OMRON CS1W-ADO41-V1 Analog Output Unit – CS1 Series Programmable Controller
In a modern industrial production line, the precise control of analog signals is the lifeline of process automation. When an analog output module fails or is unavailable, variable-frequency drives lose their speed reference, control valves freeze in position, and the entire process loop collapses — resulting in unplanned downtime, product quality failures, and costly emergency shutdowns. The OMRON CS1W-ADO41-V1 Analog Output Unit is the critical bridge between your PLC logic and the physical world of actuators, drives, and process controllers.
The CS1W-ADO41-V1 is a 4-channel analog output module designed specifically for the OMRON CS1 Series Programmable Controller platform — one of the most widely deployed mid-to-large scale PLC architectures in global industrial automation. Within the CS1W I/O expansion lineup, the ADO41-V1 variant delivers enhanced resolution and signal stability, making it the preferred choice for precision process control applications in industries ranging from chemical processing to semiconductor manufacturing. Its proven reliability and seamless integration with CX-Programmer and Sysmac Studio environments have made it a standard specification in automation projects across Asia, Europe, and the Americas.
Technical Specifications
- Model Number: CS1W-ADO41-V1
- Series: CS1W (OMRON CS1 Series PLC)
- Module Type: Analog Output Unit
- Number of Output Channels: 4 channels
- Output Signal Range: 1 to 5 V / 0 to 10 V / 0 to 20 mA / 4 to 20 mA (selectable per channel)
- Resolution: 1/6000 (full scale)
- Conversion Speed: 1 ms/channel (all channels simultaneously)
- Accuracy: ±0.3% of full scale (at 25°C)
- Isolation: Photocoupler isolation between internal circuit and I/O terminals
- Power Consumption: 5 VDC, 160 mA (from PLC backplane)
- External Power Supply: 24 VDC ±10%, 120 mA
- Operating Temperature: 0 to 55°C
- Storage Temperature: -20 to 75°C
- Operating Humidity: 10% to 90% RH (non-condensing)
- Weight: Approx. 780 g
- Standards: CE, UL, cUL
Key Features & Benefits
- 4 Independent Analog Output Channels — Each channel can be individually configured for voltage or current output, providing maximum flexibility for multi-loop control architectures.
- High Resolution 1/6000 — Delivers fine-grained signal control essential for precision process applications such as flow control, pressure regulation, and temperature setpoint management.
- Simultaneous Conversion — All 4 channels convert simultaneously at 1 ms/channel, eliminating phase lag between control loops and improving system response.
- Photocoupler Isolation — Protects the PLC backplane from ground loops and electrical noise originating from field devices, enhancing system reliability in electrically noisy environments.
- Offset/Gain Calibration — Supports software-based offset and gain adjustment via CX-Programmer, allowing field calibration without hardware modification.
- Hold/Clear Output on Error — Configurable output behavior on CPU error: hold last value or clear to zero, ensuring safe process states during fault conditions.
- Compact DIN-Rail Form Factor — Mounts directly onto the CS1 backplane without additional wiring adapters, minimizing panel space and installation time.
Industry & Equipment Applications
- Chemical & Petrochemical Plants — Analog setpoint output to control valves, flow meters, and pressure regulators in continuous process loops.
- Food & Beverage Manufacturing — Speed reference signals to VFDs on conveyor systems, mixers, and filling machines requiring precise throughput control.
- Pharmaceutical Production — Temperature and pressure setpoint control in GMP-compliant batch processing systems.
- Semiconductor & Electronics Manufacturing — High-precision analog output for cleanroom environmental control systems (HVAC, gas flow).
- Water Treatment & Utilities — Pump speed control and dosing pump regulation in municipal and industrial water treatment facilities.
- Automotive Assembly — Torque and speed control signals for servo amplifiers and robotic welding systems integrated with CS1 PLC platforms.
- Building Automation (HVAC) — Chiller setpoint, AHU damper control, and variable air volume (VAV) system management.
