Industrial Automation Solution – Schneider Electric 171CCC76010 | Modicon Quantum
Where This Product Is Used
The Schneider Electric 171CCC76010 Processor Adaptor is a critical interface component within the Modicon Quantum PLC platform, designed for demanding industrial environments. Engineers and system integrators specify this adaptor across the following application scenarios:
- Oil & Gas Process Control – Connects Quantum processors in upstream/downstream SCADA and DCS architectures where high-availability redundancy is mandatory.
- Power Generation & Utilities – Deployed in substation automation and turbine control panels requiring IEC 61131-3 compliant PLC backplanes.
- Automotive Manufacturing – Integrated into body-in-white (BIW) assembly lines and paint shop conveyor control systems for deterministic I/O response.
- Water & Wastewater Treatment – Used in pump station controllers and SCADA-linked remote terminal units (RTUs) for continuous process monitoring.
- Chemical & Pharmaceutical Plants – Supports SIL-rated safety instrumented systems (SIS) where processor-to-backplane integrity is mission-critical.
- Building Management Systems (BMS) – Facilitates HVAC, fire suppression, and energy management integration via Modbus TCP/IP and Ethernet I/O.
Technical Specifications
| Part Number | 171CCC76010 |
| Manufacturer | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Module Type | Processor Adaptor |
| Backplane Compatibility | Modicon Quantum Backplane (140 Series) |
| Communication Interface | Modbus Plus / Ethernet (platform-dependent) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | 80 g |
| Certifications | CE, UL, cUL |
| Country of Origin | France / EU |
Why Engineers Specify This Model
- Seamless Processor Integration – Provides a direct, low-latency physical and electrical bridge between Quantum CPUs and the backplane bus, eliminating signal degradation in high-cycle environments.
- Hot-Swap Ready Architecture – Supports Quantum platform’s hot-standby redundancy configurations, minimizing unplanned downtime in 24/7 production facilities.
- Proven Field Reliability – Modicon Quantum is one of the most widely deployed PLC platforms globally, with a 20+ year installed base in critical infrastructure.
- Backward Compatibility – Compatible with legacy Quantum rack configurations, protecting existing capital investment during system upgrades.
- Simplified Maintenance – Tool-free module extraction and clear labeling reduce MTTR (Mean Time to Repair) during field service operations.
Complete System Bill of Materials
For a complete Modicon Quantum control system, the 171CCC76010 is typically specified alongside:
- 140CPU65150 – Modicon Quantum Unity CPU, 1 MB, Ethernet
- 140XBP01600 – 16-Slot Quantum Backplane
- 140CPS11420 – Quantum Power Supply, 115/230 VAC
- 140DAI54000 – Discrete Input Module, 32-channel, 24 VDC
- 140DAO84000 – Discrete Output Module, 32-channel, 24 VDC
- 140ACI04000 – Analog Input Module, 4-channel, 4–20 mA
- 140NOE77101 – Ethernet TCP/IP Communication Module
Compliance & Industry Standards
- IEC 61131-2 – Programmable Controllers: Equipment Requirements and Tests
- IEC 61131-3 – PLC Programming Languages (Ladder, FBD, ST, IL, SFC)
- CE Marking – EU Low Voltage Directive & EMC Directive compliance
- UL 508 / cUL – Industrial Control Equipment (North America)
- RoHS Directive 2011/65/EU – Restriction of Hazardous Substances
- ISO 9001:2015 – Schneider Electric Quality Management System
Quality Assurance & Sourcing
At Konmask.com, every Schneider Electric 171CCC76010 unit is:
- ✅ Sourced from authorized distributors or verified surplus channels with full traceability
- ✅ Inspected for physical integrity, label authenticity, and firmware version consistency
- ✅ Tested for backplane connector pin integrity prior to dispatch
- ✅ Packaged in anti-static ESD-safe materials with moisture barrier protection
- ✅ Shipped with a certificate of conformance (CoC) available upon request
How to Source This Part
- Add to Cart – Click the purchase button above to place your order directly online.
- Request a Quote – For bulk orders (>5 units) or project-based procurement, email support@konmask.com for volume pricing.
- Expedited Shipping – DHL Express, FedEx International Priority, and UPS Worldwide available. Typical lead time: 3–7 business days.
- Technical Pre-Sales Support – Our engineers can verify compatibility with your existing Quantum rack configuration before purchase.
Application-Specific FAQ
Q: Is the 171CCC76010 compatible with all Modicon Quantum CPU modules?
A: It is designed for use within the Modicon Quantum platform. Please confirm your specific CPU part number with our technical team to ensure backplane slot compatibility.
Q: Can this adaptor be used in a hot-standby redundancy configuration?
A: Yes. The Modicon Quantum platform supports hot-standby CPU redundancy, and this adaptor is compatible with those configurations when paired with the appropriate redundancy modules.
Q: What is the warranty on this part?
A: Konmask offers a 90-day functional warranty on all tested components. Extended warranty options are available — contact us for details.
Q: Do you provide documentation or wiring diagrams?
A: Yes. Schneider Electric’s official installation guide and Quantum hardware reference manual are available upon request with your order.
Q: Is this part RoHS compliant?
A: Schneider Electric’s Modicon Quantum series is manufactured in compliance with RoHS Directive 2011/65/EU. Please request the declaration of conformity if required for your project documentation.
