Temperature Measurement Solution – Schneider Electric BMXART0814 | Modicon M340 BMX Series
Where This Product Is Used
The Schneider Electric BMXART0814 is an 8-channel analog input module designed for RTD (Resistance Temperature Detector) and thermocouple (TC) signals. It is widely deployed in environments where precise, multi-point temperature monitoring is critical:
- Process Manufacturing – Reactor temperature profiling in chemical and petrochemical plants
- Energy & Utilities – Boiler and turbine temperature monitoring in power generation facilities
- Food & Beverage – Pasteurization and sterilization process control requiring ±0.1°C accuracy
- HVAC & Building Automation – Multi-zone temperature acquisition in large commercial buildings
- Pharmaceutical – GMP-compliant temperature logging in cleanrooms and cold-chain storage
- Water Treatment – Monitoring heat exchangers and biological reactor temperatures
- Metal & Mining – Furnace and kiln temperature control using Type K/J thermocouples
Technical Specifications
| Part Number | BMXART0814 |
| Brand | Schneider Electric |
| Series | Modicon M340 (BMX) |
| Module Type | Analog Input – RTD / Thermocouple |
| Number of Channels | 8 (isolated) |
| Sensor Types Supported | Pt100, Pt1000, Ni100, Ni1000 (RTD); Type B, E, J, K, L, N, R, S, T, U (TC) |
| Resolution | 16-bit |
| Measurement Range | -200°C to +1820°C (sensor-dependent) |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Bus Interface | Modicon M340 backplane (X-Bus) |
| Power Consumption | ≤ 1.5 W (from backplane) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Weight | 180 g |
| Dimensions (H × W × D) | 100 × 30 × 73 mm (standard M340 single-slot) |
| Certifications | CE, UL, cUL, RoHS |
| Country of Origin | France / EU |
Why Engineers Specify This Model
- Universal Sensor Compatibility – Supports 10+ thermocouple types and 4 RTD variants in a single module, eliminating the need for separate signal conditioners.
- Channel-to-Channel Isolation – Prevents ground loops in multi-sensor installations, critical in high-noise industrial environments.
- 16-Bit Resolution – Delivers sub-degree accuracy for tight process control loops.
- Native M340 Integration – Plug-and-play on any Modicon M340 rack; auto-detected by Unity Pro / EcoStruxure Control Expert.
- Compact Single-Slot Form Factor – Maximizes rack density in space-constrained control panels.
- Open-Wire Detection – Built-in diagnostics flag broken sensor leads, reducing unplanned downtime.
Complete System Bill of Materials
A typical Modicon M340 temperature acquisition system using the BMXART0814 includes:
- CPU – BMXP342020 or BMXP3420302 (Ethernet + CANopen)
- Power Supply – BMXCPS2000 (100–240 VAC) or BMXCPS3500 (24 VDC)
- Rack – BMXXBP0400 (4-slot) / BMXXBP0800 (8-slot) / BMXXBP1200 (12-slot)
- This Module – BMXART0814 (8-ch RTD/TC analog input)
- Terminal Block – BMXFTB2000 (20-pin screw terminal) or BMXFTB2010 (spring-clamp)
- Connecting Cable – BMXFCA150 (1.5 m) or BMXFCA300 (3 m)
- Programming Software – EcoStruxure Control Expert (formerly Unity Pro) v14.0+
Compliance & Industry Standards
- IEC 61131-2 – Programmable controllers: equipment requirements and tests
- IEC 61000-4 series – EMC immunity (ESD, EFT, surge, conducted RF)
- EN 61010-1 – Safety requirements for electrical equipment for measurement and control
- UL 508 – Industrial control equipment (UL/cUL listed)
- RoHS 2011/65/EU – Restriction of hazardous substances
- CE Marking – EU Declaration of Conformity
Quality Assurance & Sourcing
All BMXART0814 units supplied by Konmask.com are:
- Sourced from authorized distributors or verified OEM channels with full traceability
- Inspected for authentic labeling, firmware version, and physical integrity prior to dispatch
- Shipped with original packaging and documentation where available
- Backed by our 90-day quality guarantee against defects in materials and workmanship
- Supported by our technical team for pre-sales compatibility verification
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly.
- Request a Quote – Email support@konmask.com for volume pricing or lead-time confirmation.
- Verify Compatibility – Share your M340 rack configuration and we will confirm fit before shipment.
- Expedited Sourcing – For urgent MRO needs, contact us via WhatsApp/WeChat: +0086 19859288691.
Application-Specific FAQ
Q: Can the BMXART0814 read both RTD and thermocouple sensors simultaneously?
A: Yes. Each of the 8 channels is independently configurable in software; you can mix RTD and TC sensor types on the same module.
Q: Is cold-junction compensation (CJC) built in for thermocouple measurements?
A: Yes. The module includes an internal CJC sensor, eliminating the need for external compensation hardware.
Q: Which version of EcoStruxure Control Expert is required?
A: Unity Pro v6.0 or later (EcoStruxure Control Expert v13.0+) is recommended for full diagnostic function block support.
Q: Can this module be used in a remote I/O drop (Ethernet or CANopen)?
A: The BMXART0814 is a local backplane module. For remote temperature acquisition, consider the STBAHI8321 (Advantys STB) or BMXNOE0100 with distributed I/O architecture.
Q: What is the maximum cable length for RTD sensors?
A: Schneider Electric recommends a maximum of 300 m for 3-wire Pt100 connections to maintain accuracy within specification.
Q: Is the BMXART0814 still in production?
A: This module is in the mature/maintained phase. Konmask.com maintains stock for MRO and system expansion needs. Contact us for long-term availability planning.