System Integration & Compatible Parts
The CS1W-ADO41-V1 is designed for seamless integration within the OMRON CS1 Series ecosystem. Compatible and commonly paired components include:
- CPU Units: CS1G-CPU42H, CS1G-CPU43H, CS1H-CPU63H, CS1H-CPU64H, CS1H-CPU65H, CS1H-CPU66H, CS1H-CPU67H
- Power Supply Units: CS1W-PA204, CS1W-PA204S, CS1W-PD025
- Backplane Units: CS1W-BC023, CS1W-BC033, CS1W-BC053, CS1W-BC083, CS1W-BC103
- Analog Input Counterparts: CS1W-AD041-V1, CS1W-AD081-V1 (for closed-loop PID configurations)
- Programming Software: CX-Programmer V9.x and above; Sysmac Studio (via CJ/CS gateway)
- Terminal Block Connectors: XW2B series (OMRON) for field wiring termination
Our Quality Assurance Process
At Konmask.com, every OMRON CS1W-ADO41-V1 unit undergoes a rigorous multi-stage inspection before shipment:
- Authenticity Verification — Serial number and date code cross-referenced against OMRON’s authorized distribution records to confirm genuine origin.
- Visual Inspection — Full examination of housing, terminal blocks, connector pins, and label integrity for any signs of damage, remanufacturing, or counterfeit indicators.
- Functional Power-On Test — Module is powered and communication with a CS1 CPU is verified; output channel response is confirmed across all 4 channels.
- ESD-Safe Packaging — Units are packed in anti-static bags with foam cushioning and moisture barrier packaging for safe international transit.
- Documentation Included — Datasheet, test report, and certificate of conformity provided upon request.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com with your required quantity and delivery timeline.
- Our technical team will confirm availability, lead time, and provide a formal quotation within 24 business hours.
- Upon order confirmation, we issue a Proforma Invoice (PI) and arrange payment via T/T, L/C, or other agreed terms.
- Units are shipped via DHL, FedEx, or sea freight with full tracking and export documentation (commercial invoice, packing list, COO).
- After-sales technical support is available for integration assistance and troubleshooting.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC modules, DCS cards, servo drives, and HMI panels from leading global brands.
- ✅ Genuine Parts Guaranteed — We source directly from authorized channels and provide traceability documentation.
- ✅ Global B2B Export Experience — Serving MRO buyers, system integrators, and OEM manufacturers across 50+ countries.
- ✅ Fast Response & Competitive Pricing — Quotation within 24 hours; volume discounts available for project orders.
- ✅ Technical Support Included — Our engineers can assist with module configuration, wiring diagrams, and CX-Programmer setup guidance.
Frequently Asked Questions
- Q: Is the CS1W-ADO41-V1 compatible with the CS1G and CS1H CPU series?
- A: Yes. The CS1W-ADO41-V1 is compatible with all CS1G and CS1H CPU units when mounted on a CS1W series backplane. It occupies one I/O slot and is recognized automatically by CX-Programmer during I/O table generation.
- Q: What is the difference between CS1W-ADO41 and CS1W-ADO41-V1?
- A: The V1 revision incorporates improved EMC performance and enhanced output stability compared to the original ADO41. For new installations, the V1 version is strongly recommended. Both versions share the same wiring and software configuration.
- Q: Can I mix voltage and current output on different channels?
- A: Yes. Each of the 4 output channels can be independently configured for voltage (1–5 V or 0–10 V) or current (0–20 mA or 4–20 mA) output via DIP switch settings and CX-Programmer software configuration.
- Q: What happens to the analog outputs if the PLC CPU goes into error mode?
- A: The output behavior on CPU error is configurable. You can set each channel to either hold the last output value or clear to 0 (or 4 mA for 4–20 mA range), depending on your process safety requirements.
- Q: Do you provide a warranty for this module?
- A: Yes. Konmask.com provides a 90-day warranty covering manufacturing defects and functional failures under normal operating conditions. Extended warranty options are available for project orders.
