OMRON R7D-BP02HH-Z 200W AC Servo Drive – R7D Series
When a servo drive fails on the production line, everything stops. Robotic arms freeze mid-cycle, CNC spindles lose position feedback, and conveyor systems halt without warning. Every minute of unplanned downtime translates directly into lost output and costly emergency maintenance. The OMRON R7D-BP02HH-Z is the precision motion control component that keeps these critical systems running — a purpose-built AC servo drive engineered for demanding industrial environments where reliability is non-negotiable.
Within OMRON’s R7D Series, the R7D-BP02HH-Z occupies the 200W single-phase segment — the workhorse rating for compact, high-cycle automation tasks. OMRON’s R7D Series is globally recognized as one of the most widely deployed servo drive families in factory automation, with installations spanning automotive assembly, semiconductor handling, food processing, and precision packaging across Asia, Europe, and the Americas.
Technical Specifications
- Model: R7D-BP02HH-Z
- Brand: OMRON
- Series: R7D Series (SMARTSTEP 2)
- Rated Output Power: 200W
- Power Supply: Single-Phase 100–115 VAC / 200–230 VAC, 50/60 Hz
- Control Method: IGBT PWM Sinusoidal Drive
- Encoder Interface: Incremental Encoder (2,000 P/R)
- Control Modes: Position, Speed, Torque
- Communication: RS-232C / RS-485 (CX-Drive compatible)
- Protective Functions: Overcurrent, Overvoltage, Undervoltage, Overload, Encoder Error, Regeneration Error
- Ambient Temperature: 0–55°C (Operating), -20–65°C (Storage)
- Humidity: 90% RH max (non-condensing)
- Weight: Approx. 0.8 kg
- Compliance: CE, UL, cUL
Key Features & Benefits
- Compact 200W Form Factor: Optimized for space-constrained control panels without sacrificing performance.
- High-Resolution Position Control: 2,000 P/R incremental encoder support enables precise positioning for pick-and-place and indexing applications.
- Auto-Tuning: Built-in real-time auto-tuning reduces commissioning time and adapts to load changes dynamically.
- Vibration Suppression: Adaptive notch filter minimizes mechanical resonance for smooth, stable motion.
- Comprehensive Protection: Multi-layer fault detection protects both the drive and connected motor from damage.
- CX-Drive Software Compatible: Full parameter management, monitoring, and diagnostics via OMRON’s CX-Drive PC tool.
- Global Certifications: CE and UL/cUL listed for worldwide deployment compliance.
Industry & Equipment Applications
- Semiconductor & Electronics Manufacturing: Wafer handling, PCB drilling, SMT pick-and-place machines
- Food & Beverage Packaging: Filling machines, labeling systems, portioning conveyors
- Automotive Assembly: Welding positioners, torque-controlled fastening stations
- Textile Machinery: Yarn tension control, winding and unwinding systems
- Medical Equipment: Diagnostic imaging positioning, laboratory automation
- General Factory Automation: Rotary indexing tables, gantry systems, multi-axis robots
System Integration & Compatible Parts
- Compatible Servo Motors: OMRON R88M-GP20030H-Z, R88M-GP20030T-Z (200W R88M Series)
- Recommended PLC: OMRON CJ2M, CP1H, NX1P2 Series
- Regeneration Resistor: R88A-RR Series (external, application-dependent)
- Cables: R88A-CA Series encoder cables, R88A-CA Series power cables
- Programming Tool: CX-Drive Ver. 2.0 or later
- I/O Terminal Block: Compatible with standard 50-pin connector wiring harnesses
Our Quality Assurance Process
- Source Verification: All units are sourced from authorized distributors or directly from OMRON-certified supply chains.
- Incoming Inspection: Each unit undergoes visual inspection, label verification, and serial number cross-check upon receipt.
- Functional Testing: Where applicable, drives are bench-tested for power-on response and fault-code readiness before shipment.
- Secure Packaging: Anti-static packaging with foam cushioning and moisture-barrier bags for international transit.
- Documentation: Original datasheet, test report, and certificate of conformity available upon request.
How to Order
- Step 1: Submit an inquiry via the Contact Us form or email [email protected] with your required quantity and delivery timeline.
- Step 2: Receive a formal quotation within 24 business hours including unit price, lead time, and shipping options.
- Step 3: Confirm the order with a purchase order (PO) or advance payment per agreed terms.
- Step 4: Shipment dispatched with tracking number, commercial invoice, and packing list.
- Step 5: After-sales support available for installation guidance and warranty claims.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, servo, and motion control components — not a general marketplace.
- ✅ Global B2B Supply: Serving OEMs, system integrators, and MRO buyers in 30+ countries with reliable cross-border logistics.
- ✅ Technical Expertise: Our team includes qualified automation engineers who can assist with compatibility and application questions.
- ✅ Competitive Lead Times: In-stock items ship within 3–5 business days; sourced items within 2–4 weeks.
- ✅ Transparent Documentation: Full traceability documentation provided for every order.
- ✅ Responsive Support: Dedicated account managers for B2B clients with ongoing procurement needs.
Frequently Asked Questions
Q: Is the OMRON R7D-BP02HH-Z compatible with 220V single-phase power supply?
A: Yes. The R7D-BP02HH-Z supports single-phase 200–230 VAC input, making it compatible with standard 220V industrial power supplies in most regions.
Q: Which servo motor should I pair with the R7D-BP02HH-Z?
A: This drive is designed for use with OMRON’s 200W R88M Series servo motors, such as the R88M-GP20030H-Z. Always verify the motor-drive combination using OMRON’s official selection guide.
Q: Can I use CX-Drive software to configure this drive?
A: Yes. The R7D-BP02HH-Z is fully compatible with OMRON CX-Drive software via RS-232C or RS-485 connection for parameter setting, monitoring, and diagnostics.
Q: What does the “-Z” suffix in R7D-BP02HH-Z indicate?
A: The “-Z” suffix typically denotes a specific regional or specification variant within OMRON’s product naming convention. Please contact us to confirm the exact specification for your application.
Q: Do you provide a warranty for this product?
A: Yes. We offer a standard warranty period on all supplied units. Warranty terms are confirmed at the time of quotation based on product condition (new, refurbished, or surplus).
Q: Can you supply multiple units for a production line upgrade?
A: Absolutely. We handle both single-unit MRO orders and bulk procurement for OEM and system integrator projects. Contact us with your BOM for a consolidated quote.
