Industrial Automation & Machine Control Solution – OMRON TPM1A-20CDT-D-V1 | CPM1A Series
The OMRON TPM1A-20CDT-D-V1 is a compact, high-reliability programmable logic controller from the renowned CPM1A Series. Designed for demanding industrial environments, this 20 I/O DC transistor output PLC module delivers precise, real-time control for a wide range of automation applications. Sourced and verified by Konmask.com — your trusted global supplier of industrial automation components.
Where This Product Is Used
The TPM1A-20CDT-D-V1 is specified by engineers across multiple industries for its compact footprint and robust performance:
- Packaging Machinery: Precise sequencing control for filling, sealing, and labeling lines
- Conveyor & Material Handling Systems: Multi-axis coordination and speed regulation
- Injection Molding Machines: Cycle timing, temperature interlocking, and safety logic
- Food & Beverage Processing: Hygienic-environment compatible control with fast scan cycles
- Textile & Printing Equipment: High-speed I/O response for pattern synchronization
- HVAC & Building Automation: Compact panel integration for environmental control loops
- Water Treatment & Pump Stations: Reliable standalone control in remote installations
- Assembly Line Automation: Coordinated multi-station sequencing and fault detection
Technical Specifications
| Model | TPM1A-20CDT-D-V1 |
| Brand | OMRON |
| Series | CPM1A |
| I/O Points | 20 (12 Inputs / 8 Outputs) |
| Output Type | Transistor (NPN / Sink), DC |
| Power Supply | DC 24V |
| Program Capacity | 2,048 Instructions |
| Scan Time | 0.64 ms / 1K Steps |
| Communication | Peripheral Port (RS-232C compatible) |
| Operating Temperature | 0°C to 55°C |
| Weight | Approx. 2,500 g (packaged) |
| Compliance | CE, UL, cUL |
Why Engineers Specify This Model
- Compact DIN-Rail Design: Saves panel space without sacrificing I/O capacity — ideal for space-constrained control cabinets
- Transistor DC Output: High-speed switching suitable for servo drives, stepper motors, and high-frequency loads
- Proven CPM1A Architecture: Millions of units deployed globally; extensive ladder logic library and CX-Programmer support
- Robust EMI Immunity: Designed to operate reliably in electrically noisy factory environments
- Easy Expansion: Supports CPM1A expansion I/O units for scalable system growth
- Long Product Lifecycle: OMRON’s commitment to long-term parts availability reduces obsolescence risk
Complete System Bill of Materials
Build a complete CPM1A-based control system with these compatible components:
- Expansion I/O Units: CPM1A-8ED, CPM1A-8ET, CPM1A-20EDT
- Analog I/O Units: CPM1A-MAD01, CPM1A-MAD11
- Communication Adapters: CPM1-CIF01 (RS-232C), CPM1-CIF11 (RS-422)
- Programming Software: OMRON CX-Programmer (CX-One Suite)
- Programming Cable: CS1W-CN226 / CS1W-CN626
- Power Supply: S8VS-06024 (24VDC, 2.5A)
- DIN Rail Mounting: PFP-50N / PFP-100N
Contact Konmask.com for complete BOM sourcing and volume pricing.
Compliance & Industry Standards
- ✅ CE Marking — European conformity for EMC and Low Voltage Directives
- ✅ UL / cUL Listed — North American safety certification
- ✅ RoHS Compliant — Restriction of Hazardous Substances
- ✅ IEC 61131-2 — Programmable Controllers standard compliance
- ✅ IP20 Enclosure Rating — Protected against solid objects >12mm
Quality Assurance & Sourcing
At Konmask.com, every OMRON component undergoes a rigorous verification process before shipment:
- Origin Verification: Cross-referenced against OMRON’s authorized distributor network and factory batch records
- Physical Inspection: Label authenticity, housing integrity, connector condition, and firmware version check
- Functional Testing: Power-on diagnostics and I/O response validation where applicable
- Documentation Package: Certificate of conformity, test report, and traceability records provided on request
We maintain long-term supplier relationships with authorized OMRON channels across Asia, Europe, and North America — ensuring genuine parts with full traceability.
How to Source This Part
- Add to Cart — Proceed directly for standard orders
- Request a Quote — Email [email protected] for volume pricing, lead time confirmation, or custom configurations
- Provide Your BOM — Send your full bill of materials for consolidated sourcing and freight optimization
- Expedited Sourcing — Urgent requirements? Call or WhatsApp +0086 19859288691 for priority handling
Application-Specific FAQ
Q: Is the TPM1A-20CDT-D-V1 compatible with CX-Programmer?
A: Yes. It is fully supported by OMRON CX-Programmer within the CX-One software suite. Use the CPM1A device type during project setup.
Q: Can this PLC control servo drives directly?
A: The transistor (NPN) outputs support high-speed pulse output, making it suitable for basic open-loop stepper/servo positioning. For closed-loop servo control, pair with an OMRON servo driver and motion control unit.
Q: What is the maximum number of expansion units?
A: The CPM1A supports up to 3 expansion I/O units, extending the system to a maximum of 100 I/O points.
Q: Do you supply the programming cable?
A: Yes. We can supply the CS1W-CN226 or CS1W-CN626 programming cable. Please specify when ordering.
Q: Is this a new or refurbished unit?
A: We supply new, surplus-new, and factory-refurbished units depending on availability. Condition is clearly stated on each order confirmation. All units are tested and verified.
Q: Can you ship to my country?
A: Konmask.com ships globally via DHL, FedEx, UPS, and sea freight. Export documentation and customs support are available for all major markets.
