Schneider Electric BMXAMO0410 Analog Output Module | Replacement, Equivalent & Selection Guide
The Schneider Electric BMXAMO0410 is a 4-channel analog output module designed for the Modicon M340 PLC platform. It delivers precise voltage and current signal outputs for process control, drive control, and industrial automation applications. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Part Number: BMXAMO0410
- Manufacturer: Schneider Electric
- Series: Modicon M340
- Module Type: Analog Output
- Number of Channels: 4
- Output Signal: ±10 V / 0–20 mA / 4–20 mA (configurable per channel)
- Resolution: 12-bit (voltage), 12-bit (current)
- Isolation: Non-isolated between channels; isolated from bus
- Update Time: ≤ 1 ms per channel
- Power Supply: 24 VDC (from backplane)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -25°C to +70°C
- Humidity: 5–95% RH (non-condensing)
- Mounting: Modicon M340 backplane (BMX XBP series)
- Weight: ~160 g
- Certifications: CE, UL, cUL, IEC 61131-2
- Communication: Via M340 backplane bus (X-Bus)
Compatible Replacement & Equivalent Models
The following modules are verified compatible replacements or functional equivalents for the BMXAMO0410. Always confirm backplane compatibility and firmware version before substitution.
| Model | Manufacturer | Channels | Output Type | Compatibility Notes |
|---|---|---|---|---|
| BMXAMO0410 | Schneider Electric | 4 | V / mA | Original OEM — direct fit |
| BMXAMO0800 | Schneider Electric | 8 | V / mA | Upgrade option; same platform, double channels |
| BMXAMO0410H | Schneider Electric | 4 | V / mA | ATEX/hazardous-area variant |
| 140AVO02000 | Schneider Electric | 4 | V | Quantum platform — not pin-compatible; functional reference |
| 1756-OF4 | Allen-Bradley (Rockwell) | 4 | V / mA | Cross-brand equivalent; requires ControlLogix rack |
| 6ES7135-4GB01-0AB0 | Siemens | 4 | V / mA | ET 200S platform equivalent; not physically compatible |
⚠ Note: Cross-brand replacements require re-engineering of I/O mapping and software configuration. Consult your system integrator before substitution.
Why Choose the Original Model
- Guaranteed Backplane Compatibility: Designed exclusively for Modicon M340 BMX XBP backplanes — zero integration risk.
- Unity Pro / EcoStruxure Machine Expert Native Support: Full diagnostic, configuration, and firmware update support without third-party drivers.
- Proven Field Reliability: Widely deployed in water treatment, oil & gas, and discrete manufacturing since 2006.
- Schneider Electric Lifecycle Support: Active product with available spare parts, firmware updates, and technical documentation.
- Regulatory Compliance: CE, UL, cUL certified — meets IEC 61131-2 for industrial environments.
Typical Applications
- Analog setpoint control for variable-speed drives (VFDs)
- Process control loops (flow, pressure, temperature, level)
- Valve positioner control (4–20 mA)
- SCADA/DCS interface signal generation
- Conveyor and packaging line speed reference
- Water & wastewater treatment plant automation
- Building management systems (BMS) integration
System Compatibility
- PLC Platform: Modicon M340 (BMX series)
- Backplane: BMX XBP 0400 / 0800 / 1200 / 2000
- Power Supply: BMX CPS series (24 VDC or 100–240 VAC)
- CPU Compatibility: BMX P34 1000 / 2000 / 2010 / 2020 / 2030
- Programming Software: Unity Pro v2.0+, EcoStruxure Machine Expert
- Communication Protocols: Modbus TCP/IP, CANopen, Ethernet I/O (via CPU)
- Not Compatible With: Modicon Premium (TSX), Modicon Quantum (140), Modicon M580 (BMENOC)
Selection Guide
Use the criteria below to confirm BMXAMO0410 is the right module for your application:
- Channel Count: Need 4 analog outputs? → BMXAMO0410. Need 8? → Consider BMXAMO0800.
- Signal Type: Requires both voltage (±10 V) and current (4–20 mA) outputs? → BMXAMO0410 supports both per channel.
- Hazardous Area: ATEX Zone 2 required? → Select BMXAMO0410H instead.
- Platform: Running Modicon M340? → BMXAMO0410 is the native fit. Running M580? → Evaluate BMEAHO0412.
- Budget vs. OEM: Refurbished units available — confirm warranty and test certification before purchase.
- Spare Parts Strategy: For critical lines, stock at least one spare BMXAMO0410 to minimize downtime risk.
Quality Assurance & Sourcing
- ✅ New OEM Stock: Factory-sealed units with full Schneider Electric warranty
- ✅ Refurbished / Tested: Professionally reconditioned with functional test report available on request
- ✅ Traceability: All units supplied with batch/lot documentation
- ✅ Anti-Counterfeit: Sourced from authorized distributors and verified supply chains only
- ✅ Inspection: Pre-shipment visual and electrical inspection standard on all orders
- ✅ Packaging: ESD-safe packaging with humidity indicator card
How to Order
- Confirm your Modicon M340 backplane model and available slot count.
- Verify CPU firmware version supports BMXAMO0410 (Unity Pro v2.0+ recommended).
- Select stock type: New OEM, Refurbished, or Exchange.
- Contact us via the form below or email support@konmask.com with your PO or RFQ.
- Receive quotation within 1 business day. Lead time: 1–5 business days for in-stock units.
📦 Shipping: DHL / FedEx / SF Express worldwide. Export documentation (CO, packing list, commercial invoice) provided.
Replacement & Compatibility FAQ
Q: Can I use BMXAMO0410 in a Modicon M580 rack?
A: No. The M580 uses a different backplane (BM• series) and is not electrically or mechanically compatible with M340 BMX modules.
Q: Is BMXAMO0410 still in production?
A: Yes, as of 2026 it remains an active Schneider Electric product with full lifecycle support.
Q: Can I mix BMXAMO0410 with BMXAMI0410 (input module) in the same rack?
A: Yes. M340 backplanes support mixed I/O module configurations in any slot order.
Q: What is the difference between BMXAMO0410 and BMXAMO0410H?
A: The BMXAMO0410H is the ATEX-certified variant for use in Zone 2 hazardous areas. Functionally identical, but with additional safety certifications and housing.
Q: Do you provide a test report with refurbished units?
A: Yes. All refurbished BMXAMO0410 units ship with a functional test report upon request. Contact us before ordering to confirm availability.
Q: Can BMXAMO0410 replace a 140AVO02000 (Quantum module)?
A: Not directly — they use different backplanes and software platforms. A full platform migration would be required.
