Schneider Electric BSH0703P12F1A AC Servo Motor – BSH Series
When a servo motor fails on the production line, the consequences are immediate and costly: conveyor belts stop, robotic arms freeze mid-cycle, CNC spindles lose position feedback, and entire manufacturing cells go dark. Every minute of unplanned downtime translates directly into lost output, missed delivery windows, and escalating maintenance costs. The Schneider Electric BSH0703P12F1A is engineered to eliminate exactly this scenario — delivering the precise torque, speed control, and thermal resilience that modern industrial automation demands without compromise.
Within Schneider Electric’s BSH (Brushless Servo High-performance) series, the BSH0703P12F1A occupies a critical mid-range position: compact enough for space-constrained machine designs, yet powerful enough to drive demanding multi-axis motion profiles. The BSH series is recognized globally as a benchmark in servo technology, widely deployed across European, North American, and Asia-Pacific manufacturing facilities in sectors ranging from semiconductor fabrication to food and beverage packaging. Its compatibility with Schneider Electric’s Lexium servo drive ecosystem makes it a preferred choice for OEMs and system integrators building next-generation automation platforms.
Technical Specifications
- Model / SKU: BSH0703P12F1A
- Brand: Schneider Electric
- Series: BSH (Brushless Servo High-performance)
- Motor Type: AC Brushless Servo Motor
- Frame Size: 070 (70 mm flange)
- Shaft Type: Smooth shaft with key (as indicated by model suffix)
- Feedback: Incremental encoder (as per P12 designation)
- Holding Brake: Without brake (F1 suffix)
- Connector Type: Standard connector (A suffix)
- Protection Rating: IP65 (standard BSH series)
- Insulation Class: Class F
- Compatible Drive: Schneider Electric Lexium 23, Lexium 32 series
- Weight: Approx. 13.6 kg
Note: All specifications are based on Schneider Electric official BSH series documentation. Verify exact parameters against the official datasheet for your application.
Key Features & Benefits
- High Torque Density: BSH series motors deliver exceptional torque-to-size ratios, enabling compact machine designs without sacrificing dynamic performance.
- Precision Encoder Feedback: The incremental encoder provides accurate position and speed feedback, essential for closed-loop servo control in high-precision applications.
- IP65 Protection: Sealed against dust ingress and water jets, making it suitable for harsh industrial environments including washdown-adjacent zones.
- Plug-and-Play with Lexium Drives: Native compatibility with Schneider Electric’s Lexium servo drive family simplifies commissioning and reduces integration time.
- Low Cogging Torque: Smooth rotation at low speeds ensures superior surface finish in machining and consistent motion in pick-and-place operations.
- Thermal Stability: Class F insulation and optimized winding design allow sustained operation under continuous duty cycles in elevated ambient temperatures.
- Compact 70 mm Frame: The 070 frame size fits into tight machine envelopes while maintaining the performance characteristics of larger servo motors.
Industry & Equipment Applications
- CNC Machine Tools: Axis drives for milling, turning, and grinding machines requiring precise position control.
- Industrial Robotics: Joint actuators in articulated and SCARA robot arms for assembly and material handling.
- Packaging Machinery: High-speed indexing, filling, and sealing stations in food, beverage, and pharmaceutical packaging lines.
- Semiconductor & Electronics Manufacturing: Wafer handling, PCB drilling, and SMT pick-and-place equipment.
- Textile Machinery: Winding, unwinding, and tension control systems in yarn and fabric production.
- Printing & Converting: Web tension control and register correction in offset and flexographic printing presses.
- Conveyor & Material Handling: Precision positioning in automated storage and retrieval systems (AS/RS).
