RADISYS EM-DIO 02 Digital I/O Expansion Module | AdvancedTCA / CompactPCI Platform
Engineering Background
The RADISYS EM-DIO 02 (Part Number: 2445400132-01-05-42960065) is a dedicated digital input/output expansion module engineered for RADISYS embedded computing platforms. Designed to extend the I/O capability of carrier-grade and industrial control systems, this module integrates seamlessly into AdvancedTCA, CompactPCI, and ATCA-based architectures where deterministic signal handling and high-density I/O are mission-critical requirements.
Product Positioning
Targeted at procurement engineers and system integrators operating in telecommunications infrastructure, industrial process control, defense electronics, and transportation automation, the EM-DIO 02 delivers reliable discrete signal interfacing in environments demanding 24/7 uptime. Its compact form factor and platform-native compatibility make it the preferred choice for MRO (Maintenance, Repair & Overhaul) sourcing and system expansion projects.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | RADISYS Corporation |
| Part Number | 2445400132-01-05-42960065 |
| Model | EM-DIO 02 |
| Module Type | Digital I/O Expansion Module |
| Platform Compatibility | RADISYS AdvancedTCA / CompactPCI Series |
| I/O Interface | Discrete Digital Input / Output |
| Form Factor | Mezzanine / Expansion Module |
| Operating Temperature | 0°C to +55°C (Commercial Grade) |
| Storage Temperature | -40°C to +85°C |
| Power Supply | Supplied via host carrier board |
| Compliance | RoHS Compliant |
| Weight | Approx. 500 g |
| Condition | New / Refurbished OEM Available |
Proven Application Environments
- Telecommunications Infrastructure: Base station controllers, media gateways, and signaling servers requiring high-density discrete I/O expansion.
- Industrial Process Control: SCADA systems, DCS platforms, and PLC-integrated architectures where deterministic digital signal acquisition is essential.
- Defense & Aerospace Electronics: Ruggedized embedded computing systems with strict signal integrity and environmental compliance requirements.
- Transportation Automation: Railway control systems, traffic management units, and vehicle onboard computing platforms.
- MRO & System Lifecycle Extension: Direct OEM-equivalent replacement for aging RADISYS platform deployments to extend operational life without full system redesign.
Engineering Advantages
- Platform-Native Integration: Designed specifically for RADISYS carrier boards — eliminates compatibility risk and reduces integration engineering hours.
- Deterministic I/O Response: Hardware-level digital signal handling ensures predictable latency, critical for real-time control loops.
- High Channel Density: Maximizes I/O capacity within existing chassis footprint, deferring costly infrastructure upgrades.
- RoHS Compliance: Meets international environmental directives for global deployment and export compliance.
- Proven Field Reliability: Deployed across carrier-grade telecom and industrial installations with documented MTBF performance.
System Architecture & Signal Flow
The EM-DIO 02 mounts directly onto the RADISYS host carrier board via the designated mezzanine connector. Digital input signals are conditioned and latched at the module level before being passed to the host processor via the platform bus, ensuring signal integrity independent of host CPU load. Output channels are driven by buffered drivers capable of sourcing/sinking standard industrial logic levels. The module’s firmware is managed by the host BIOS/BSP, requiring no standalone configuration — plug-and-play within the RADISYS software ecosystem.
Sourcing & Quality Verification
- All units sourced through verified OEM channels and authorized industrial distributors.
- Each module undergoes incoming inspection including visual examination, part number verification against OEM documentation, and functional continuity checks prior to shipment.
- Serialized traceability records maintained for enterprise procurement audit requirements.
- Packaging: Anti-static ESD bag + foam-lined carton, compliant with JEDEC J-STD-033 handling standards.
Procurement Process
- Submit your RFQ or place order directly via Konmask.com product page.
- Receive order confirmation with lead time and shipping estimate within 1 business day.
- Quality inspection completed and shipment dispatched with tracking number.
- Post-delivery technical support available via email or phone for integration queries.
For volume orders (>5 units), blanket PO arrangements, or expedited sourcing, contact our procurement team directly at [email protected] or +0086 19859288691.
Technical FAQ
Q: Is the EM-DIO 02 compatible with all RADISYS carrier boards?
A: The EM-DIO 02 is designed for specific RADISYS platform generations. Please provide your host carrier board part number to our team for compatibility confirmation before ordering.
Q: Can this module be used as a standalone unit?
A: No. The EM-DIO 02 is a mezzanine expansion module and requires a compatible RADISYS host carrier board for power and bus connectivity.
Q: What is the warranty policy?
A: New OEM units carry the original manufacturer warranty. Refurbished units are covered by Konmask’s 90-day functional warranty. Extended warranty options available on request.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. CoC documentation is available upon request for all orders. Please specify at time of purchase.
Q: What are the lead times for this part?
A: In-stock units ship within 2–3 business days. For out-of-stock scenarios, typical sourcing lead time is 2–4 weeks. Contact us for real-time availability.
