Process Control Solution — Schneider Electric 140AII33010 | Quantum Series
Where This Product Is Used
The Schneider Electric 140AII33010 is a 16-channel analog input module engineered for the Modicon Quantum PLC platform. It is deployed across demanding industrial environments where precise, real-time analog signal acquisition is critical to process integrity and safety.
- Oil & Gas: Wellhead pressure and temperature monitoring, pipeline flow measurement, separator level control
- Water & Wastewater Treatment: pH, turbidity, dissolved oxygen, and flow sensor integration across multi-stage treatment plants
- Power Generation & Utilities: Generator load monitoring, transformer temperature trending, substation SCADA integration
- Chemical & Petrochemical Plants: Reactor temperature profiling, pressure differential measurement, feed-rate control loops
- Automotive Manufacturing: Paint booth climate control, press tonnage monitoring, conveyor tension feedback
- Food & Beverage Processing: Pasteurization temperature control, tank level management, CIP flow verification
- Pulp & Paper Mills: Steam pressure regulation, dryer section temperature control, stock consistency measurement
- Mining & Minerals: Crusher load monitoring, slurry density measurement, conveyor belt tension control
Technical Specifications
| Part Number | 140AII33010 |
| Brand / Manufacturer | Schneider Electric (Modicon) |
| Series / Platform | Modicon Quantum |
| Module Type | Analog Input Module |
| Number of Channels | 16 Channels (single-ended) |
| Input Signal Range | 4–20 mA / 0–20 mA / 0–10 V DC (software-configurable per channel) |
| Resolution | 12-bit (0–4095 counts) |
| Accuracy | ±0.1% of full scale at 25°C |
| Isolation | Channel-to-backplane optical isolation |
| Scan Time | ≤ 10 ms for all 16 channels |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Consumption | 800 mA @ 5 VDC (from backplane) |
| Backplane Compatibility | Modicon Quantum 140 Series backplanes |
| Weight | 910 g |
| Dimensions (H × W × D) | Standard Quantum single-slot form factor |
| Wiring Connector | Removable screw-terminal block (field-side) |
| Firmware / Software | Unity Pro / Control Expert compatible |
| Country of Origin | France / EU |
Why Engineers Specify This Model
- High Channel Density: 16 analog inputs in a single slot reduces rack space and wiring complexity versus multi-module alternatives.
- Per-Channel Software Configuration: Signal type (current/voltage) and range are set in Unity Pro/Control Expert without hardware jumpers, eliminating field wiring errors.
- Optical Isolation: Channel-to-backplane isolation protects the CPU and other I/O from ground loops and transient surges common in heavy industrial environments.
- Proven Quantum Ecosystem: Seamless integration with Quantum CPUs (140CPU series), Hot Standby redundancy configurations, and RIO/DIO drop architectures.
- Long Product Lifecycle: Schneider Electric’s Quantum platform has decades of installed base, ensuring long-term spare parts availability and engineering familiarity.
- Deterministic Scan Performance: Sub-10 ms full-channel scan time supports tight PID loop tuning in process control applications.
Complete System Bill of Materials
The 140AII33010 operates within the Modicon Quantum ecosystem. A typical process control rack may include:
- CPU: 140CPU65160 / 140CPU67160 (Hot Standby)
- Power Supply: 140CPS11420 / 140CPS21400
- Backplane: 140XBP01600 (16-slot) / 140XBP00600 (6-slot)
- Analog Input: 140AII33010 (this module)
- Analog Output: 140AVO02000 / 140ACO13000
- Digital I/O: 140DDI35300 / 140DDO35300
- Communication: 140NOE77101 (Ethernet TCP/IP) / 140NOM21200 (Modbus Plus)
- Terminal Block: TSXCAP030 / compatible 40-pin field wiring accessories
Contact support@konmask.com for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- CE Marking — EU Low Voltage Directive & EMC Directive compliant
- UL Listed — UL 508 (Industrial Control Equipment)
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- IEC 61000-4 Series — EMC Immunity (ESD, EFT, Surge, Conducted RF)
- RoHS Compliant — Restriction of Hazardous Substances Directive
- ATEX / IECEx — Suitable for use in Zone 2 classified areas when installed in certified enclosures (verify with project EIC)
- DNV GL / ABS — Marine and offshore installation approvals available on select configurations
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for mission-critical applications. Every 140AII33010 unit we supply is:
- Authenticity Verified: Sourced from authorized distributors and verified OEM supply chains — no grey-market or counterfeit risk.
- Functional Tested: Bench-tested for power-on, backplane communication, and channel response prior to shipment where applicable.
- Condition Disclosed: New-in-box (NIB), factory-refurbished, or surplus stock clearly labeled — no ambiguity on product condition.
- Traceability Documented: Lot codes, date codes, and supply chain documentation available on request for regulated industries.
- Packaged for Transit: ESD-safe packaging with anti-static bags, foam cushioning, and moisture barrier for international freight.
How to Source This Part
Getting the 140AII33010 to your facility is straightforward:
- In-Stock Orders: Add to cart and check out — most orders ship within 1–3 business days from our warehouse.
- Bulk / Project Quantities: Email support@konmask.com with your project BOM for volume pricing and lead-time confirmation.
- Urgent / Emergency Shutdown (ESD) Requirements: Call or WhatsApp +0086 19859288691 for expedited sourcing and same-day quotation.
- Cross-Reference & Substitution: If your application requires an alternative analog input module, our engineers can recommend compatible Quantum or Modicon M340/M580 equivalents.
- Export & International Shipping: We ship globally with full export documentation (commercial invoice, packing list, COO). DDP/DAP Incoterms available.
Application-Specific FAQ
Q: Can the 140AII33010 be used in a Hot Standby (HSBY) Quantum configuration?
A: Yes. The module is fully compatible with Quantum Hot Standby CPU pairs (e.g., 140CPU67160). I/O scanning is managed by the primary CPU; the standby CPU takes over seamlessly on failover without analog input data loss.
Q: Is the 140AII33010 compatible with HART field devices?
A: No. The 140AII33010 is a standard analog input module and does not support HART protocol pass-through. For HART-enabled analog input, specify the 140AHI33000 or use a dedicated HART multiplexer.
Q: What software is required to configure this module?
A: Schneider Electric Unity Pro (legacy) or Control Expert (current) is required for module configuration, channel scaling, and diagnostics. The module is not compatible with Concept or ProWORX software.
Q: Can I mix 4–20 mA and 0–10 V sensors on the same module?
A: Yes. Each of the 16 channels is independently configurable for current or voltage input via software — no hardware changes required.
Q: What is the replacement or modern equivalent for this module?
A: The Modicon M580 platform (BMXAMI0810 / BMXAMI0410) is Schneider Electric’s current-generation equivalent. Konmask can supply both legacy Quantum and current M580 modules — contact us for migration guidance.
Q: Do you provide a warranty on this module?
A: Yes. Konmask provides a 12-month warranty on all new-in-box units and a 6-month warranty on tested surplus/refurbished units. Warranty covers manufacturing defects and functional failure under normal operating conditions.
