Bosch Rexroth VT-3014 S35 R5 Proportional Amplifier Card | Replacement, Equivalent & Selection Guide
The Bosch Rexroth VT-3014 S35 R5 is a plug-in proportional amplifier card designed for controlling proportional directional and pressure/flow control valves in industrial hydraulic systems. As an authorized distributor and sourcing partner, Konmask.com supplies both genuine OEM units and verified compatible replacements to minimize downtime and reduce procurement costs.
Technical Specifications
- Part Number: VT-3014 S35 R5
- Manufacturer: Bosch Rexroth AG
- Series: VT-3014 (Proportional Amplifier Card Series)
- Function: Proportional solenoid amplifier / control card
- Supply Voltage: 24 V DC (±15%)
- Output Current: Max. 3.5 A per solenoid
- Enable Input: Digital enable signal compatible
- Command Input: ±10 V differential or 0–10 V
- Form Factor: Eurocard plug-in board (DIN 41612)
- Weight: ~4.46 kg (packaged)
- Operating Temperature: 0 °C to +50 °C
- Protection Class: IP 00 (card format)
- Standards: CE compliant
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the VT-3014 S35 R5. Always verify electrical and mechanical compatibility before substitution:
- Rexroth VT-3014 S36 R5 – Next revision, pin-compatible in most rack configurations
- Rexroth VT-3013 S35 R5 – Single-solenoid variant; suitable for simpler valve topologies
- Rexroth VT-VSPA2-1-1X/V0/T1 – Modern successor amplifier card with enhanced diagnostics
- Rexroth VT-MSPA1-1 – Modular amplifier for proportional valves, rack-mount compatible
- Moog T167 Series Amplifier Card – Third-party equivalent; requires wiring adaptation
- Parker Hannifin PCD00A-AA-0 – Cross-brand alternative for proportional valve control
⚠ Disclaimer: Cross-brand replacements require engineering validation. Contact our technical team for a compatibility assessment.
Why Choose the Original VT-3014 S35 R5
- ✅ Factory-calibrated for Rexroth proportional valve families (4WRPH, 4WRKE, DBEM series)
- ✅ Guaranteed parameter matching — no re-tuning required on drop-in replacement
- ✅ Full traceability with Rexroth material number and batch certification
- ✅ Supported by Rexroth global service network and spare parts availability
- ✅ Proven reliability in continuous-duty industrial hydraulic applications
Typical Applications
- Injection molding machine hydraulic axis control
- Metal forming press proportional pressure/flow regulation
- Industrial robot hydraulic actuator positioning
- Steel mill rolling mill gap control systems
- Marine and offshore hydraulic steering systems
- Test bench closed-loop force and position control
System Compatibility
The VT-3014 S35 R5 is designed for use within the Rexroth VT-3000 amplifier card rack system and is compatible with the following valve families:
- Rexroth 4WRPH / 4WRKE proportional directional control valves
- Rexroth DBEM / DREM proportional pressure control valves
- Rexroth 2FRE / 2FRM proportional flow control valves
- PLC systems with ±10 V analog output (Siemens S7, Allen-Bradley, Mitsubishi Q/iQ-R series)
- DCS platforms with standard 4–20 mA or ±10 V command signals (via signal converter)
Selection Guide
Use the following criteria to confirm the VT-3014 S35 R5 is the correct card for your application:
- Step 1 – Valve Type: Confirm your proportional valve requires a dual-solenoid amplifier (VT-3014 series). Single-solenoid valves use VT-3013.
- Step 2 – Revision Level: Check the “S35” suffix — this denotes the hardware revision. Mixing revisions in the same rack is generally safe but verify with Rexroth documentation.
- Step 3 – Software Version: “R5” indicates firmware/parameter set version. Confirm compatibility with your existing rack controller firmware.
- Step 4 – Supply Voltage: Verify your rack provides stable 24 V DC ±15% to the card slot.
- Step 5 – Command Signal: Confirm your PLC/DCS outputs ±10 V differential or 0–10 V single-ended command signal.
- Step 6 – Quantity & Lead Time: Contact Konmask.com for stock availability and expedited sourcing options.
Quality Assurance & Sourcing
- 🔍 100% functional test performed on all cards prior to shipment
- 📦 Anti-static ESD packaging with humidity indicator card
- 📋 Certificate of Conformance available upon request
- 🏭 Sourced from authorized distributors and verified secondary market channels
- 🔄 30-day return policy for DOA (Dead on Arrival) units
- 🌐 Global shipping via DHL / FedEx / UPS with full tracking
How to Order
- Confirm part number: VT-3014 S35 R5 (or specify your required revision)
- Specify quantity and required delivery timeline
- Submit inquiry via support@konmask.com or WhatsApp +0086 19859288691
- Receive quotation within 24 business hours with stock confirmation
- Confirm order — payment via T/T, PayPal, or credit card accepted
- Shipment dispatched within 1–3 business days with tracking number provided
