Phoenix Contact 2320157 QUINT-DIODE/12-24DC/2×20/1×40 Redundancy Module | Replacement, Equivalent & Selection Guide
The Phoenix Contact 2320157 QUINT-DIODE/12-24DC/2×20/1×40 is a high-performance diode redundancy module designed for 12–24 VDC power supply systems. It enables parallel connection of two power supplies (each up to 20 A) to deliver a combined output of up to 40 A, ensuring uninterrupted operation in critical industrial automation environments. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number / SKU: 2320157
- Model: QUINT-DIODE/12-24DC/2×20/1×40
- Brand: Phoenix Contact
- Function: Diode redundancy module for parallel power supply connection
- Input Voltage: 12–24 VDC
- Input Channels: 2 × 20 A
- Output Current: Up to 40 A
- Topology: Active ORing / diode decoupling
- Mounting: DIN rail (35 mm)
- Protection: Reverse polarity, overload, short-circuit
- Signaling: Collective error message contact
- Operating Temperature: −25 °C to +70 °C
- Weight: 680 g
- Certifications: UL, CE, ATEX (refer to datasheet)
- Series: QUINT POWER
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the Phoenix Contact 2320157. Always verify electrical parameters and form factor before substitution.
- Phoenix Contact 2320170 – QUINT-DIODE/24DC/2×20/1×40 (24 VDC fixed input variant)
- Phoenix Contact 2866594 – QUINT4-DIODE/24DC/2×20/1×40 (next-generation QUINT4 series, enhanced diagnostics)
- Murr Elektronik 85601 – MCS-B REDUNDANCY MODULE 24VDC/2×20A (functional equivalent, different form factor)
- Weidmüller PRO ECO 40W – Redundancy module with comparable current rating (verify pinout)
- PULS YR40.241 – Redundancy module 24 VDC / 40 A (direct functional equivalent, DIN rail)
- Siemens 6EP1961-2BA21 – SITOP redundancy module 24 VDC / 40 A (cross-brand equivalent)
Note: Cross-brand replacements require full datasheet comparison. Contact support@konmask.com for application-specific guidance.
Why Choose the Original Model
- Proven QUINT reliability: Phoenix Contact QUINT series is an industry benchmark for power supply redundancy in harsh industrial environments.
- Active ORing technology: Minimizes voltage drop compared to passive diode solutions, preserving system efficiency.
- Integrated diagnostics: Collective error signaling enables fast fault detection without additional monitoring hardware.
- Wide input range: 12–24 VDC flexibility supports both legacy 12 V and modern 24 V system architectures.
- Long-term availability: Supported by Phoenix Contact’s global spare-parts and service network.
Typical Applications
- PLC and DCS control panel power redundancy
- Industrial automation lines requiring 24/7 uptime
- Railway and transportation control systems
- Oil & gas and process industry control cabinets
- Building automation and HVAC control systems
- Machine safety circuits requiring redundant power feeds
System Compatibility
The 2320157 is designed to work seamlessly with Phoenix Contact QUINT POWER series power supplies, including:
- QUINT-PS/1AC/24DC/20 (2938600)
- QUINT-PS/3AC/24DC/20 (2938627)
- QUINT4-PS/1AC/24DC/20 (2904602)
It is also compatible with any 12–24 VDC power supply with a current output of up to 20 A per channel, regardless of brand, provided the output connector and voltage tolerance are matched.
Selection Guide
Use the following criteria to confirm the 2320157 is the correct module for your application:
- System voltage: 12 VDC or 24 VDC nominal? → 2320157 supports both.
- Per-channel current: ≤ 20 A per power supply? → Confirmed compatible.
- Total load current: ≤ 40 A? → Within rated output.
- Mounting: 35 mm DIN rail available? → Standard fit.
- Diagnostics required: Need error signaling? → Built-in collective error contact included.
- Upgrade path: Planning to migrate to QUINT4? → Consider 2866594 for forward compatibility.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels.
- Each module undergoes visual inspection and functional verification before shipment.
- Original manufacturer packaging and documentation preserved where available.
- Traceability records maintained for B2B and OEM customers upon request.
- Konmask.com specializes in industrial automation components — PLC modules, DCS parts, and power supply accessories from leading global brands.
How to Order
- Online: Add to cart directly on this page.
- Email: support@konmask.com — include your required quantity and delivery address.
- Phone / WhatsApp: +0086 19859288691
- Bulk / OEM orders: Request a formal quotation via email for volume pricing and lead-time confirmation.
- Lead time: In-stock items ship within 1–3 business days. Out-of-stock items subject to sourcing lead time — contact us for ETA.
Replacement & Compatibility FAQ
Q: Can I replace the 2320157 with the QUINT4-DIODE 2866594?
A: Yes, the QUINT4 series is the next-generation successor. It is electrically compatible but has a slightly different housing profile. Verify DIN rail space before installation.
Q: Is the 2320157 compatible with non-Phoenix Contact power supplies?
A: Yes, as long as the power supply outputs 12–24 VDC at ≤ 20 A per channel with standard terminal connections.
Q: What is the difference between 2320157 and 2320170?
A: The 2320170 is rated for 24 VDC fixed input only, while the 2320157 supports 12–24 VDC. Choose 2320157 for mixed-voltage or legacy 12 V systems.
Q: Do you provide a certificate of conformity?
A: Yes, available upon request for B2B orders. Contact support@konmask.com.
Q: Can Konmask.com source discontinued or hard-to-find variants?
A: Yes. We specialize in sourcing obsolete and long-lead industrial components. Submit your part number and quantity for a quote.
