Genuine Schneider TSXDSZ32R5 Relay Discrete Output Module | TSX Premium Series – Verified Source
The Schneider Electric TSXDSZ32R5 is a 32-channel relay discrete output module engineered for the Modicon TSX Premium PLC platform. In process-critical environments — from automotive assembly lines to water treatment facilities — a failed output module can halt an entire production cell, triggering costly unplanned downtime and safety incidents. The TSXDSZ32R5 provides the robust relay switching capability that keeps your control system commanding field devices with absolute reliability.
As a verified distributor sourcing directly from authorized Schneider Electric channels and certified secondary markets, Konmask.com supplies this module with full traceability documentation. Every unit undergoes our in-house 4-step verification process before shipment, ensuring you receive a genuine, fully functional component — not a counterfeit or refurbished substitute passed off as new.
Technical Specifications
- Part Number: TSXDSZ32R5
- Brand: Schneider Electric (Modicon)
- Series: TSX Premium
- Module Type: Relay Discrete Output Module
- Number of Output Channels: 32
- Output Type: Relay (dry contact)
- Rated Output Voltage: 24 VDC / 48–240 VAC
- Max Switching Current per Channel: 2 A
- Isolation: Galvanic isolation between channels and backplane
- Backplane Bus: TSX Premium rack-compatible
- Weight: 641 g
- Operating Temperature: 0°C to +60°C
- Standards Compliance: IEC 61131-2, CE
Note: All specifications are sourced from official Schneider Electric documentation. Konmask.com does not modify or fabricate technical data.
Our 4-Step Quality Verification Process
Every TSXDSZ32R5 unit sold through Konmask.com passes the following verification protocol before dispatch:
- Step 1 — Visual Inspection: Physical examination of housing, label integrity, connector pins, and PCB condition. Any signs of rebranding, corrosion, or tampering result in immediate rejection.
- Step 2 — Label & Serial Number Authentication: Cross-referencing the module’s serial number and date code against Schneider Electric’s known production batches and label formats.
- Step 3 — Functional Bench Test: Where applicable, modules are powered up and relay switching is verified across all 32 channels using a calibrated test rig.
- Step 4 — Packaging & Documentation Review: Units are repackaged in anti-static ESD-safe materials. Traceability documents (test report, sourcing declaration) are included with every shipment.
Key Features & Benefits
- 32 Independent Relay Outputs — High channel density reduces rack space and wiring complexity in large I/O applications.
- Dry Contact Relay Switching — Compatible with both AC and DC field loads, offering maximum flexibility for mixed-voltage installations.
- Galvanic Isolation — Protects the PLC backplane from field-side voltage transients and ground loops.
- Hot-Swap Compatible — Supports module replacement without full system shutdown (rack-dependent configuration).
- Native TSX Premium Integration — Plug-and-play with Unity Pro / PL7 Pro programming environments; no additional configuration hardware required.
- Proven Field Reliability — Widely deployed across global industrial installations since the TSX Premium platform launch.
Typical Applications
- Motor starter and contactor control in manufacturing lines
- Valve and actuator switching in process automation (oil & gas, water treatment)
- Conveyor and material handling system control
- HVAC and building management system (BMS) integration
- Packaging machinery and bottling line control
- Power distribution and switchgear control panels
Compatible System Components
The TSXDSZ32R5 is designed for use within the Schneider Electric TSX Premium ecosystem. Commonly paired components include:
- CPU Modules: TSXP57104M, TSXP57204M, TSXP57304M, TSXP57454M
- Rack / Backplane: TSXRKY4, TSXRKY6, TSXRKY8, TSXRKY12
- Power Supply: TSXPSY2600M, TSXPSY5500M
- Discrete Input Modules: TSXDEY32D2, TSXDEY64D2
- Programming Software: Unity Pro (v2.0+), PL7 Pro
Contact our technical team to verify compatibility with your specific rack configuration before ordering.
Global Sourcing & Shipping Capabilities
- Stock Location: Warehouses in China (Mainland) with consolidation hubs for international dispatch
- Lead Time: In-stock units typically ship within 1–3 business days of order confirmation
- Shipping Methods: DHL Express, FedEx International Priority, UPS Worldwide, sea freight for bulk orders
- Export Documentation: Commercial invoice, packing list, certificate of origin available upon request
- Minimum Order Quantity: 1 unit (bulk pricing available for 5+ units)
- Served Markets: Southeast Asia, Middle East, Europe, Americas, Africa
Certifications & Compliance Statement
Konmask.com operates as a professional industrial automation component distributor. We do not manufacture, modify, or alter any products. All items are sourced from authorized distributors, OEM surplus channels, or verified secondary markets. The TSXDSZ32R5 carries the following certifications as issued by Schneider Electric:
- CE Marking (European Conformity)
- IEC 61131-2 Compliance (Programmable Controllers — Equipment Requirements)
- RoHS Compliant (per applicable production batch)
Konmask.com does not make independent certification claims. All compliance documentation is as provided by the original manufacturer.
How to Order
- Submit an Inquiry: Use the contact form on this page or email [email protected] with your required quantity and delivery timeline.
- Receive a Quotation: Our team will respond within 24 business hours with pricing, availability, and lead time confirmation.
- Order Confirmation: Confirm your purchase order (PO) via email. We accept T/T bank transfer, PayPal, and other agreed payment terms for established accounts.
- Quality Check & Dispatch: Your unit(s) pass our 4-step verification process and are shipped with full documentation.
- After-Sales Support: Our technical team remains available post-delivery for integration questions or warranty claims.
Authenticity & Trust FAQ
Q: How do I know the TSXDSZ32R5 I receive is genuine?
A: Every unit is verified through our 4-step process including visual inspection, serial number authentication, functional testing, and ESD-safe repackaging. A sourcing declaration and test report are included with each shipment.
Q: Do you sell refurbished or repaired modules?
A: We clearly distinguish between new-surplus and refurbished stock. If a unit is refurbished, this is explicitly stated in the product listing and quotation. The TSXDSZ32R5 listed here is new-surplus unless otherwise specified in your quotation.
Q: Can you provide a warranty?
A: Yes. We offer a 12-month warranty against manufacturing defects and functional failure under normal operating conditions. Warranty claims are handled directly by Konmask.com.
Q: What if the module is not compatible with my system?
A: Contact our technical team before ordering. We will verify compatibility with your rack, CPU, and software version. If a compatibility issue arises post-delivery due to incorrect information provided by our team, we will arrange a replacement or refund.
Q: Do you accept returns?
A: Yes, within 30 days of delivery for unused, uninstalled units in original packaging. Please contact [email protected] to initiate a return authorization.
Q: Can you source other TSX Premium modules not listed on your site?
A: Absolutely. Konmask.com specializes in sourcing hard-to-find and discontinued Schneider Electric components. Submit your part number inquiry and we will respond with availability within 24–48 hours.
