Process Control Solution – Schneider Electric 140XTS00200 | Modicon Quantum Series
In continuous process industries — refineries, chemical plants, water treatment facilities, and power generation stations — the analog output module is the final command link between the control system and the physical world. When this module fails or goes missing from a spare parts inventory, operators lose the ability to send precise 4–20 mA or 0–10 V signals to control valves, variable-speed drives, and positioners. The result: uncontrolled flow rates, pressure excursions, and in worst cases, emergency shutdowns that cost tens of thousands of dollars per hour. The Schneider Electric 140XTS00200 is the component that keeps that command chain intact.
The 140XTS00200 is a dedicated analog output module engineered for the Modicon Quantum platform — Schneider Electric’s flagship high-availability PLC/DCS architecture widely deployed in oil & gas, utilities, and heavy manufacturing worldwide. Within the Quantum family, the 140XTS series occupies the role of precision signal conditioning, delivering stable, noise-immune analog outputs that meet the exacting demands of safety-instrumented and process-critical loops. Its global installed base makes it one of the most specified analog output modules in brownfield plant maintenance and MRO procurement.
Technical Specifications
- Part Number: 140XTS00200
- Manufacturer: Schneider Electric
- Series: Modicon Quantum
- Module Type: Analog Output Module
- Platform Compatibility: Modicon Quantum PLC/DCS backplane
- Weight: 4,460 g (shipping weight)
- Country of Origin: France / EU manufacturing
Note: Detailed electrical specifications (channel count, output range, resolution, isolation) should be verified against the official Schneider Electric datasheet for 140XTS00200 prior to installation.
Where This Product Is Used
The 140XTS00200 is specified and deployed across a broad range of industrial environments where precise analog command signals are non-negotiable:
- Oil & Gas Upstream & Midstream: Wellhead control panels, pipeline SCADA systems, and compressor station automation — where control valve positioning accuracy directly impacts flow measurement and safety.
- Chemical & Petrochemical Plants: Reactor temperature and pressure loop control, where a stable 4–20 mA output to a control valve determines product quality and prevents runaway reactions.
- Water & Wastewater Treatment: Dosing pump speed control and valve modulation in filtration and disinfection stages, requiring reliable analog outputs 24/7.
- Power Generation: Turbine governor control and boiler feedwater regulation systems built on Modicon Quantum infrastructure.
- Automotive & Discrete Manufacturing: Paint line conveyor speed control and press force regulation integrated into Quantum-based machine controllers.
- Pharmaceutical Manufacturing: GMP-compliant process control loops for bioreactors and clean-in-place (CIP) systems.
Why Engineers Specify This Model
- Platform-Native Compatibility: Designed exclusively for the Modicon Quantum backplane — no adapter cards, no firmware workarounds, no integration risk.
- Proven Reliability in Harsh Environments: The Quantum series is rated for industrial temperature ranges and EMC environments, making the 140XTS00200 suitable for panel installations near heavy machinery.
- MRO Availability: As a long-lifecycle Schneider Electric product, the 140XTS00200 remains a critical spare part for plants with 10–20+ year Quantum system installations.
- Reduced Commissioning Time: Drop-in replacement for existing Quantum racks — no re-engineering of the control program required when replacing like-for-like.
- Global Support Ecosystem: Backed by Schneider Electric’s worldwide service network and extensive third-party MRO supplier base.
Complete System Bill of Materials
The 140XTS00200 operates within the Modicon Quantum ecosystem. A complete analog output subsystem typically includes:
- Quantum CPU Module — e.g., 140CPU65160 or 140CPU67160 for hot-standby configurations
- Quantum Backplane / Rack — e.g., 140XBP01600 (16-slot) or 140XBP00600 (6-slot)
- Power Supply Module — e.g., 140CPS11420 or 140CPS21400
- 140XTS00200 Analog Output Module — this unit
- Terminal Block / Field Wiring Adapter — compatible Quantum I/O terminal accessories
- Ethernet / Communication Module — e.g., 140NOE77101 for Modbus TCP/IP connectivity
Contact Konmask.com to source any of the above companion parts as a complete kit.
Compliance & Industry Standards
- CE Marking — EU Machinery and EMC Directives
- UL Listed — North American electrical safety
- IEC 61131-2 — Programmable controllers hardware requirements
- RoHS Compliant
- Designed for use in IEC 61511 / IEC 61508 process safety environments (consult SIL documentation for specific loop configurations)
Quality Assurance & Sourcing
At Konmask.com, every Schneider Electric 140XTS00200 unit we supply undergoes a structured verification process before shipment:
- Visual Inspection: Housing integrity, connector condition, and label authenticity checked against OEM references.
- Functional Verification: Where applicable, modules are bench-tested for basic power-on and communication response.
- Traceability Documentation: Each unit is accompanied by sourcing records to support your incoming inspection and audit requirements.
- Secure Packaging: ESD-safe anti-static bags and foam-lined cartons to prevent transit damage.
We supply both new-in-box OEM stock and professionally refurbished units — clearly identified at the time of quotation so you can make an informed procurement decision.
How to Source This Part
- Submit an Inquiry: Use the contact form on this page or email [email protected] with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and stock availability.
- Order Confirmation: Confirm your purchase order — we accept T/T bank transfer and other B2B payment terms.
- Shipment & Tracking: We ship globally via DHL, FedEx, and UPS with full tracking and export documentation.
- After-Sales Support: Our technical team remains available post-delivery for installation guidance and warranty queries.
Application-Specific FAQ
Q: Is the 140XTS00200 compatible with all Modicon Quantum rack sizes?
A: The 140XTS00200 is designed for the Modicon Quantum backplane family. Compatibility should be confirmed against your specific rack model and firmware version — contact us and we can assist with cross-referencing.
Q: Can this module be used as a direct replacement for an existing failed unit without reprogramming?
A: In most cases, yes — a like-for-like replacement of the 140XTS00200 in the same rack slot does not require changes to the PLC program. However, always verify the firmware version and module configuration parameters in Unity Pro or Concept software before hot-swapping.
Q: Do you supply new or refurbished units?
A: We supply both. All units are clearly identified as new-in-box or refurbished at the quotation stage. Refurbished units are tested and include a warranty period.
Q: What is the typical lead time for the 140XTS00200?
A: Lead time depends on current stock levels. In-stock units ship within 3–5 business days internationally. For urgent requirements, contact us directly for expedited options.
Q: Can Konmask.com supply the full Modicon Quantum system — not just this module?
A: Yes. We specialize in complete Quantum system sourcing including CPUs, power supplies, communication modules, and I/O cards. Submit a full BOM for a consolidated quote.
