RELIANCE ELECTRIC HR500 BLJC-08R 5RD1601 – AC Servo Drive Module | HR500 Series Platform
Engineering Background
The Reliance Electric HR500 Series represents a proven generation of industrial AC servo drive technology engineered for demanding motion control applications. Designed to meet the rigorous requirements of continuous-duty manufacturing environments, the HR500 platform integrates seamlessly with legacy and modern PLC architectures, making it a preferred choice for maintenance engineers and system integrators managing long-lifecycle automation assets.
Product Positioning
The RELIANCE HR500 BLJC-08R 5RD1601 is a precision AC servo drive module targeting procurement engineers who require a verified, drop-in replacement or expansion component for existing HR500-based servo systems. Sourced, inspected, and dispatched by Konmask.com — your trusted industrial automation parts specialist.
Complete Technical Specifications
| Manufacturer | Reliance Electric (Rockwell Automation) |
| Series / Platform | HR500 AC Servo Drive Series |
| Part Number | BLJC-08R |
| Catalog / Order Number | 5RD1601 |
| Module Type | AC Servo Drive Module |
| Drive Technology | AC Servo (Closed-Loop Vector) |
| Input Power | AC Three-Phase (refer to OEM nameplate for exact voltage/frequency rating) |
| Output | Variable frequency / voltage for servo motor control |
| Feedback Interface | Encoder / Resolver compatible (HR500 standard) |
| Communication | HR500 backplane / rack-based integration |
| Mounting | HR500 rack-mount module form factor |
| Weight | Approx. 2.16 kg |
| Country of Origin | USA |
| Condition | Used / Refurbished — Tested & Verified |
Note: Always cross-reference with the OEM HR500 technical manual for full electrical ratings before installation.
Proven Application Environments
- Automotive Manufacturing — Precision servo positioning on assembly lines and robotic welding cells
- Paper & Printing Industry — Web tension control and register servo systems
- Plastics & Extrusion — Extruder screw speed and position control
- Metal Forming & Press Lines — Servo-driven feed and transfer mechanisms
- Material Handling — Conveyor indexing and palletizing servo axes
- Textile Machinery — Multi-axis coordinated motion control
- Packaging Lines — High-speed pick-and-place and form-fill-seal servo axes
Engineering Advantages
- Drop-in Compatibility — Direct replacement for existing HR500 rack installations; no re-engineering required
- Closed-Loop Precision — Encoder/resolver feedback ensures accurate position, velocity, and torque control
- Proven Long-Term Reliability — HR500 platform has decades of field-proven performance in heavy industrial environments
- Reduced Downtime — Stocking a verified spare eliminates extended lead times during unplanned failures
- Broad PLC Integration — Compatible with Allen-Bradley, Reliance, and third-party PLC controllers via standard I/O and backplane interfaces
- Tested Before Dispatch — Each unit undergoes functional verification at Konmask.com prior to shipment
System Architecture & Signal Flow
The HR500 BLJC-08R module operates within the HR500 modular rack architecture. The signal flow is as follows:
- Command Input — Velocity or position reference received from the host PLC or motion controller via the HR500 backplane
- Drive Processing — Internal DSP computes PWM output based on closed-loop error signal
- Power Stage Output — Three-phase AC output delivered to the servo motor
- Feedback Loop — Encoder/resolver signals returned to the drive for real-time correction
- Fault & Status — Drive status and fault codes reported back to the PLC via backplane communication
Sourcing & Quality Verification
- All units are sourced from verified industrial surplus channels and decommissioned OEM installations
- Each module is visually inspected for physical damage, corrosion, and component integrity
- Functional power-on testing performed where applicable
- Serialized tracking maintained for full traceability
- Shipped in anti-static, padded packaging to prevent transit damage
- Certificate of testing available upon request
Procurement Process
- Confirm Part Number — Verify BLJC-08R / 5RD1601 matches your existing HR500 system BOM
- Request Quote — Contact support@konmask.com for volume pricing or expedited availability
- Place Order — Secure checkout via Konmask.com; PO and wire transfer accepted for B2B orders
- Dispatch & Tracking — Ships within 1–3 business days; DHL / FedEx international express available
- Installation Support — Technical guidance available post-delivery via email or phone
Technical FAQ
Q: Is this a new or refurbished unit?
A: This is a used/refurbished unit that has been tested and verified functional. New OEM units are available upon special request — contact us for lead time and pricing.
Q: What is the warranty?
A: Konmask.com provides a 90-day functional warranty covering verified defects identified upon receipt. Damage caused by incorrect installation is excluded.
Q: Can this module be used with non-Reliance servo motors?
A: The HR500 platform is optimized for Reliance servo motors. Compatibility with third-party motors depends on feedback interface and motor parameters — consult our technical team before ordering.
Q: Do you provide the HR500 technical manual?
A: Yes. The HR500 series documentation can be provided upon request. Contact support@konmask.com.
Q: What are the shipping options for international orders?
A: We ship worldwide via DHL Express, FedEx International Priority, and EMS. Typical transit time to Europe/North America is 3–7 business days.
Q: Can I return the module if it doesn’t fit my system?
A: Returns are accepted within 14 days of receipt for unused, uninstalled units in original condition. Please contact support@konmask.com to initiate a return.
