Schneider Electric PN072139P904 – Inverter Power Board | ATV Series Variable Frequency Drive
Engineering Background: The PN072139P904 is an OEM inverter power board (driver board) manufactured by Schneider Electric for use within the Altivar (ATV) series of variable frequency drives. This board serves as the core power conversion and gate-drive interface between the control logic and the IGBT power stage, making it a critical component in industrial motor control systems.
Product Positioning: Sourced directly from verified industrial channels, this board is the preferred replacement part for maintenance engineers and MRO procurement teams managing Schneider ATV drive fleets in manufacturing, HVAC, water treatment, and process automation environments. Konmask.com supplies this part with full traceability and pre-shipment inspection.
Complete Technical Specifications
- Part Number: PN072139P904
- Manufacturer: Schneider Electric
- Component Type: Inverter Power Board / Gate Driver Board
- Compatible Platform: Schneider Altivar (ATV) Series Variable Frequency Drives
- Board Function: DC bus power supply, IGBT gate drive signal distribution, fault feedback interface
- Mounting: PCB plug-in / screw-mount (drive-chassis specific)
- Operating Temperature: -10°C to +55°C (ambient, per ATV drive spec)
- Weight: Approx. 3,500 g (packaged)
- Country of Origin: China
- Condition: New / Refurbished (specify at order)
Proven Application Environments
- Industrial motor speed control (pumps, fans, compressors, conveyors)
- HVAC variable air volume (VAV) and chiller systems
- Water and wastewater treatment plant drives
- Packaging and material handling automation lines
- Oil & gas field auxiliary drive systems
- CNC machine tool spindle drive repair
Engineering Advantages
- OEM Part Number: Exact Schneider Electric reference — no cross-compatibility guesswork
- Drop-in Replacement: Designed to restore original drive performance without firmware or parameter changes
- Pre-shipment Inspection: Each board visually inspected for PCB damage, burnt components, and connector integrity
- Reduced Downtime: Ready-to-install; eliminates the lead time of full drive replacement
- Cost Efficiency: Board-level repair cost is typically 10–30% of a complete drive replacement
System Architecture & Signal Flow
The PN072139P904 power board interfaces between the ATV drive’s main control board and the IGBT power module. It receives PWM gate signals from the DSP/control board, conditions and amplifies them via isolated gate driver ICs, and distributes drive pulses to each IGBT leg. Simultaneously, it monitors DC bus voltage, over-current, and temperature fault signals, feeding protection logic back to the control board. The board also provides auxiliary DC power rails (typically ±15 V, +5 V) to the control circuitry from the main DC bus via an onboard SMPS stage.
Sourcing & Quality Verification
- Supply Chain: Sourced from authorized industrial distributors and certified MRO channels
- Traceability: Batch and date codes recorded; documentation available on request
- Inspection Standard: Visual + functional check prior to dispatch
- Packaging: Anti-static ESD bag + foam-padded carton for safe international transit
- Warranty: 90-day replacement warranty against manufacturing defects
Procurement Process
- Confirm your ATV drive model number and existing board part number (PN072139P904)
- Submit your order via Konmask.com or contact us for bulk/B2B pricing
- Receive order confirmation with estimated lead time (typically 3–7 business days)
- Board ships in ESD-safe packaging with tracking number provided
- Installation support available via email or WhatsApp
Technical FAQ
Q: Is PN072139P904 compatible with all ATV drive models?
A: This board is specific to certain ATV series models. Please confirm your drive’s exact model number before ordering. Contact us if unsure.
Q: Can I send my faulty board for repair instead of buying new?
A: Yes. We offer board-level repair services. Contact support@konmask.com with photos of the fault for a repair quote.
Q: What causes inverter power board failure?
A: Common causes include IGBT gate driver IC failure, DC bus overvoltage transients, electrolytic capacitor aging, and thermal stress from inadequate drive ventilation.
Q: Do you provide installation guidance?
A: Yes. We provide wiring diagrams and step-by-step installation notes upon request. Always de-energize and discharge the DC bus before board replacement.
Q: What is the lead time for international orders?
A: Standard international shipping is 7–15 business days. Express DHL/FedEx options are available at checkout.
