Process Control Solution — Schneider Electric 140XBP00600 | Modicon Quantum Series
The Schneider Electric 140XBP00600 is a 6-slot backplane rack from the Modicon Quantum PLC platform — one of the most widely deployed distributed control architectures in heavy industry. Designed for high-density I/O expansion and CPU-to-module communication, this backplane forms the physical and electrical backbone of any Quantum control system.
Where This Product Is Used
The 140XBP00600 is specified by control engineers across demanding industrial environments where system uptime and signal integrity are non-negotiable:
- Oil & Gas Processing Plants — DCS rack expansion for wellhead, pipeline, and refinery control loops
- Water & Wastewater Treatment — SCADA-integrated PLC racks for pump stations, filtration, and dosing systems
- Power Generation & Utilities — Substation automation and turbine governor control panels
- Automotive Manufacturing — Body-in-white welding lines and paint shop conveyor control
- Pharmaceutical & Food Processing — FDA/GMP-compliant batch control systems requiring validated hardware
- Mining & Minerals — Crusher, conveyor, and flotation cell automation in harsh environments
- Building Management Systems (BMS) — Central plant HVAC and energy management controllers
Technical Specifications
| Part Number | 140XBP00600 |
| Brand | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Module Slots | 6 slots |
| Backplane Type | Local / Remote I/O Rack |
| Bus Interface | Quantum Backplane Bus (proprietary high-speed) |
| Power Supply Slot | Slot 1 (dedicated, left-most) |
| Compatible CPUs | 140CPU series (e.g. 140CPU65150, 140CPU67160) |
| Compatible I/O | 140DDI, 140DDO, 140DAI, 140DAO, 140ACI, 140ACO series |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0°C to +60°C |
| Weight | 1,040 g |
| Country of Origin | France / EU |
Why Engineers Specify This Model
- 6-slot density — Optimal for mid-size control panels where rack space is limited but I/O count is moderate (16–64 points per rack)
- Hot-swap compatible modules — Supports live module replacement on select Quantum configurations, minimizing planned downtime
- Proven platform longevity — Modicon Quantum has been in continuous production since the 1990s; spare parts and engineering expertise are globally available
- Deterministic scan cycle — Backplane bus architecture ensures predictable, low-latency I/O scan times critical for safety-related applications
- Wide module compatibility — Accepts the full Quantum I/O, communication, and specialty module library without adapter hardware
Complete System Bill of Materials
A typical Quantum control node built around the 140XBP00600 includes:
- 140XBP00600 — This 6-slot backplane (qty: 1)
- 140CPS11420 or 140CPS21400 — Quantum power supply module (qty: 1)
- 140CPU65150 — Quantum CPU module with Ethernet (qty: 1)
- 140DDI35300 — 32-channel 24VDC discrete input module (qty: as required)
- 140DDO35300 — 32-channel 24VDC discrete output module (qty: as required)
- 140ACI04000 — 4-channel analog current input module (qty: as required)
- 140NOE77101 — Ethernet TCP/IP communication module (qty: optional)
Contact Konmask for complete BOM pricing and availability on multi-unit orders.
Compliance & Industry Standards
- CE Marked — EU Machinery Directive and EMC Directive compliant
- UL Listed — UL 508 Industrial Control Equipment
- IEC 61131-2 — Programmable controllers hardware requirements
- RoHS Compliant — Restriction of Hazardous Substances
- ATEX / IECEx — Compatible with Quantum safety modules for Zone 2 applications (with appropriate barriers)
Quality Assurance & Sourcing
- Authentic OEM hardware — Sourced from authorized Schneider Electric distribution channels and verified industrial surplus
- Pre-shipment inspection — Each unit inspected for physical integrity, connector condition, and label authenticity
- Functional test available — Power-on and bus communication test available on request for critical applications
- Traceability — Lot and date codes documented; certificates of conformance available upon request
- Packaging — Anti-static bag + foam-lined carton; ESD-safe handling throughout
How to Source This Part
- Add to cart and complete checkout — standard lead time 1–3 business days for in-stock units
- Request a quote for volume orders (5+ units) or multi-line BOM sourcing via support@konmask.com
- Urgent requirement? Call or WhatsApp +0086 19859288691 for same-day shipping options
- International buyers — We ship worldwide via DHL Express, FedEx, and UPS with full commercial invoice and packing list documentation
Application-Specific FAQ
Q: Can the 140XBP00600 be used as a remote I/O rack?
A: Yes. When paired with a 140CRA93200 remote I/O adapter module, this backplane can be deployed as a remote rack on a Quantum RIO drop, extending the system up to 31 remote racks from the local CPU rack.
Q: Is this backplane compatible with the Quantum Hot Standby (HSBY) architecture?
A: The 140XBP00600 is compatible with standard Quantum racks used in HSBY configurations. The Hot Standby CPU modules (140CPU67160S) and the dedicated HSBY cable connect at the CPU slot level, not the backplane level.
Q: What is the maximum number of 140XBP00600 racks per Quantum system?
A: A single Quantum CPU supports up to 16 local extension racks and up to 31 remote I/O drops. Each drop can use multiple backplane sizes including the 6-slot 140XBP00600.
Q: Can I mix 6-slot and 16-slot racks in the same system?
A: Yes. Quantum supports mixed rack configurations. The 140XBP00600 (6-slot) can coexist with 140XBP01600 (16-slot) and 140XBP01000 (10-slot) racks in the same control system.
Q: Do you provide a warranty?
A: All units sold by Konmask carry a 90-day functional warranty. Extended warranty and exchange programs are available — contact us for details.
