Schneider Electric 140XTS00200 – Terminal Strip for Modicon Quantum I/O Modules | Quantum PLC Platform
Engineering Background
The Modicon Quantum series represents Schneider Electric’s flagship rack-based PLC platform, engineered for mission-critical process automation in industries where signal integrity and wiring reliability are non-negotiable. The 140XTS00200 Terminal Strip is a dedicated field-wiring accessory designed to interface directly with Quantum I/O modules, providing a structured, labeled, and mechanically secure termination point for field cables.
Product Positioning
Procurement engineers specifying Modicon Quantum systems require OEM-matched accessories to maintain system certification, reduce commissioning time, and ensure long-term serviceability. The 140XTS00200 eliminates improvised wiring solutions and ensures every field connection meets Schneider Electric’s original design intent — critical for SIL-rated and high-availability installations.
Complete Technical Specifications
- Part Number / SKU: 140XTS00200
- Manufacturer: Schneider Electric (Modicon)
- Product Family: Modicon Quantum PLC Accessories
- Type: Terminal Strip / Field Wiring Accessory
- Compatible Platform: Modicon Quantum I/O Modules (140 Series)
- Mounting: Direct plug-in to Quantum I/O module connector
- Weight: 180 g
- Country of Origin: France / EU (OEM)
- Condition: New / Surplus New
Proven Application Environments
- Oil & Gas process control panels (DCS/PLC hybrid architectures)
- Power generation and utilities SCADA systems
- Automotive and heavy manufacturing assembly lines
- Water treatment and municipal infrastructure automation
- Chemical plant distributed I/O cabinets
- Railway signaling and transportation control systems
Engineering Advantages
- OEM Fit & Form: Designed exclusively for Modicon Quantum I/O modules — no adapter or modification required.
- Structured Wiring: Pre-numbered terminal positions reduce field wiring errors and accelerate commissioning.
- Mechanical Reliability: Robust connector housing withstands industrial vibration and thermal cycling.
- Serviceability: Field-replaceable without removing the I/O module from the rack, minimizing downtime.
- Certification Compliance: Maintains system-level CE, UL, and cUL certifications when used with matched Quantum modules.
System Architecture & Signal Flow
In a Modicon Quantum rack, field signals enter the system through the 140XTS00200 terminal strip, which plugs directly into the front-face connector of the corresponding 140 Series I/O module. The terminal strip provides screw-clamp or spring-clamp termination points (depending on variant) for field cables, routing analog or digital signals through the module’s internal circuitry to the Quantum backplane bus, and ultimately to the CPU (e.g., 140CPU65160) for processing. This architecture ensures a clean, documented signal path from field device to controller logic.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified surplus channels.
- Physical inspection performed: housing integrity, connector pin condition, label legibility.
- Serialization and date codes verified against Schneider Electric manufacturing records where applicable.
- Counterfeit-risk screening applied per IEC 62239 supply chain best practices.
- Packaging: anti-static bag + foam-lined carton for transit protection.
Procurement Process
- Step 1: Confirm compatibility with your specific Quantum I/O module part number.
- Step 2: Submit RFQ or place order directly via Konmask.com product page.
- Step 3: Receive order confirmation and lead-time estimate within 1 business day.
- Step 4: Shipment with tracking; DHL / FedEx / UPS international express available.
- Step 5: Post-delivery technical support available via email or phone.
Technical FAQ
Q: Is the 140XTS00200 compatible with all Modicon Quantum I/O modules?
A: It is designed for specific 140 Series I/O modules. Please confirm your module’s part number with our technical team before ordering.
Q: Can this terminal strip be used with Modicon Premium or M340 platforms?
A: No. The 140XTS00200 is exclusively designed for the Modicon Quantum (140 Series) platform. Different platforms use different connector standards.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC documentation is available upon request for qualified orders.
Q: What is the lead time for bulk orders?
A: Standard stock orders ship within 3–5 business days. For bulk or project quantities, contact us for a dedicated lead-time commitment.
Q: Is this a new or refurbished part?
A: We stock both new and surplus-new (unused, original packaging) units. Condition is specified at time of quotation.
