Schneider 170ADO35000 Discrete Output Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 170ADO35000 is a discrete output module designed for the Modicon Quantum PLC platform. It provides reliable digital output control for industrial automation systems, offering robust performance in demanding manufacturing and process environments. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 170ADO35000 |
| Manufacturer | Schneider Electric |
| Series | Modicon Quantum |
| Module Type | Discrete Output Module |
| Output Points | 32 points |
| Output Voltage | 24 VDC |
| Output Current | 0.5 A per point |
| Output Type | Transistor (Sourcing) |
| Isolation | Optically isolated |
| Backplane Bus | Quantum I/O bus |
| Operating Temperature | 0°C to 60°C |
| Weight | 910 g |
| Certifications | CE, UL, cUL |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents for the 170ADO35000. Always verify electrical and firmware compatibility before substitution:
- 170ADO35001 – Revised revision of the same series; pin-compatible in most Quantum racks
- 170ADO54000 – Higher-density 64-point discrete output alternative for expanded I/O needs
- 140DDO35300 – Modicon Premium platform equivalent (requires rack/bus adapter)
- BMXDDO3202K – Modicon M340 platform equivalent for system migration projects
- TM5SDO12D – Modicon TM5 distributed I/O equivalent for decentralized architectures
Note: Cross-platform replacements may require configuration changes in Unity Pro / EcoStruxure Control Expert.
Why Choose the Original Model
- Proven platform stability – The Quantum series has decades of field-proven reliability in heavy industry
- Direct rack compatibility – No adapters or firmware changes required within the Quantum ecosystem
- Deterministic I/O response – Consistent scan-cycle performance critical for process control
- Full Schneider Electric support – Backed by global spare parts availability and technical documentation
- Regulatory compliance – CE, UL, and cUL certified for international deployment
Typical Applications
- Discrete control of solenoid valves, relays, and contactors in process plants
- Motor starter and drive enable/disable sequencing
- Conveyor and material handling system control
- Oil & gas wellhead and pipeline automation
- Water treatment and utilities SCADA integration
- Automotive assembly line PLC control panels
System Compatibility
- PLC Platform: Schneider Modicon Quantum (140-series racks)
- Software: Unity Pro, EcoStruxure Control Expert (v13.0+)
- Communication: Modbus TCP/IP, Modbus Plus via Quantum CPU
- Power Supply: 140CPS series Quantum power supplies
- Hot Standby: Compatible with Quantum Hot Standby redundancy configurations
Selection Guide
Use the criteria below to confirm the 170ADO35000 is the right module for your application, or to identify a suitable alternative:
- Output count needed ≤ 32 points at 24 VDC / 0.5 A: → 170ADO35000 is the optimal choice
- Output count needed > 32 points: → Consider 170ADO54000 (64-point)
- Migrating from Quantum to M340 platform: → Evaluate BMXDDO3202K with EcoStruxure migration tools
- Distributed I/O architecture required: → TM5SDO12D with CANopen or EtherNet/IP
- Relay output isolation required: → Consider 170ADO35300 (relay output variant)
- Budget-constrained retrofit: → Certified refurbished 170ADO35000 units available — contact us for stock
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Each module undergoes functional testing and visual inspection prior to shipment
- Original manufacturer packaging and documentation preserved where available
- Traceability records maintained for B2B procurement compliance
- Warranty: 90-day functional guarantee on all stocked units
How to Order
- Confirm your Quantum rack model and available slot position
- Verify firmware version compatibility with your CPU module
- Contact [email protected] or call +0086 19859288691 for stock availability and lead time
- Provide your PO number, shipping address, and any required certifications
- Receive order confirmation with tracking within 1 business day
Replacement & Compatibility FAQ
Q: Can the 170ADO35000 replace the 170ADO35001 directly?
A: In most cases yes — both are pin-compatible within Quantum racks. Verify the firmware revision of your CPU for any behavioral differences.
Q: Is the 170ADO35000 compatible with Modicon Premium racks?
A: No. The Quantum and Premium platforms use different backplane buses. Use the 140DDO35300 series for Premium systems.
Q: Can I use this module with EcoStruxure Control Expert?
A: Yes. The 170ADO35000 is fully supported in EcoStruxure Control Expert (formerly Unity Pro) v13.0 and later.
Q: Do you supply new or refurbished units?
A: We supply both. All units are tested and documented. Please specify your preference when ordering.
Q: What is the lead time for out-of-stock units?
A: Typical lead time is 3–10 business days depending on sourcing channel. Contact us for urgent requirements.
