Industrial Motion Control Solution – Parker HCS02.1E-W0054-A-03-NNNN | HCS02 Ministep Drive Series
Where This Product Is Used
The Parker HCS02.1E-W0054-A-03-NNNN Ministep Drive is engineered for demanding industrial motion control environments where precision, reliability, and compact footprint are non-negotiable. Typical deployment scenarios include:
- CNC Machining Centers – Axis feed drives requiring tight velocity loop bandwidth and smooth torque delivery at high spindle speeds.
- Packaging Machinery – High-cycle pick-and-place, form-fill-seal, and labeling lines where deterministic positioning repeatability is critical.
- Printing & Converting Equipment – Web tension control and register correction loops demanding sub-millisecond response.
- Semiconductor & Electronics Assembly – Gantry and wafer-handling stages requiring micron-level positioning accuracy.
- Robotics & Collaborative Arms – Joint actuator drives in multi-axis articulated robots where compact drive footprint saves cabinet space.
- Material Handling & Conveyor Systems – Synchronised multi-axis transport lines controlled via SERCOS or PROFIBUS fieldbus.
Technical Specifications
| Attribute | Value |
|---|---|
| Manufacturer Part Number | HCS02.1E-W0054-A-03-NNNN |
| Cross-Reference SKUs | PDS15-2 / 808-620160-2 / 881-620680-1 / 808-620680-1 / 881-620160 |
| Series | HCS02 (Ministep Drive) |
| Manufacturer | Parker Hannifin – Electromechanical & Drives Division |
| Drive Type | AC Servo Drive (Transistor PWM) |
| Continuous Output Current | 5.4 A (rms) |
| Peak Output Current | 10.8 A (rms) |
| Supply Voltage | 3 × 200–480 V AC, 50/60 Hz |
| DC Bus Voltage | 565 V DC (nominal) |
| Feedback Interface | Resolver / Encoder (configurable) |
| Communication | SERCOS II / Analog ±10 V / Step-Direction |
| Protection Class | IP20 |
| Cooling | Forced air (internal fan) |
| Weight | 2.6 kg |
| Country of Origin | Germany |
Why Engineers Specify This Model
- Compact Power Density – The HCS02 series delivers 5.4 A continuous in a narrow bookshelf housing, reducing panel footprint by up to 30% versus previous-generation drives.
- Multi-Protocol Flexibility – Native SERCOS II support alongside analog and step/direction interfaces allows integration into both legacy and modern motion controllers without gateway hardware.
- Adaptive Current Control – Parker’s proprietary current-loop algorithm minimises torque ripple, critical for surface-finish quality in grinding and milling applications.
- Safe Torque Off (STO) – Integrated SIL 2 / PLd safety function eliminates external safety contactors, simplifying CE/UL machine safety compliance.
- Plug-and-Play Motor Database – Pre-loaded motor parameter sets for Parker MPP, MPJ, and MPS servo motors accelerate commissioning from hours to minutes.
Complete System Bill of Materials
For a fully operational servo axis using this drive, engineers typically specify:
- Parker HCS02.1E-W0054-A-03-NNNN – Servo Drive (this unit)
- Parker MPP-Series or MPJ-Series AC Servo Motor (matched to load inertia)
- Parker HNF01 or HNL01 – Line Filter / Choke (EMC compliance)
- Parker HAS02 – Braking Resistor Module (for high-inertia deceleration)
- Parker IndraControl or compatible SERCOS master controller
- Shielded servo motor cable (Parker MKDS or equivalent, ≤ 25 m)
- Resolver or encoder feedback cable (Parker MKDS-R or equivalent)
- 24 V DC control power supply (min. 3 A)
Compliance & Industry Standards
- CE Marking – Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C – Power Conversion Equipment
- EN 61800-5-1 – Adjustable Speed Electrical Power Drive Systems (Safety)
- EN 61800-3 – EMC Requirements for Drive Systems
- IEC 62061 / ISO 13849-1 – STO function rated SIL 2 / PLd
- RoHS 2011/65/EU compliant
Quality Assurance & Sourcing
Every unit offered through Konmask.com undergoes a structured verification process:
- Visual Inspection – Housing, connector pins, and label integrity checked against OEM specifications.
- Functional Power-On Test – Drive initialisation, fault-code readout, and parameter upload verified before dispatch.
- Traceability – Serial number and date code recorded; full chain-of-custody documentation available on request.
- Packaging – Anti-static bag + foam-lined export carton; shock-watch indicator included for international shipments.
We source from authorised distributors, OEM surplus channels, and verified industrial resellers. Counterfeit-risk screening is applied to all Parker Hannifin products per our internal sourcing policy.
How to Source This Part
Stock availability for the HCS02.1E-W0054-A-03-NNNN is updated in real time. To place an order or request a formal quotation:
- Online: Add to cart directly on this page – lead time displayed at checkout.
- Email RFQ: [email protected] – include quantity, required delivery date, and ship-to country.
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Bulk / OEM Orders: Volume pricing available for 3+ units; contact us for a tiered quote.
Application-Specific FAQ
Q: Can the HCS02.1E-W0054-A-03-NNNN replace an older PDS15-2 drive without hardware changes?
A: In most cases yes – the HCS02 series is the direct successor to the PDS15 platform. Connector pinouts and motor parameter structures are compatible; firmware migration via DriveTop software is recommended.
Q: What motor feedback types are supported?
A: The -A-03 firmware variant supports resolver and incremental encoder (TTL/HTL). Hiperface and EnDat 2.1 require the -A-04 or later firmware option.
Q: Is the STO function certified for use in collaborative robot (cobot) applications?
A: Yes. The integrated STO meets IEC 62061 SIL 2 and ISO 13849-1 PLd, which satisfies the safety requirements of ISO/TS 15066 for cobot force-limiting applications.
Q: What is the maximum cable length between drive and motor?
A: Parker specifies a maximum of 25 m for standard shielded cable. Lengths up to 50 m are achievable with an output choke (HNL01) and reduced PWM frequency.
Q: Do you provide a warranty?
A: All units carry a 90-day functional warranty from date of shipment. Extended warranty and repair services are available – contact us for details.