System Integration & Compatible Parts
The BSH0703P12F1A is designed for seamless integration within the Schneider Electric Lexium motion control ecosystem. Key compatible components include:
- Servo Drives: Lexium 23 (LXM23A), Lexium 32 (LXM32A/M/C) series
- Motion Controllers: Modicon M241, M251, M262 logic controllers with motion modules
- Servo Cables: BSH series power and encoder cables (VW3M series)
- Gearboxes: Schneider Electric planetary gearboxes compatible with 070 frame BSH motors
- Related BSH Models: BSH0703P12A1A, BSH0703T12F1A, BSH1001P12F1A
When sourcing replacement or expansion components, always cross-reference the full model number to ensure encoder type, brake configuration, and connector compatibility match your existing system.
Our Quality Assurance Process
At Konmask.com, every unit of the BSH0703P12F1A undergoes a rigorous verification process before shipment:
- Authenticity Verification: All products are sourced from authorized distributors or verified surplus channels. We do not deal in counterfeit or refurbished-as-new components.
- Visual & Physical Inspection: Each unit is inspected for label integrity, connector condition, shaft runout, and packaging completeness.
- Documentation Check: Original manufacturer documentation, serial numbers, and date codes are verified and recorded.
- Secure Packaging: Products are packed in anti-static, shock-resistant packaging with moisture-barrier protection for international shipping.
- Traceability: Full sourcing traceability is maintained for every order, available upon request for compliance and audit purposes.
How to Order
- Submit an Inquiry: Contact us via the inquiry form on this page or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote: Our technical sales team will respond within 24 business hours with pricing, lead time, and availability confirmation.
- Order Confirmation: Upon agreement, we issue a proforma invoice. Payment terms are confirmed at this stage.
- Shipment & Tracking: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation is provided for international shipments.
- After-Sales Support: Our engineering team is available post-delivery to assist with installation queries and compatibility verification.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on industrial automation components — PLCs, servo systems, DCS modules, and drives — giving us deep product knowledge that generalist distributors cannot match.
- Global B2B Supply: We serve OEMs, system integrators, MRO teams, and end-users across Europe, Southeast Asia, the Middle East, and the Americas.
- Fast Response: Dedicated account managers respond to all inquiries within 24 hours, with technical pre-sales support available.
- Competitive Pricing: Direct sourcing relationships and efficient operations allow us to offer competitive pricing on both standard and hard-to-find components.
- Reliable Logistics: Partnerships with major international couriers ensure safe, timely delivery with full export compliance documentation.
Frequently Asked Questions
Q: What is the difference between BSH0703P12F1A and BSH0703P12A1A?
A: The key difference lies in the shaft configuration. The “F” in position 10 of the model code typically denotes a smooth shaft with keyway, while “A” denotes a smooth shaft without keyway. Always verify against the Schneider Electric BSH series catalog for your specific application requirements.
Q: Which Lexium drive is compatible with the BSH0703P12F1A?
A: The BSH0703P12F1A is compatible with the Lexium 23 (LXM23A) and Lexium 32 (LXM32A, LXM32M, LXM32C) servo drive families. Ensure the drive’s continuous and peak current ratings match the motor’s requirements as specified in the BSH series datasheet.
Q: Can you supply the matching servo cables for this motor?
A: Yes. We can source the corresponding VW3M series power and encoder cables for the BSH0703P12F1A. Please specify the required cable length when submitting your inquiry.
Q: Do you provide a warranty on this product?
A: All products supplied by Konmask.com are covered by our standard quality guarantee. Specific warranty terms are confirmed at the time of order based on product condition and sourcing channel.
Q: What is the lead time for the BSH0703P12F1A?
A: Lead time depends on current stock availability. Please submit an inquiry for a real-time availability and lead time confirmation. We maintain relationships with multiple supply channels to minimize lead times on critical components.
Q: Is this motor suitable for use in a washdown environment?
A: The BSH0703P12F1A carries an IP65 protection rating, which provides protection against dust ingress and low-pressure water jets. It is not rated for full washdown (IP67/IP69K). For washdown-intensive environments, consult Schneider Electric’s BSH-W (washdown) variant options.
