Genuine PROSOFT 5021-MNET-DFNT Modbus/TCP to DF1 Communication Module | MVI Series – Verified Source
The PROSOFT 5021-MNET-DFNT is a high-performance Modbus/TCP to DF1 communication gateway module designed for seamless integration between Ethernet-based SCADA/HMI systems and Allen-Bradley DF1 serial networks. Sourced directly through verified industrial distribution channels, every unit sold by Konmask.com undergoes rigorous authenticity and functional verification before dispatch.
Whether you are expanding an existing control architecture or commissioning a new automation cell, the 5021-MNET-DFNT delivers the protocol bridging reliability your operation demands.
Technical Specifications
- Part Number: 5021-MNET-DFNT
- Manufacturer: ProSoft Technology
- Series: MVI (Multi-purpose Versatile Interface)
- Primary Protocol (Network Side): Modbus/TCP (Client & Server)
- Secondary Protocol (Serial Side): DF1 Full-Duplex / Half-Duplex
- Ethernet Port: 10/100 Mbps, RJ-45
- Serial Port: RS-232 / RS-485 (configurable)
- Power Supply: 5 VDC (supplied via backplane)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% (non-condensing)
- Backplane Compatibility: Allen-Bradley SLC 500 / MicroLogix chassis
- Configuration Interface: ProSoft Configuration Builder (PCB) software
- Certifications: CE, UL Listed, RoHS Compliant
- Dimensions: Standard SLC 500 single-slot module form factor
Our 4-Step Quality Verification Process
Every PROSOFT 5021-MNET-DFNT unit shipped from Konmask.com passes through our documented 4-step verification workflow:
- Step 1 — Source Authentication: Units are procured exclusively from authorised distributors and verified OEM channels. Supplier documentation and certificates of conformance are retained on file.
- Step 2 — Physical Inspection: Each module is inspected for label integrity, firmware revision markings, connector condition, and absence of counterfeit indicators (reground markings, mismatched date codes, irregular PCB finish).
- Step 3 — Functional Bench Test: Where applicable, modules are powered up and communication handshake tests are performed to confirm basic operational status prior to packaging.
- Step 4 — Secure Packaging & Documentation: Units are packed in anti-static ESD-safe packaging with a Konmask inspection checklist enclosed. Batch traceability records are maintained for 24 months.
Key Features & Benefits
- Bridges Modbus/TCP Ethernet networks to legacy DF1 serial devices without PLC programming changes
- Supports both Modbus/TCP Client (Master) and Server (Slave) operation modes simultaneously
- DF1 Full-Duplex and Half-Duplex (BCC & CRC) support for maximum Allen-Bradley device compatibility
- Configurable via intuitive ProSoft Configuration Builder — no ladder logic required for basic setup
- Onboard diagnostic LEDs for rapid field troubleshooting
- Backplane-powered design eliminates external power wiring complexity
- Compact single-slot form factor preserves chassis real estate
- Firmware field-upgradeable for long-term supportability
Typical Applications
- Connecting Modbus/TCP SCADA or DCS systems to Allen-Bradley SLC 500 / MicroLogix PLCs via DF1
- Retrofitting legacy DF1 serial networks with modern Ethernet supervisory infrastructure
- Oil & gas remote terminal unit (RTU) integration projects
- Water/wastewater treatment plant automation upgrades
- Manufacturing execution system (MES) data acquisition from DF1-based controllers
- Building automation and energy management system integration
- Food & beverage process control modernisation
Compatible System Components
- PLC Platforms: Allen-Bradley SLC 500 series, MicroLogix 1500
- Chassis: 1746-A4, 1746-A7, 1746-A10, 1746-A13 (SLC 500 chassis family)
- Programming Software: RSLogix 500, Studio 5000 (for supervisory integration)
- Configuration Tool: ProSoft Configuration Builder (PCB) — free download from ProSoft Technology
- Ethernet Infrastructure: Standard managed/unmanaged industrial Ethernet switches (100 Mbps)
- Serial Devices: Any DF1 Full-Duplex or Half-Duplex compatible Allen-Bradley or third-party device
Global Sourcing & Shipping Capabilities
Konmask.com operates as a specialist industrial automation component supplier with established logistics partnerships for reliable cross-border fulfilment:
- Domestic (China): Same-day dispatch for in-stock items; SF Express / JD Logistics delivery within 1–3 business days
- Asia-Pacific: DHL Express / FedEx International Priority; typical transit 3–5 business days
- Europe & Americas: DHL / FedEx / UPS; typical transit 5–10 business days depending on customs clearance
- Export Documentation: Commercial invoice, packing list, certificate of origin, and ESD-safe packaging declaration provided as standard
- Customs HS Code: 8537.10 (Boards, panels, consoles for electric control — verify with your local customs authority)
- Minimum Order Quantity: 1 unit; volume pricing available for orders of 5+ units — contact us for a quote
Certifications & Compliance Statement
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed: Recognised under applicable UL standards for industrial control equipment
- RoHS Compliant: Restriction of Hazardous Substances Directive (EU 2011/65/EU)
- ESD Handling: All units handled and shipped in accordance with ANSI/ESD S20.20 guidelines
- Konmask Authenticity Statement: Konmask.com does not knowingly source, stock, or sell counterfeit or non-genuine components. Any unit found to be non-genuine will be replaced or fully refunded. See our Returns Policy for details.
How to Order
- Online: Add to cart and check out securely at Konmask.com
- Email RFQ: Send your part number, quantity, and required delivery date to [email protected]
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Payment Terms: T/T bank transfer, PayPal, and major credit cards accepted; Net-30 terms available for approved corporate accounts
- Lead Time: In-stock units ship within 1 business day of payment confirmation; out-of-stock items subject to sourcing lead time (typically 7–21 days — confirm at time of order)
Authenticity & Trust FAQ
Q: How do I know the module is genuine PROSOFT?
A: Every unit is sourced through documented supply chains. We retain supplier invoices and certificates of conformance. Upon request, we can share sourcing documentation for your procurement records.
Q: What if the module is DOA (Dead on Arrival)?
A: We offer a 30-day DOA replacement guarantee. Contact us within 30 days of receipt with photos and a description of the fault. We will arrange a replacement or full refund at no cost to you.
Q: Can you provide a test report or inspection certificate?
A: Yes. For orders of 3+ units, a Konmask inspection checklist is enclosed as standard. Individual test reports can be arranged for volume orders — please enquire at time of purchase.
Q: Do you offer warranty beyond 30 days?
A: We honour the original manufacturer’s warranty terms where applicable. Extended warranty and service contracts can be discussed for volume or project-based purchases.
Q: Are you able to supply other PROSOFT MVI series modules?
A: Yes. Konmask.com stocks and sources a wide range of ProSoft Technology MVI, MVI46, MVI56, and MVI69 series modules. Contact us with your full BOM for a consolidated quote.
