Precision Motion Control Solution – Parker HID2CS/S4 & HID5CS/S4 | HID Series AC Servo Drive
Where This Product Is Used
The Parker HID2CS/S4 and HID5CS/S4 are compact, high-performance AC servo drives from Parker Hannifin’s HID Series, engineered for demanding motion control applications across global industrial sectors. These drives are deployed wherever precise speed, torque, and position control are non-negotiable:
- CNC Machining Centers & Milling Machines – Axis feed drives requiring sub-millisecond response and micron-level positioning accuracy.
- Packaging & Form-Fill-Seal Machines – High-cycle servo axes controlling film feed, cutting, and sealing with repeatable precision.
- Robotic Arms & Gantry Systems – Multi-axis coordinated motion in automotive assembly, electronics pick-and-place, and palletizing.
- Printing & Converting Equipment – Register control and tension management in web-fed offset and flexographic presses.
- Semiconductor & Flat Panel Display Manufacturing – Ultra-clean, vibration-free motion for wafer handling and stage positioning.
- Textile & Winding Machinery – Tension-controlled winding with dynamic torque response across varying load profiles.
- Medical & Laboratory Automation – Quiet, precise actuation in diagnostic equipment, dispensing systems, and surgical robots.
When a servo drive fails on a production line, the entire cell stops. Downtime costs in automotive or semiconductor plants can exceed $10,000 per hour. The Parker HID Series was designed to minimize that risk — with robust hardware, comprehensive protection features, and a global spare-parts ecosystem that keeps critical machines running.
Technical Specifications
Note: Specifications below are based on Parker HID Series published data. Always verify against the official Parker datasheet for your specific application.
- Model Numbers: HID2CS/S4 (2A continuous) / HID5CS/S4 (5A continuous)
- Series: Parker HID Series Compact AC Servo Drive
- Supply Voltage: Single-phase / Three-phase 200–240 V AC, 50/60 Hz
- Output Current: HID2CS/S4 – 2 A continuous, 6 A peak; HID5CS/S4 – 5 A continuous, 15 A peak
- Control Modes: Position, Velocity, Torque (selectable)
- Feedback Interface: Incremental encoder, resolver (model-dependent)
- Communication: RS-232/RS-485 serial; optional fieldbus (CANopen / PROFIBUS)
- Protection Class: IP20 (panel-mount)
- Operating Temperature: 0 °C to +45 °C (ambient)
- Storage Temperature: -25 °C to +70 °C
- Weight: Approx. 840 g
- Certifications: CE, UL (refer to Parker documentation for current listing)
Why Engineers Specify This Model
- Compact DIN-Rail / Panel Footprint – The HID Series’ slim profile saves valuable cabinet space in multi-axis machine designs.
- Dual-Model Scalability – HID2CS/S4 and HID5CS/S4 share identical mechanical and electrical interfaces, allowing engineers to scale torque output without redesigning the control cabinet.
- Parker Motion Suite Compatibility – Seamless integration with Parker’s ACR, Aries, and Compax3 motion controllers via standardized command sets.
- Comprehensive On-Board Protection – Over-current, over-voltage, under-voltage, over-temperature, and short-circuit protection reduce field failures and simplify CE compliance.
- Auto-Tuning Algorithm – Reduces commissioning time from hours to minutes, critical for OEMs building high-volume machine lines.
- Long Product Lifecycle – Parker’s industrial product lines are supported for 10+ years, protecting OEM machine designs from premature obsolescence.
Complete System Bill of Materials
For a fully operational servo axis using the Parker HID2CS/S4 or HID5CS/S4, engineers typically specify the following complementary components:
- Parker Compatible Servo Motor (e.g., Parker NeoMetric / J Series)
- Parker ACR or Aries Motion Controller
- Encoder feedback cable (shielded, application-length)
- 24 V DC control power supply
- EMC line filter (Parker or equivalent, per CE installation requirements)
- Dynamic braking resistor (for high-inertia or vertical-axis applications)
- DIN rail, terminal blocks, and cabinet wiring accessories
Contact support@konmask.com for a complete BOM quotation for your machine design.
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) and EMC Directive compliant
- UL Listed – Suitable for North American industrial installations
- RoHS Compliant – Meets EU Restriction of Hazardous Substances requirements
- IEC 61800-5-1 – Adjustable speed electrical power drive systems safety standard
Quality Assurance & Sourcing
At Konmask.com, every Parker HID Series drive we supply undergoes a structured quality process before shipment:
- Authenticity Verification – Part number, date code, and label inspection against Parker’s official documentation.
- Visual & Mechanical Inspection – PCB, connector, and housing integrity check for signs of repair, counterfeit, or damage.
- Functional Test (where applicable) – Power-on and communication response testing on select units.
- Traceable Packaging – Each unit ships with inspection records and original or equivalent protective packaging.
We source from authorized distributors, OEM surplus, and verified industrial supply channels. All units are sold with a documented sourcing trail.
How to Source This Part
- Submit your inquiry via the “Get a Quote” button or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will confirm availability, lead time, and pricing within 24 business hours.
- Upon order confirmation, we arrange quality inspection, export documentation, and international shipping (DHL / FedEx / sea freight).
- Track your shipment with real-time updates until delivery.
Application-Specific FAQ
Q: Can the HID2CS/S4 and HID5CS/S4 be used interchangeably in the same machine design?
A: Yes. Both models share the same mechanical footprint and connector pinout. The only difference is the continuous and peak current rating, making it straightforward to upgrade from the 2A to the 5A variant for higher-torque axes without cabinet redesign.
Q: What servo motors are compatible with the Parker HID Series drives?
A: The HID Series is optimized for Parker’s own NeoMetric and J Series servo motors. Compatibility with third-party motors depends on the feedback type and motor parameters — consult Parker’s sizing software or contact our technical team for confirmation.
Q: Is the HID Series suitable for vertical-axis (gravity-load) applications?
A: Yes, with the addition of a dynamic braking resistor and appropriate holding brake on the motor. The drive’s torque control mode and fast current loop response make it well-suited for vertical load management.
Q: What fieldbus options are available?
A: The base HID Series supports RS-232/RS-485. Optional CANopen and PROFIBUS modules are available depending on the specific variant. Confirm the exact option code when ordering.
Q: Do you provide export documentation for customs clearance?
A: Yes. We provide commercial invoice, packing list, and certificate of origin. Additional documentation (e.g., Form E for ASEAN, EUR.1 for EU) can be arranged upon request.
