Parker PA08T-133 – 13.3″ Industrial HMI Touch Screen Panel | PA08T Series
Engineering Background: The Parker PA08T-133 is a high-performance human-machine interface (HMI) panel engineered by Parker Hannifin for demanding industrial automation environments. Designed to integrate seamlessly with PLCs, DCS platforms, and SCADA systems, this unit delivers reliable operator control and real-time process visualization across a wide range of industrial sectors.
Product Positioning: As part of Parker’s PA08T Series, the PA08T-133 targets applications requiring a large-format, high-brightness display with robust communication flexibility. It is the preferred choice for procurement engineers specifying operator panels in process control, machine automation, and energy management systems.
Complete Technical Specifications
- Model / SKU: PA08T-133
- Brand: Parker Hannifin
- Series: PA08T
- Display Size: 13.3 inch (diagonal)
- Display Type: TFT LCD, Wide-angle viewing
- Resolution: 1280 × 800 (WXGA)
- Brightness: ≥ 400 cd/m²
- Touch Technology: Resistive / Capacitive (model-dependent)
- Processor: ARM Cortex-A series, high-speed embedded CPU
- Operating System: Embedded Linux / Windows CE (variant-dependent)
- Memory: 512 MB RAM / 4 GB Flash (standard configuration)
- Communication Ports: RS-232, RS-485, Ethernet (RJ45 × 2), USB Host/Device
- Supported Protocols: Modbus RTU/TCP, EtherNet/IP, PROFIBUS DP, CANopen, BACnet (via optional modules)
- Power Supply: 24 VDC (±15%), typical current 1.5 A
- Operating Temperature: 0°C to +50°C
- Storage Temperature: -20°C to +60°C
- Humidity: 10% to 90% RH, non-condensing
- Protection Rating: IP65 (front panel), IP20 (rear)
- Mounting: Panel cut-out, flush mount
- Dimensions: Approx. 360 × 230 × 55 mm (W × H × D)
- Weight: Approx. 4.8 kg
- Certifications: CE, UL (region-dependent)
Proven Application Environments
- Process manufacturing: chemical, pharmaceutical, food & beverage
- Machine tool control and CNC operator stations
- Water treatment and utilities SCADA visualization
- Oil & gas upstream/downstream control rooms
- Building automation and energy management systems
- Packaging and material handling lines
- Power generation and substation monitoring
Engineering Advantages
- Large 13.3″ display — maximizes operator situational awareness with full-page process graphics and alarm dashboards
- Multi-protocol native support — eliminates gateway hardware in mixed-vendor PLC environments
- IP65 front panel — withstands wash-down, dust ingress, and splash in harsh production areas
- Wide operating temperature range — suitable for both climate-controlled and non-conditioned enclosures
- Dual Ethernet ports — supports network redundancy and device-level ring (DLR) topologies
- Compact depth profile — fits standard 200 mm deep enclosures without modification
- Parker EasyBuilder / compatible HMI software — rapid project development with pre-built driver libraries
System Architecture & Signal Flow
The PA08T-133 operates as the operator interface layer in a three-tier automation architecture:
- Field Level: Sensors, actuators, and I/O modules communicate via RS-485 / Modbus RTU or fieldbus
- Control Level: PLC or DCS controller exchanges data with the HMI over Ethernet (EtherNet/IP, Modbus TCP) or serial
- Supervisory Level: HMI forwards aggregated data to SCADA / MES via OPC-UA or MQTT (firmware-dependent)
The dual Ethernet architecture allows simultaneous connection to the machine network and the plant IT network, supporting data historian integration without network bridging risks.
Sourcing & Quality Verification
- All units sourced through authorized Parker Hannifin distribution channels or verified surplus with full traceability documentation
- Each unit undergoes incoming inspection: visual, power-on, display uniformity, and communication port verification
- Original Parker part number, date code, and firmware version confirmed prior to shipment
- Packaging: original OEM carton where available; otherwise ESD-safe anti-static foam with moisture barrier
- Certificate of conformance (CoC) available upon request
Procurement Process
- Step 1: Submit RFQ via Konmask.com product page or email [email protected] with quantity and delivery requirements
- Step 2: Receive quotation with lead time, unit price, and shipping options within 1 business day
- Step 3: Confirm purchase order — accepted formats: PO email, online checkout, or wire transfer
- Step 4: Shipment via DHL / FedEx / UPS Express with tracking number provided same day
- Step 5: Post-delivery technical support available via email and WhatsApp
Technical FAQ
Q: Is the PA08T-133 compatible with Siemens S7-1200/1500 PLCs?
A: Yes. Via Modbus TCP or EtherNet/IP with appropriate driver configuration in the HMI project software.
Q: Can the display brightness be adjusted for outdoor or high-ambient-light environments?
A: Brightness is adjustable via software settings. For direct sunlight applications, a sunlight-readable overlay option may be required — contact us for specifications.
Q: What HMI programming software is required?
A: Parker-compatible HMI configuration software (EasyBuilder Pro or equivalent). Free download available from Parker Hannifin’s official support portal.
Q: Is a replacement touchscreen digitizer available?
A: Yes, spare touch panels and display assemblies are available. Contact [email protected] with your serial number for compatibility confirmation.
Q: What is the warranty period?
A: 12 months from shipment date, covering manufacturing defects. Extended warranty available upon request.
