OMRON H8PR-8 – Programmable 8-Point Output Relay | H8PR Series
Engineering Background
The OMRON H8PR-8 is a high-density programmable output relay module engineered for precision timing and sequential control in industrial automation environments. Developed under OMRON’s H8PR Series platform, this module delivers deterministic output switching across 8 independent relay points, making it a trusted component in machine builders’ control cabinets worldwide.
Product Positioning
Designed for procurement engineers and system integrators who require a compact, DIN-rail-mountable relay solution with programmable timing logic, the H8PR-8 eliminates the need for external timer modules by consolidating multi-point output control into a single, standardized form factor. It is the preferred choice for OEM panel builders, process automation upgrades, and legacy PLC I/O expansion projects.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Model | H8PR-8 |
| Manufacturer | OMRON Corporation |
| Series | H8PR |
| Output Points | 8 programmable relay output points |
| Output Type | Relay contact output |
| Control Mode | Programmable sequential / timer output |
| Mounting | DIN rail (35 mm) |
| Country of Origin | Japan |
| Weight | Approx. 200 g |
| Compliance | CE, UL (refer to OMRON datasheet for full certifications) |
Proven Application Environments
- Machine Tool Control: Sequential relay switching for spindle, coolant, and axis interlocks
- Conveyor & Packaging Lines: Timed output sequencing for belt drives and actuator control
- Building Automation: HVAC staging, lighting control, and alarm relay panels
- Process Industry: Pump sequencing, valve control, and batch process timing
- PLC I/O Expansion: Supplementary relay output for Mitsubishi, Siemens, Allen-Bradley, and OMRON PLCs
Engineering Advantages
- 8 independent programmable output points in a compact single-module footprint
- Eliminates external discrete timer wiring — reduces panel complexity and commissioning time
- DIN-rail mounting ensures fast installation and standardized panel layout
- OMRON’s proven relay contact technology delivers high switching reliability and long mechanical life
- Compatible with standard 24 VDC control circuits common in modern PLC architectures
- Simplified programming interface reduces engineering hours during system integration
System Architecture & Signal Flow
The H8PR-8 interfaces directly with PLC digital output cards or standalone control circuits. Each of the 8 relay output points can be individually programmed for on-delay, off-delay, or sequential timing patterns. The module accepts standard control voltage inputs and provides isolated relay contacts for load switching, ensuring clean signal separation between control and power circuits. This architecture supports both normally-open (NO) and normally-closed (NC) wiring configurations.
Sourcing & Quality Verification
- All OMRON H8PR-8 units sourced through authorized industrial distribution channels
- Each unit inspected for original OMRON packaging, holographic labels, and date codes prior to shipment
- Traceability documentation available upon request for quality-critical procurement
- Konmask.com maintains a zero-tolerance policy on counterfeit components — all stock is verified against OMRON’s genuine product standards
Procurement Process
- Submit your RFQ or place order directly via Konmask.com product page
- Receive order confirmation with lead time and shipping details within 1 business day
- Inspection report and packing list provided with every shipment
- DHL / FedEx / SF Express international shipping available — contact us for freight quotes on bulk orders
- After-sales technical support available via email and WhatsApp
Technical FAQ
Q: Is the H8PR-8 compatible with OMRON CJ/CS series PLCs?
A: Yes. The H8PR-8 relay outputs are compatible with standard 24 VDC I/O circuits used in OMRON CJ2, CS1, and CP series PLCs, as well as third-party PLC platforms.
Q: Can the output sequence be reprogrammed in the field?
A: Yes. The H8PR-8 supports field programming via its front-panel interface without requiring specialized software tools.
Q: What is the maximum load per relay output point?
A: Please refer to the official OMRON H8PR-8 datasheet for rated contact capacity. Contact Konmask.com for the latest technical documentation.
Q: Do you offer volume pricing for OEM or system integrator orders?
A: Yes. Contact our sales team at support@konmask.com for volume pricing, blanket order arrangements, and consignment stock options.
