Schneider Electric XS1M30MA250 – Inductive Proximity Sensor | OsiSense XS Series
Engineering Background: The XS1M30MA250 is part of Schneider Electric’s OsiSense XS family — a globally recognized platform for industrial proximity detection. Designed to meet the rigorous demands of factory automation, this sensor delivers reliable non-contact detection of metallic targets in harsh industrial environments.
Product Positioning: Targeted at OEM machine builders, system integrators, and MRO procurement engineers who require a proven, IEC-compliant inductive sensor with broad PLC compatibility and long service life. The XS1M30MA250 is a direct-fit replacement and new-installation solution for Schneider Electric control architectures and third-party automation systems alike.
Complete Technical Specifications
- Part Number / SKU: XS1M30MA250
- Manufacturer: Schneider Electric
- Series / Platform: OsiSense XS
- Sensor Type: Inductive Proximity Sensor
- Housing Form Factor: Cylindrical, M30
- Sensing Range (Sn): 15 mm (nominal, ferrous target)
- Output Type: 2-wire AC/DC (confirm datasheet for variant)
- Supply Voltage: 24–240 V AC/DC
- Output Current: ≤ 250 mA
- Switching Frequency: ≤ 25 Hz
- Protection Rating: IP67 (IEC 60529)
- Operating Temperature: -25°C to +70°C
- Connection: Cable, 2 m PVC
- Standards Compliance: IEC 60947-5-2, CE, UL
- Weight: approx. 360 g (with cable)
Proven Application Environments
- Automotive body-in-white assembly lines — end-of-arm tooling position feedback
- Food & beverage packaging — stainless-steel conveyor pallet detection
- Discrete manufacturing — CNC machine tool-change confirmation
- Material handling — pallet presence detection on roller conveyors
- Water treatment — pump shaft rotation monitoring in wet zones
- Pharmaceutical — cleanroom-compatible metal part detection (IP67 wash-down)
Engineering Advantages
- Non-contact detection eliminates mechanical wear, extending MTBF beyond 10⁷ switching cycles
- IP67 sealing withstands coolant, dust, and high-pressure wash-down without degradation
- Wide voltage range (24–240 V AC/DC) simplifies integration across global power standards
- M30 threaded barrel fits standard DIN mounting brackets — zero custom machining required
- OsiSense XS platform ensures form-fit-function interchangeability within the Schneider ecosystem
- Short-circuit and overload protection built-in for panel-level safety compliance
System Architecture & Signal Flow
The XS1M30MA250 operates on an LC oscillator principle: a ferrite-core coil generates an electromagnetic field at the sensor face. When a conductive metallic target enters the sensing zone (≤15 mm), eddy currents are induced, damping the oscillation. The internal trigger circuit detects this amplitude change and switches the solid-state output accordingly.
Typical wiring topology: Sensor output → PLC digital input module (e.g., Schneider TM3DI16 / Modicon M340 BMX DDI) → ladder logic rung for presence/absence logic. 2-wire AC/DC output is loop-powered — no separate supply rail required at the sensor.
Sourcing & Quality Verification
- All units sourced through authorized Schneider Electric distribution channels or verified surplus with full traceability documentation
- Each unit inspected for: label integrity, date code consistency, housing condition, and electrical continuity pre-shipment
- Original manufacturer packaging preserved where available; anti-static ESD bags used for repackaged units
- Certificate of Conformance (CoC) available upon request for regulated industries
- Counterfeit-risk mitigation: holographic labels and QR traceability codes verified against Schneider Electric’s product authentication portal
Procurement Process
- Step 1: Add XS1M30MA250 to cart or submit RFQ via support@konmask.com
- Step 2: Receive order confirmation with lead time and shipping options (DHL / FedEx / sea freight)
- Step 3: Payment via T/T, PayPal, or credit card — proforma invoice issued for B2B orders
- Step 4: Shipment with tracking number; export documentation (commercial invoice, packing list, CoC) included
- Step 5: Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: What is the sensing range for non-ferrous metals?
A: Sensing range is reduced for non-ferrous targets — typically 50–70% of nominal Sn for aluminum, and 30–50% for copper. Refer to the correction factor table in the Schneider Electric XS1M30MA250 datasheet.
Q: Can this sensor be used with a Modicon M221 PLC?
A: Yes. The 2-wire output is compatible with Modicon M221, M241, M251, and M340 digital input modules operating at 24 V DC. Verify input impedance against sensor minimum load current specification.
Q: Is the XS1M30MA250 RoHS compliant?
A: Yes. Schneider Electric confirms RoHS 2 (Directive 2011/65/EU) compliance for the OsiSense XS series.
Q: What is the difference between XS1M30MA250 and XS1M30PA250?
A: The XS1M30MA250 uses a 2-wire AC/DC output; the XS1M30PA250 is a PNP 3-wire DC output variant. Selection depends on your PLC input module type and wiring architecture.
Q: Can I get a sample or trial unit?
A: Sample requests are evaluated case-by-case for qualified OEM accounts. Contact support@konmask.com with your application details.
