Motor Starter Configuration Solution – Schneider Electric CA3-USBCB-01 | TeSys U Series
Where This Product Is Used
The Schneider Electric CA3-USBCB-01 is the dedicated USB-to-serial data transfer cable engineered for TeSys U motor starters (LUCA, LUCB, LUCC, LUCD, LUCE, LUCF, LUCM multifunction control units). It bridges a standard PC USB port to the RJ45 communication port on TeSys U control units, enabling engineers and commissioning technicians to upload, download, and archive motor protection parameters without manual DIP-switch adjustment.
- OEM production lines requiring repeatable motor protection setups across multiple starters
- Panel builders pre-configuring TeSys U units before cabinet delivery
- Maintenance teams performing predictive diagnostics and parameter backup on installed starters
- System integrators commissioning conveyor, pump, fan, and compressor drives in process plants
- MRO departments replacing failed control units and restoring saved parameter profiles
Technical Specifications
| Part Number | CA3-USBCB-01 |
| Brand | Schneider Electric |
| Series | TeSys U Accessories |
| Cable Type | USB-A to RJ45 Data Transfer Cable |
| Compatible Control Units | LUCA•, LUCB•, LUCC•, LUCD•, LUCE•, LUCF•, LUCM• (TeSys U) |
| PC Interface | USB Type-A (USB 1.1 / 2.0 compatible) |
| Device Interface | RJ45 (8P8C) |
| Software | PowerSuite / SoMove (Schneider Electric, free download) |
| OS Support | Windows 7 / 8 / 10 / 11 (driver required) |
| Cable Length | Approx. 1.5 m |
| Weight | 180 g |
| Country of Origin | China |
| Schneider Reference | CA3USBCB01 |
Why Engineers Specify This Model
- OEM-matched interface: RJ45 plug mates directly with TeSys U control unit port — no adapters, no pin-out guesswork.
- Parameter archiving: Save and restore full motor protection profiles (FLA, trip class, phase-loss sensitivity) in seconds via SoMove software.
- Eliminates manual DIP-switch errors: Software-driven configuration reduces commissioning errors on high-volume panel builds.
- Plug-and-play USB driver: Installs automatically on modern Windows systems; no proprietary interface card required.
- Compact and portable: Lightweight 180 g form factor fits in a technician’s tool bag for field service calls.
- Genuine Schneider Electric accessory: Ensures full compatibility and warranty compliance with TeSys U control units.
Complete System Bill of Materials
For a fully configured TeSys U motor starter system with PC programming capability, engineers typically specify:
- CA3-USBCB-01 – This USB programming cable
- LUCA•E / LUCB•BL / LUCM•BL – TeSys U multifunction control unit (select current rating)
- LUB• – TeSys U power base (12 A, 32 A, or 38 A)
- LUFA• – Fault relay module (optional, for remote fault signaling)
- LU9M10 – Communication module for Modbus/CANopen (if network integration required)
- SoMove Software – Free PC configuration tool (Schneider Electric download portal)
Compliance & Industry Standards
- Designed for use with TeSys U products compliant with IEC 60947-4-1 (Low-voltage switchgear – contactors and motor starters)
- USB interface compliant with USB 2.0 specification
- RoHS compliant
- CE marked (as part of Schneider Electric TeSys U accessory range)
Quality Assurance & Sourcing
Konmask.com sources the CA3-USBCB-01 exclusively through verified Schneider Electric authorized distribution channels. Every unit is inspected for:
- Authentic Schneider Electric labeling and holographic security markings
- Intact RJ45 and USB connector housings with no pin damage
- Original factory packaging with part number and batch traceability
We maintain traceability documentation available upon request for quality-audited procurement processes.
How to Source This Part
- Add to cart directly on this page for standard orders.
- Request a quote for volume orders (10+ units) — contact [email protected] for tiered pricing.
- Lead time: In-stock units ship within 1–3 business days. Out-of-stock lead time is 7–15 business days via air freight.
- Export documentation (CO, packing list, commercial invoice) provided for international shipments.
Application-Specific FAQ
Q: Is CA3-USBCB-01 compatible with TeSys D or TeSys K starters?
A: No. This cable is designed exclusively for the TeSys U series control units. TeSys D and TeSys K use different communication interfaces.
Q: Which software do I need to use with this cable?
A: Schneider Electric’s SoMove (successor to PowerSuite) is the recommended free configuration tool. Download it from the Schneider Electric software portal.
Q: Do I need to install a driver?
A: Yes. A USB-to-serial driver (typically CP210x or similar) is required. It is included with SoMove installation or available from the chip manufacturer’s website.
Q: Can I use this cable to monitor live motor data?
A: Yes. SoMove supports real-time monitoring of current, thermal state, and trip history when connected via CA3-USBCB-01.
Q: Is this cable suitable for ATEX/hazardous area use?
A: No. The CA3-USBCB-01 is a standard industrial accessory not rated for hazardous area classification. Disconnect power before connecting in any environment.
