Schneider Electric BMXAMI0810 High-Level Analog Input Module – Modicon M340 Series
Imagine a critical process line — a chemical dosing system, a high-speed packaging machine, or a water treatment facility — suddenly losing its analog signal feedback. Without a reliable analog input module, the PLC becomes blind: temperature readings vanish, pressure curves flatline, and flow rates go unmonitored. The result is unplanned downtime, product loss, and potential safety incidents. The Schneider Electric BMXAMI0810 exists precisely to prevent this scenario, delivering accurate, high-resolution analog signal acquisition that keeps your control system fully informed at all times.
Within the Modicon M340 ecosystem, the BMXAMI0810 occupies a pivotal position as the standard 8-channel high-level analog input module. It is engineered to interface directly with voltage and current transmitters — the most common signal types in global process industries — without requiring external signal conditioning. As part of Schneider Electric’s globally deployed Modicon M340 platform, this module is trusted by automation engineers across manufacturing, energy, water, and infrastructure sectors on every continent.
Technical Specifications
- Part Number / SKU: BMXAMI0810
- Brand: Schneider Electric
- Series: Modicon M340
- Module Type: High-Level Analog Input
- Number of Channels: 8 analog input channels
- Input Signal Types: Voltage (±10V, 0–10V, 1–5V) and Current (0–20mA, 4–20mA)
- Resolution: 12-bit + sign (13-bit)
- Isolation: Channel-to-backplane isolation
- Backplane Bus: Modicon M340 X-Bus
- Power Supply: Supplied via backplane (no external power required)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -25°C to +70°C
- Relative Humidity: 5% to 95% non-condensing
- Weight: Approx. 120 g
- Certifications: CE, UL, cUL
- Form Factor: Single-slot M340 rack module
Note: All specifications are sourced from Schneider Electric official documentation. Contact us to verify the latest datasheet revision.
Key Features & Benefits
- 8 Independent High-Level Analog Channels: Simultaneously acquire signals from 8 field transmitters, maximizing rack density and reducing wiring complexity.
- Universal Voltage & Current Input: Configurable per channel for ±10V or 0–20mA/4–20mA, eliminating the need for separate modules for different signal types.
- High Resolution (13-bit): Delivers precise process variable measurement critical for PID control loops and quality-sensitive applications.
- Plug-and-Play Integration: Recognized automatically by Unity Pro / EcoStruxure Control Expert software — no manual address configuration required.
- Robust Industrial Design: Conformal coating and wide temperature tolerance ensure reliable operation in harsh factory environments.
- Compact Single-Slot Form Factor: Optimizes rack space in space-constrained control panels.
- Diagnostics & Fault Detection: Built-in over-range, under-range, and wire-break detection with status reporting to the CPU.
Industry & Equipment Applications
- Process Manufacturing: Chemical, pharmaceutical, and food & beverage plants using 4–20mA transmitters for temperature, pressure, and flow.
- Water & Wastewater Treatment: Monitoring dissolved oxygen, pH, turbidity, and pump flow rates.
- Energy & Power Generation: Analog feedback from generators, transformers, and grid monitoring equipment.
- Building Automation (HVAC): Integrating temperature and humidity sensors into M340-based BMS systems.
- Packaging & Material Handling: Speed and tension feedback from servo drives and variable frequency drives (VFDs).
- Oil & Gas: Wellhead pressure and flow monitoring in remote RTU/PLC installations.
System Integration & Compatible Parts
The BMXAMI0810 is designed exclusively for the Modicon M340 platform. Ensure compatibility with the following system components:
- CPUs: BMX P34 1000 / BMX P34 2000 / BMX P34 2010 / BMX P34 2020 / BMX P34 2030
- Power Supplies: BMX CPS 2000 / BMX CPS 3500 / BMX CPS 3020
- Racks: BMX XBP 0400 / BMX XBP 0800 / BMX XBP 1200
- Programming Software: EcoStruxure Control Expert (formerly Unity Pro) v11.0+
- Related I/O Modules: BMXAMO0410 (Analog Output), BMXDDI1602 (Digital Input), BMXDDO1602 (Digital Output)
- Terminal Blocks: BMXFTB2800 (28-pin screw terminal block for analog modules)
Our Quality Assurance Process
At Konmask.com, every BMXAMI0810 unit undergoes a rigorous multi-stage verification process before shipment:
- Source Verification: Units are sourced exclusively from authorized distributors and verified OEM channels to eliminate counterfeit risk.
- Visual Inspection: Each module is inspected for physical integrity — label authenticity, connector condition, and housing integrity.
- Functional Pre-Check: Where applicable, modules are bench-tested for basic power-on and communication response.
- Secure Packaging: Anti-static ESD packaging with moisture barrier bags and shock-absorbing foam inserts.
- Documentation: Certificate of conformity and traceability documentation available upon request.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm the order with a purchase order (PO) or advance payment per agreed terms.
- Track your shipment with the provided logistics reference number.
We support DHL, FedEx, UPS, and sea freight for global delivery. Export documentation (commercial invoice, packing list, COO) is provided as standard.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, HMI, and automation components — not a generalist marketplace.
- ✅ Global B2B Supply: Serving engineering firms, system integrators, and MRO teams in 50+ countries.
- ✅ Fast Inquiry Response: Dedicated technical sales team responds within 24 hours.
- ✅ Competitive Pricing: Direct sourcing relationships enable competitive pricing on both new and refurbished stock.
- ✅ Traceability & Authenticity: Full supply chain documentation available for compliance-sensitive projects.
- ✅ Long-Term Partnership: We support your project from initial BOM inquiry through to after-sales technical assistance.
Frequently Asked Questions
Q: Is the BMXAMI0810 compatible with the Modicon M580 platform?
A: No. The BMXAMI0810 is designed exclusively for the Modicon M340 backplane (X-Bus). For M580 systems, the equivalent module is the BMEAHI0812.
Q: Can I mix voltage and current inputs on the same BMXAMI0810 module?
A: Yes. Each channel is independently configurable for voltage or current input via software in EcoStruxure Control Expert, without hardware jumper changes.
Q: Do you supply new, refurbished, or surplus units?
A: We supply both new (factory-sealed) and tested refurbished units. The condition is clearly stated in the quotation. All units pass our QA process regardless of condition.
Q: What is the typical lead time for BMXAMI0810?
A: In-stock units ship within 3–5 business days. For larger quantities or special sourcing, lead time is typically 2–4 weeks. Contact us for current stock status.
Q: Can you provide the official Schneider Electric datasheet?
A: Yes. The BMXAMI0810 datasheet and installation guide are available upon request. Contact support@konmask.com.
Q: What warranty do you offer?
A: We offer a 90-day warranty on all units covering manufacturing defects and functional failures under normal operating conditions.
