Industrial Motion Control Solution – Rexroth DDS02.1-W200-D | DDS Series AC Servo Drive
Where This Product Is Used
The Rexroth DDS02.1-W200-D is a high-performance AC servo drive controller engineered for demanding industrial motion control environments. Engineers and system integrators specify this unit across a wide range of applications:
- CNC Machine Tools – Precision axis control for milling, turning, and grinding centers requiring tight velocity and position loop performance.
- Industrial Robotics – Multi-axis coordinated motion in articulated arm robots, SCARA systems, and gantry robots on automotive and electronics assembly lines.
- Injection Molding Machines – High-dynamic servo control of clamping, injection, and ejection axes for cycle-time optimization.
- Printing & Packaging Machinery – Register control and web tension management in high-speed converting and packaging lines.
- Semiconductor & Electronics Manufacturing – Ultra-precise positioning in pick-and-place, wafer handling, and PCB drilling equipment.
- Material Handling & Conveyors – Synchronized multi-drive systems for palletizers, sorters, and automated storage/retrieval systems (AS/RS).
Technical Specifications
| Parameter | Value |
|---|---|
| Model | DDS02.1-W200-D |
| Series | DDS (Digital Drive System) |
| Manufacturer | Bosch Rexroth AG |
| Continuous Output Current | 200 A |
| Drive Type | AC Servo Drive Controller |
| Control Mode | Position / Velocity / Torque |
| Interface | SERCOS / Analog / Digital I/O |
| Feedback | Resolver / Encoder compatible |
| Protection Class | IP20 (panel-mount) |
| Cooling | Forced air (internal fan) |
| Compliance | CE, UL, cUL |
| Weight | Approx. 1.0 kg (module only) |
Why Engineers Specify This Model
- 200 A continuous output – Handles high-inertia loads and aggressive duty cycles without derating.
- DDS Digital Drive architecture – Rexroth’s proven closed-loop digital platform delivers sub-millisecond current loop response for superior surface finish and throughput.
- Multi-mode control – Seamlessly switches between position, velocity, and torque modes via fieldbus command, reducing PLC programming complexity.
- SERCOS compatibility – Deterministic real-time fiber-optic bus integration with Rexroth DIAX04, IndraControl, and third-party CNC controllers.
- Compact panel-mount form factor – Optimizes cabinet space in retrofit and new-build control panels.
- Long service life – Rexroth’s industrial-grade power stage components are rated for 24/7 continuous operation in harsh factory environments.
Complete System Bill of Materials
For a fully operational DDS02.1-W200-D servo axis, the following components are typically required:
- Rexroth DDS02.1-W200-D – AC Servo Drive Controller (this unit)
- Rexroth MHD / MKD / MKE Series AC Servo Motor (matched to load requirements)
- Rexroth HVR / HVE Power Supply Module (DC bus supply)
- Rexroth SERCOS Interface Card or analog command module
- Feedback cable (resolver or encoder, shielded, Rexroth IKS series recommended)
- Motor power cable (Rexroth IKL series, appropriately rated)
- 24 VDC control power supply
- Line filter / EMC filter (per CE installation requirements)
Contact support@konmask.com for complete BOM assistance and compatibility verification.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and EMC Directive.
- UL / cUL Listed – Recognized for use in North American industrial control panels.
- RoHS Compliant – Meets EU Restriction of Hazardous Substances requirements.
- ISO 9001 – Manufactured under Bosch Rexroth’s certified quality management system.
- IEC 61800 – Adjustable speed electrical power drive systems standard.
Quality Assurance & Sourcing
Every Rexroth DDS02.1-W200-D unit offered by Konmask.com undergoes the following quality process:
- Visual & mechanical inspection – Connectors, PCB, and housing checked for damage or counterfeit indicators.
- Functional power-on test – Drive initialized and parameter readback verified where applicable.
- Traceability – Serial number and date code recorded against each order.
- Secure packaging – Anti-static bag, foam-lined carton, and moisture barrier for international shipment.
We source from authorized distributors, OEM overstock, and verified industrial surplus channels. All units are sold with a 90-day warranty against defects in materials and workmanship.
How to Source This Part
- Add to cart and complete checkout — we accept T/T bank transfer, PayPal, and major credit cards.
- Request a quote for volume orders (>3 units) or urgent delivery via support@konmask.com.
- Lead time: In-stock units ship within 1–3 business days. Ex-stock or sourced units: 5–15 business days.
- Export documentation: Commercial invoice, packing list, and COO certificate available upon request.
- Technical support: Our engineering team can assist with parameter setup, wiring diagrams, and compatibility checks.
Application-Specific FAQ
Q: Is the DDS02.1-W200-D compatible with Rexroth DIAX04 motors?
A: Yes. The DDS02.1 series is designed to work with Rexroth MHD, MKD, and MKE servo motors. Always verify the motor feedback type (resolver vs. encoder) matches the drive configuration.
Q: Can this drive be used as a retrofit replacement for an older DDS01 unit?
A: In many cases yes, but mechanical mounting dimensions and parameter sets differ. Contact our team for a compatibility assessment before ordering.
Q: What fieldbus protocols does the DDS02.1-W200-D support?
A: The standard -D variant supports SERCOS fiber-optic interface. Analog ±10 V and digital I/O command modes are also available depending on firmware configuration.
Q: Do you provide the Rexroth IndraWorks commissioning software?
A: We can advise on software sourcing. Bosch Rexroth’s IndraWorks DS is available through their official channels; we provide guidance on parameter backup and restore procedures.
Q: What is the minimum order quantity?
A: MOQ is 1 unit. Volume pricing is available for orders of 3 or more units.
