Industrial Automation Solution – OMRON C200HE-CPU42 | C200HE Series
Where This Product Is Used
The OMRON C200HE-CPU42 is a high-performance CPU module from the C200HE PLC series, widely deployed across demanding industrial environments. Typical application scenarios include:
- Discrete Manufacturing Lines – Coordinating multi-axis motion, conveyor sequencing, and robotic cell integration in automotive and electronics assembly plants.
- Process Control Systems – Managing PID loops, analog I/O, and alarm handling in chemical, pharmaceutical, and food & beverage processing facilities.
- Packaging Machinery – Controlling high-speed filling, labeling, and wrapping machines where deterministic scan times are critical.
- Building Automation & HVAC – Supervisory control of HVAC units, pump stations, and energy management systems in commercial buildings.
- Water & Wastewater Treatment – Sequencing pumps, valves, and filtration stages in municipal and industrial water treatment plants.
- Material Handling & Logistics – Coordinating sortation systems, AGVs, and warehouse conveyor networks.
Technical Specifications
- Model: C200HE-CPU42
- Series: OMRON C200HE
- Unit Type: CPU Module
- Program Capacity: 7.2K steps
- Data Memory: 6K words
- I/O Points: Up to 1,184 points (with expansion)
- Communication Ports: Built-in RS-232C peripheral port
- Power Supply: 5 VDC (supplied via backplane)
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 75°C
- Humidity: 10% to 90% RH (non-condensing)
- Weight: Approx. 200 g
- Compliance: CE, UL, cUL
Why Engineers Specify This Model
- Proven Reliability – The C200HE platform has decades of field-proven performance in harsh industrial environments, minimizing unplanned downtime.
- Scalable I/O Architecture – Supports up to 1,184 I/O points via expansion racks, making it suitable for both small cells and large integrated lines.
- Deterministic Scan Performance – Consistent cycle times ensure precise timing for motion control and high-speed process applications.
- Broad Software Ecosystem – Fully compatible with OMRON CX-Programmer, enabling ladder diagram, function block, and structured text programming.
- Legacy System Continuity – Drop-in replacement for existing C200HE installations, protecting prior capital investment without full system redesign.
- Extensive Networking Options – Integrates with OMRON Controller Link, DeviceNet, and SYSMAC NET for plant-wide communication.
Complete System Bill of Materials
For a fully operational C200HE control system, engineers typically specify the following components alongside the C200HE-CPU42:
- Power Supply Unit: C200HW-PA204 / C200HW-PA204S
- Backplane / Rack: C200HW-BC051-V2 (5-slot) or C200HW-BC101-V2 (10-slot)
- Digital Input Module: C200H-ID212 (16-point DC input)
- Digital Output Module: C200H-OD212 (16-point transistor output)
- Analog I/O Module: C200H-AD003 / C200H-DA003
- Communication Module: C200HW-COM06-EV1 (RS-232C / RS-422)
- Programming Cable: CS1W-CN226 or USB-Serial adapter
- Programming Software: OMRON CX-Programmer (CX-One Suite)
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL 508 – Industrial Control Equipment (USA)
- cUL – Canadian Standards (CSA C22.2)
- IEC 61131-2 – Programmable Controllers Hardware Requirements
- RoHS Compliant
Quality Assurance & Sourcing
At Konmask.com, every OMRON C200HE-CPU42 unit is:
- Sourced from authorized distributors and verified supply chains
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Packaged in anti-static ESD-safe materials with protective foam inserts
- Accompanied by a certificate of conformance upon request
- Backed by our 12-month warranty against manufacturing defects
How to Source This Part
- Add the C200HE-CPU42 to your cart and proceed to checkout.
- For bulk orders (>5 units) or project-based procurement, contact our B2B team for volume pricing and lead-time confirmation.
- Need a full system BOM quotation? Email [email protected] with your project specifications.
- Express shipping available to most regions; DDP (Delivered Duty Paid) terms available for international orders.
Application-Specific FAQ
Q: Is the C200HE-CPU42 compatible with C200H expansion I/O modules?
A: Yes. The C200HE-CPU42 is backward compatible with the C200H I/O module family, allowing reuse of existing field wiring and I/O hardware.
Q: What programming software is required?
A: OMRON CX-Programmer (part of the CX-One automation software suite) is the standard tool. Legacy SYSMAC Support Software (SSS) is also compatible for older programs.
Q: Can this CPU communicate with SCADA or HMI systems?
A: Yes. Via the built-in RS-232C port or optional communication modules, the C200HE-CPU42 supports OMRON Host Link (FINS protocol), enabling integration with SCADA platforms such as Wonderware, iFIX, and OMRON NS-series HMIs.
Q: What is the maximum program memory?
A: The C200HE-CPU42 supports up to 7.2K steps of ladder program memory with 6K words of data memory.
Q: Is this unit suitable for safety-critical applications?
A: The C200HE-CPU42 is a standard (non-safety-rated) CPU. For SIL-rated applications, OMRON’s Safety Controller product line (e.g., G9SP series) should be specified instead.
