Schneider Electric Modicon TSXP572634M – High-Performance Unity Processor | TSX Premium Platform
Engineering Background
The Schneider Electric Modicon TSXP572634M is a high-performance Unity processor module designed for the TSX Premium programmable automation controller (PAC) platform. Engineered for demanding industrial environments, this processor delivers deterministic real-time control with full compatibility with Schneider Electric’s Unity Pro programming software — the industry-standard IEC 61131-3 compliant development environment.
Product Positioning
The TSXP572634M occupies the upper-mid tier of the TSX Premium processor family, offering 34 KB of application RAM and robust communication capabilities. It is the preferred choice for process engineers and system integrators who require a proven, scalable controller for complex discrete, batch, and hybrid automation architectures. Konmask.com supplies this module as a verified OEM component, sourced through authorized distribution channels with full traceability.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number / SKU | TSXP572634M |
| Brand / Manufacturer | Schneider Electric (Modicon) |
| Product Family | TSX Premium Series |
| Module Type | Unity Processor (CPU) |
| Application RAM | 34 KB |
| Programming Software | Unity Pro (IEC 61131-3) |
| Supported Languages | LD, FBD, SFC, ST, IL |
| Communication Ports | Modbus, Uni-Telway (built-in terminal port) |
| Backplane Bus | TSX Premium X-Bus / FIPIO |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Power Supply | Via TSX Premium rack backplane |
| Protection Degree | IP20 |
| Certifications | CE, UL, cUL, CSA |
| Country of Origin | France |
| HS Code | 8537.10 |
| Weight (approx.) | 800 g |
Proven Application Environments
- Discrete Manufacturing: Automotive assembly lines, machine tool control, robotic cell coordination
- Process Industries: Chemical batch processing, water/wastewater treatment, oil & gas upstream control
- Building & Infrastructure: HVAC supervisory control, power distribution management, tunnel ventilation
- Material Handling: Conveyor sequencing, palletizing systems, warehouse automation
- Energy & Utilities: Substation automation, generator control, renewable energy integration
Engineering Advantages
- IEC 61131-3 Full Compliance: Supports all five standard PLC programming languages within Unity Pro, enabling multi-discipline engineering teams to collaborate on a single project.
- Deterministic Scan Cycle: Guaranteed real-time task execution with configurable periodic, event-driven, and master tasks for precise process synchronization.
- Integrated Diagnostics: Built-in self-test routines and LED status indicators accelerate fault isolation and reduce MTTR in production environments.
- Scalable I/O Architecture: Supports local, remote (Fipio), and distributed (Ethernet/IP, Modbus TCP) I/O expansion without processor replacement.
- Hot-Standby Ready: Compatible with TSX Premium redundancy configurations for high-availability applications requiring SIL-rated control.
- Long Product Lifecycle: Part of Schneider Electric’s sustained availability program — spare parts and technical support maintained for extended operational periods.
System Architecture & Signal Flow
The TSXP572634M installs in slot 00 of any TSX Premium rack (TSX RKY series). The processor communicates with I/O modules via the high-speed X-Bus backplane. Remote I/O drops connect via the integrated FIPIO fieldbus (up to 127 nodes, 1 Mbit/s). The terminal port (TER) provides direct Uni-Telway access for Unity Pro programming, HMI connection, or Modbus master/slave communication. Application programs and data are retained in battery-backed RAM; a PCMCIA memory card slot allows program backup and transfer.
Signal flow summary: Field sensors/actuators → I/O modules → X-Bus backplane → TSXP572634M CPU → Control logic execution → Output update → Fieldbus/Ethernet supervisory layer.
Sourcing & Quality Verification
- All TSXP572634M units supplied by Konmask.com are OEM-grade, sourced from authorized Schneider Electric distribution channels or verified industrial surplus with full provenance documentation.
- Each unit undergoes incoming inspection: visual examination, firmware version verification, and functional power-on test prior to shipment.
- Original manufacturer packaging, labels, and documentation are preserved where available.
- Counterfeit-risk mitigation: serial number cross-referenced against Schneider Electric’s product authentication database upon request.
Procurement Process
- Inquiry: Submit your RFQ via the product page or email support@konmask.com with quantity and required delivery date.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options (DHL Express / FedEx International Priority).
- Order Confirmation: Place order via Shopify checkout or wire transfer (T/T). Pro-forma invoice issued immediately.
- Quality Check & Dispatch: Unit inspected, packed in anti-static ESD packaging, and dispatched within 1–3 business days.
- After-Sales Support: 12-month warranty on verified OEM units. Technical support available via WhatsApp/WeChat: +0086 19859288691.
Technical FAQ
Q: Is the TSXP572634M compatible with Unity Pro XL?
A: Yes. The module is fully compatible with all Unity Pro editions (S, M, L, XL) running on Windows 7/10/11 platforms.
Q: Can this processor replace a TSXP572634 (without the M suffix)?
A: The “M” suffix denotes a specific hardware revision. While functionally equivalent in most applications, always verify the exact part number against your system’s hardware catalog before substitution.
Q: What battery type does the TSXP572634M use for RAM backup?
A: It uses a standard 3.6V lithium battery (Schneider ref. TSXBATT01). Battery life is typically 5 years under normal operating conditions.
Q: Does this module support Ethernet communication natively?
A: The TSXP572634M does not include a built-in Ethernet port. Ethernet connectivity is added via a dedicated TSX ETY communication module installed in the same rack.
Q: What is the maximum number of I/O points supported?
A: The TSX Premium platform supports up to 1,024 discrete I/O points and 256 analog channels in a standard local + remote configuration.
