Schneider Electric 170AAI14000 Analog Input Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 170AAI14000 is a 16-channel analog input module designed for the Modicon Momentum distributed I/O platform. It accepts voltage (0–10 V) and current (4–20 mA) signals, making it a versatile choice for process monitoring in industrial automation systems. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers source the right module with confidence.
Technical Specifications
- Part Number: 170AAI14000
- Brand: Schneider Electric (Modicon)
- Series: Modicon Momentum
- Module Type: Analog Input
- Number of Channels: 16
- Input Signal Types: 0–10 V DC / 4–20 mA
- Resolution: 12-bit
- Isolation: Non-isolated between channels
- Backplane Bus: Modicon Momentum I/O bus
- Operating Temperature: 0 °C to 60 °C
- Storage Temperature: –40 °C to 85 °C
- Power Consumption: Supplied via Momentum adapter
- Weight: 220 g
- Certifications: CE, UL, cUL
- Mounting: DIN rail via Momentum adapter (e.g., 170ANR12090)
Compatible Replacement & Equivalent Models
When the 170AAI14000 is discontinued, hard to source, or requires a cost-effective alternative, the following models are commonly evaluated:
- 170AAI03000 – Schneider Electric Momentum 8-channel analog input (voltage/current); half the channel count, direct platform fit
- 170AAI14000C – Conformal-coated variant of the 170AAI14000 for harsh environments
- BMXAMI0810 – Modicon M340 8-channel analog input; requires M340 rack, not a drop-in replacement
- TSXAEY1600 – Modicon Premium 16-channel analog input; different platform, requires adapter evaluation
- Siemens 6ES7331-7KF02-0AB0 – S7-300 8-channel AI; cross-brand alternative requiring full system re-evaluation
- Allen-Bradley 1756-IF16 – ControlLogix 16-channel analog input; cross-brand, high-performance alternative
Note: Cross-brand replacements require full compatibility assessment of bus architecture, power supply, and software configuration before deployment.
Why Choose the Original Model
- Platform Native: Designed exclusively for Modicon Momentum — zero integration risk on existing Momentum systems
- Proven Reliability: Widely deployed in process industries with a long field track record
- Software Compatibility: Fully supported by Unity Pro, Concept, and ProWORX programming environments
- Spare Parts Ecosystem: Broad availability of compatible adapters, cables, and accessories
- Regulatory Compliance: CE, UL, cUL certified for global deployment
Typical Applications
- Process temperature and pressure monitoring via 4–20 mA transmitters
- Flow measurement in water treatment and chemical plants
- Level sensing in tank farms and storage facilities
- Multi-loop PID control in HVAC and building automation
- Distributed I/O nodes in large-scale manufacturing lines
- Oil & gas field instrumentation panels
System Compatibility
- Platform: Modicon Momentum distributed I/O
- Compatible Adapters: 170ANR12090 (Ethernet), 170ANR23090 (Modbus Plus), 170ANR12091 (Ethernet w/ web server)
- Programming Software: Unity Pro XL / L / S, Concept 2.6+, ProWORX 32
- Communication Protocols: Modbus TCP/IP, Modbus Plus, INTERBUS (adapter-dependent)
- Not Compatible With: Modicon M340, M580, Quantum racks (different backplane architecture)
Selection Guide
Use the following criteria to confirm the 170AAI14000 is the right module for your application:
- Channel Count: Do you need 16 analog input channels? If 8 channels suffice, consider 170AAI03000 to reduce cost.
- Signal Type: Confirm field devices output 0–10 V or 4–20 mA. For thermocouple or RTD inputs, evaluate 170AAI52040 (TC) or 170AAI52000 (RTD) instead.
- Environment: Standard industrial environment → 170AAI14000. Corrosive or high-humidity environment → 170AAI14000C (conformal coat).
- Platform: Existing Momentum system → 170AAI14000 is the direct fit. Migrating to M340 or M580 → consult Schneider migration guides for BMXAMI or BMXAMI0810 equivalents.
- Resolution Requirement: 12-bit resolution is sufficient for most process control. If 16-bit is required, evaluate BMXAMI0810 on M340 platform.
Quality Assurance & Sourcing
- Authenticity: All units sourced through verified industrial distribution channels. Batch traceability available on request.
- Condition: New (factory sealed) and tested surplus stock available. Condition clearly stated per order.
- Inspection: Pre-shipment functional verification available for critical orders.
- Warranty: 12-month warranty against manufacturing defects on new units.
- Lead Time: In-stock units ship within 1–3 business days. Contact us for bulk order lead times.
How to Order
- Confirm your part number: 170AAI14000
- Specify quantity and required condition (new / surplus tested)
- Provide your shipping destination for freight quote
- Contact us via email or phone — we respond within 24 hours on business days
- Payment: T/T bank transfer, PayPal, or trade terms for qualified accounts
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Is the 170AAI14000 still in production?
A: Schneider Electric has transitioned the Momentum platform to end-of-life. New production has ceased, but surplus and refurbished stock remain available. Contact us for current availability.
Q: Can I replace 170AAI14000 with a Modicon M340 module?
A: No direct drop-in replacement exists. M340 modules use a different rack and backplane. A platform migration project is required.
Q: What is the difference between 170AAI14000 and 170AAI14000C?
A: The “C” suffix denotes a conformal-coated PCB for protection against moisture, dust, and corrosive atmospheres. Electrically and functionally identical.
Q: Does the 170AAI14000 support HART protocol?
A: No. The 170AAI14000 does not support HART pass-through. For HART-enabled analog input on Momentum, evaluate third-party HART multiplexers.
Q: What adapter is required to use this module?
A: A Momentum communication adapter is required (e.g., 170ANR12090 for Ethernet/Modbus TCP). The I/O module alone cannot operate without an adapter.
