Industrial Power Supply Solution – PHOENIX CONTACT QUINT-PS-100-240AC/24DC/20 | QUINT POWER Series
Where This Product Is Used
The PHOENIX CONTACT QUINT-PS-100-240AC/24DC/20 (Part No. 2938620) is a 480 W DIN rail-mounted power supply engineered for demanding industrial environments. Typical deployment scenarios include:
- PLC Control Panels – Stable 24 VDC bus power for Siemens S7, Allen-Bradley ControlLogix, Mitsubishi MELSEC, and Omron NX/NJ controllers.
- Process Automation – Powering field instruments, transmitters, and I/O modules in oil & gas, chemical, and water treatment plants.
- Machine Tool & Robotics – Servo drive auxiliary circuits, safety relay chains, and HMI panels on CNC machining centers.
- Building Automation (BAS/BMS) – HVAC controllers, fire alarm panels, and access control systems requiring uninterrupted 24 VDC.
- Railway & Transportation – Trackside signaling cabinets and on-board control systems (EN 50155 environments).
- Renewable Energy – Inverter control boards and monitoring systems in solar and wind installations.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 2938620 |
| Model | QUINT-PS-100-240AC/24DC/20 |
| Input Voltage | 100 – 240 VAC (85 – 264 VAC wide range) |
| Input Frequency | 45 – 65 Hz |
| Output Voltage | 24 VDC (adjustable 18 – 29.5 VDC) |
| Output Current | 20 A nominal |
| Output Power | 480 W |
| SFB Boost Current | Up to 60 A (3× In, ≤12 ms) |
| Efficiency | ≥ 95.5 % |
| Mounting | DIN rail (EN 60715 TH 35) |
| Protection Class | IP20 |
| Operating Temperature | -25 °C … +70 °C |
| MTBF | > 500,000 h (IEC 61709) |
| Weight | 2,570 g |
| Dimensions (W×H×D) | 60 × 130 × 125 mm |
Why Engineers Specify This Model
- SFB (Selective Fuse Breaking) Technology – Delivers up to 3× rated current for ≤12 ms to reliably blow downstream fuses and isolate faults without nuisance tripping of the supply itself.
- Active Power Factor Correction (PFC) – PF > 0.99 reduces harmonic distortion and lowers energy costs in large panel installations.
- Static & Dynamic Output Voltage Adjustment – Fine-tune output from 18 to 29.5 VDC via front-panel potentiometer to compensate for long cable runs.
- Integrated Monitoring & Signaling – Floating relay contact (DC OK) and LED status indicator enable remote SCADA/PLC fault detection without additional modules.
- Parallel Redundancy Ready – Supports N+1 redundancy configurations with optional QUINT-DIODE decoupling modules for mission-critical uptime.
- Wide Temperature Range – Full rated output from -25 °C to +70 °C; no derating required up to 60 °C.
Complete System Bill of Materials
For a fully redundant 24 VDC power distribution system, engineers typically pair this unit with:
- PHOENIX CONTACT QUINT-DIODE/40 (2320238) – Redundancy module / ORing diode
- PHOENIX CONTACT QUINT-BUFFER/24DC/20 (2320500) – UPS buffer module, 20 A
- PHOENIX CONTACT CLIPLINE MINI MCB – Branch circuit protection, 2 A – 16 A
- PHOENIX CONTACT TRABTECH PT 2X2-24DC-ST (2856226) – Surge protection device
- PHOENIX CONTACT IQ SENSOR (2702459) – Current monitoring for predictive maintenance
Compliance & Industry Standards
- CE Marking – Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL 508 Listed – Industrial Control Equipment (File E135462)
- IEC/EN 61558-2-16 – Safety of transformers and power supplies
- IEC 61000-4 Series – EMC immunity (ESD, EFT, surge, conducted RF)
- SEMI F47 – Voltage sag immunity for semiconductor equipment
- RoHS 2011/65/EU – Restriction of hazardous substances
- REACH – SVHC compliance
Quality Assurance & Sourcing
Every unit offered by Konmask.com undergoes a documented incoming inspection process:
- Visual inspection against OEM cosmetic standards
- Output voltage and current load test at 25 %, 50 %, and 100 % rated load
- SFB boost-current verification
- DC OK relay contact continuity check
- Serialization and traceability record retained for 5 years
Units are sourced from authorized distributors and verified supply chains. Counterfeit-risk screening is applied to all PHOENIX CONTACT product lines.
How to Source This Part
Submit your RFQ directly via our website or contact our technical sales team:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-factory orders 2–4 weeks.
- MOQ: 1 piece
- Payment: T/T, PayPal, credit card (Visa / Mastercard)
- Shipping: DHL / FedEx / UPS express worldwide; sea freight for bulk orders
Application-Specific FAQ
Q: Can this PSU power a Siemens S7-1500 PLC with multiple I/O modules?
A: Yes. The 20 A output comfortably powers a typical S7-1516 CPU with up to 16 digital I/O modules. Use the PHOENIX CONTACT STEP PS tool to verify your exact load budget.
Q: Is the QUINT-PS-100-240AC/24DC/20 suitable for 110 VAC North American installations?
A: Yes. The wide-range input (85–264 VAC) accepts both 110 VAC (60 Hz) and 230 VAC (50 Hz) without any switch or jumper change.
Q: How does SFB differ from a standard current-limiting PSU?
A: Standard PSUs fold back current under fault, which can prevent fuses from blowing. SFB actively pushes 3× rated current for up to 12 ms, guaranteeing fuse operation and faster fault isolation.
Q: Can two units be paralleled for 40 A output?
A: Direct paralleling is not recommended. Use the QUINT-DIODE/40 redundancy module to safely combine two units in an N+1 configuration.
Q: What is the warranty?
A: Konmask.com provides a 12-month warranty against defects in materials and workmanship. PHOENIX CONTACT OEM warranty terms apply to new, sealed units.
