 matches your existing drive label or BOM.
- Verify motor model compatibility (Megatorque Motor series — provide motor nameplate data if uncertain).
- Submit order via Konmask.com or contact sales for volume pricing and lead-time confirmation.
- Receive tracking number within 1 business day of payment confirmation.
- Technical commissioning support available via email or video call upon request.
Technical FAQ
Q: Is EXEA1-0010A01-03 compatible with all NSK Megatorque Motors?
A: The EXEA1 series is designed for NSK Megatorque Motors. Compatibility depends on the motor’s rated current and encoder type. Please provide your motor model number for confirmation before ordering.
Q: Can this drive be used as a standalone replacement without re-parameterization?
A: If replacing an identical EXEA1-0010A01-03 unit, parameter backup from the original drive (via NSK EXEA1 setup software) is strongly recommended before swapping. Default factory parameters may not match your machine tuning.
Q: What communication cable is required between the drive and host PLC?
A: NSK specifies a shielded RS-422 cable for the serial interface. Maximum recommended cable length is 10 m. Refer to NSK EXEA1 Series User Manual (Doc. No. RA-TM-0001) for wiring diagrams.
Q: Is an external regenerative resistor required?
A: For standard duty cycles, the internal resistor is sufficient. High-inertia loads or rapid deceleration cycles may require the optional external resistor — consult NSK application guidelines or contact Konmask technical support.
Q: Do you provide the NSK EXEA1 parameter setup software?
A: Yes, setup software and the English user manual can be provided upon request with purchase. Contact support@konmask.com.
