Schneider TSXMFPP224K Flash EPROM Memory Extension | Replacement, Equivalent & Selection Guide
The Schneider Electric TSXMFPP224K is a 224 KB Flash EPROM application memory extension module designed for the TSX Premium PLC series. This page provides a comprehensive selection guide, compatible replacement models, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Part Number | TSXMFPP224K |
| Brand | Schneider Electric |
| Series | TSX Premium |
| Memory Type | Flash EPROM (Non-volatile) |
| Memory Capacity | 224 KB Application Memory |
| Module Function | Application Memory Extension |
| Compatible CPU | TSX P57 / TSX P47 Premium Series |
| Form Factor | Plug-in PCMCIA-style memory card |
| Data Retention | 10+ years without power |
| Weight | 44 g |
| Operating Temperature | 0°C to +60°C |
Compatible Replacement & Equivalent Models
When the TSXMFPP224K is unavailable or discontinued, the following models may serve as functional equivalents or upgrades. Always verify compatibility with your specific CPU firmware version before substitution.
| Model | Capacity | Type | Compatibility Note |
|---|---|---|---|
| TSXMFPP112K | 112 KB | Flash EPROM | Lower capacity; same form factor |
| TSXMFPP384K | 384 KB | Flash EPROM | Higher capacity upgrade option |
| TSXMFPP512K | 512 KB | Flash EPROM | Maximum capacity for TSX Premium |
| TSXMRPP224K | 224 KB | RAM + Battery | RAM alternative; requires battery backup |
Note: Konmask.com recommends using the original TSXMFPP224K for guaranteed compatibility. Contact our team for cross-reference verification.
Why Choose the Original TSXMFPP224K
- Guaranteed Compatibility: Factory-validated for TSX Premium P57/P47 CPUs — no firmware risk.
- Non-Volatile Flash: Retains application program without battery, unlike RAM-based alternatives.
- Proven Reliability: Widely deployed in manufacturing, utilities, and process control globally.
- OEM Traceability: Original Schneider Electric part with full documentation and CE/UL compliance.
- Long Data Retention: 10+ years of data retention ensures program integrity during extended shutdowns.
Typical Applications
- Application program storage and backup for TSX Premium PLCs
- Memory expansion in high-complexity automation sequences
- Redundant program storage in critical process control systems
- Factory automation: automotive assembly, food & beverage, packaging lines
- Infrastructure: water treatment, power distribution, building management
- OEM machine builders requiring extended memory for large ladder/function block programs
System Compatibility
The TSXMFPP224K is compatible with the following Schneider Electric TSX Premium CPU modules:
- TSX P57 103 / 153 / 203 / 253 / 303 / 353 / 453 / 553
- TSX P57 2623 / 2823 / 3623 / 4823 / 5623
- TSX P47 100 / 200
Always cross-reference your CPU’s hardware manual (Schneider Ref. 35006144) to confirm memory slot specifications before ordering.
Selection Guide
Use the following criteria to select the right memory module for your TSX Premium system:
- Program Size: Estimate your application’s instruction count. 224 KB supports approximately 14,000–16,000 instructions depending on data types used.
- Memory Type: Choose Flash EPROM (TSXMFPP) for battery-free retention; choose RAM (TSXMRPP) only if frequent in-system reprogramming is required.
- Upgrade Path: If your program is approaching 80% of 224 KB capacity, consider the TSXMFPP384K or TSXMFPP512K for headroom.
- Budget vs. Risk: Third-party equivalents may reduce cost but introduce firmware compatibility risks — consult Konmask.com for verified sourcing.
Quality Assurance & Sourcing
- ✅ Genuine Parts Only: All TSXMFPP224K units sourced from authorized Schneider Electric distribution channels or verified OEM surplus.
- ✅ Pre-Shipment Inspection: Each module inspected for physical integrity, label authenticity, and packaging condition.
- ✅ Traceability Documentation: Certificate of conformity and sourcing records available upon request.
- ✅ Secure Packaging: Anti-static ESD packaging with moisture barrier for safe international transit.
- ✅ Warranty: 12-month warranty against manufacturing defects.
How to Order
- Confirm Part Number: Verify TSXMFPP224K matches your CPU’s memory slot specification.
- Request a Quote: Contact [email protected] for volume pricing, lead time, and availability.
- Place Order: Add to cart directly or submit a purchase order via email.
- Shipping: DHL / FedEx / UPS express worldwide. Typical lead time: 3–7 business days.
- After-Sales: Technical support available for installation and compatibility questions.
Replacement & Compatibility FAQ
Q: Can I use TSXMFPP384K as a direct replacement for TSXMFPP224K?
A: Yes, in most cases. The TSXMFPP384K is a higher-capacity Flash EPROM with the same form factor. Verify your CPU firmware supports the larger module before substituting.
Q: Is TSXMRPP224K a compatible replacement?
A: It has the same capacity but uses RAM technology requiring a battery. It is not a like-for-like replacement — Flash EPROM is preferred for battery-free operation.
Q: Can third-party memory modules be used in TSX Premium PLCs?
A: Schneider Electric does not officially support third-party memory modules. Konmask.com recommends genuine OEM parts to avoid compatibility and warranty issues.
Q: How do I know if my TSXMFPP224K is genuine?
A: Genuine modules feature Schneider Electric holographic labels, OEM part markings, and come with traceable documentation. Contact us if you need authenticity verification.
Q: Do you offer cross-reference support for other Schneider memory modules?
A: Yes. Email [email protected] with your CPU model and program size for a free selection recommendation.
