Process Automation & Machine Control Solution – Schneider Electric TSXP57103M | Modicon Premium TSX P57 Series
Where This Product Is Used
The Schneider Electric TSXP57103M is a high-performance PLC CPU module engineered for demanding industrial environments where reliability, processing speed, and I/O scalability are non-negotiable. Engineers and system integrators specify this module across a wide range of sectors:
- Automotive Manufacturing: Body-in-white assembly lines, paint shop conveyors, and press transfer systems requiring deterministic cycle times under 10 ms.
- Water & Wastewater Treatment: SCADA-integrated pump station control, dosing systems, and filtration sequencing with IEC 61131-3 structured text programs.
- Food & Beverage Processing: Filling, capping, and labeling machines where hygienic-area PLCs must handle high-speed I/O and recipe management simultaneously.
- Oil & Gas Upstream/Midstream: Wellhead control panels, compressor station automation, and pipeline SCADA edge nodes.
- Building Automation & HVAC: Central plant chiller sequencing, AHU control, and BACnet/Modbus gateway applications.
- Discrete Manufacturing & Packaging: Pick-and-place robotics coordination, palletizer control, and end-of-line inspection systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | TSXP57103M |
| Series | Modicon Premium TSX P57 |
| Manufacturer | Schneider Electric |
| Module Type | PLC CPU Module |
| Program Memory | 256 KB (expandable) |
| Data Memory | 128 KB |
| Max I/O Points | Up to 1,024 discrete I/O |
| Communication Ports | Uni-Telway / Modbus (RS-485), Ethernet option via PCMCIA |
| Programming Standard | IEC 61131-3 (LD, FBD, ST, IL, SFC) |
| Scan Time | < 1 ms / 1,000 instructions (Boolean) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Supply | 24 VDC (via rack PSU) |
| Rack Compatibility | TSX RKY 4/6/8/12 racks |
| Weight | 4,460 g (with rack assembly) |
| Certifications | CE, UL, cUL, IEC 61131-2 |
Why Engineers Specify This Model
- Proven Platform Longevity: The Modicon Premium TSX P57 series has been deployed globally since the 1990s, with an extensive installed base ensuring long-term spare parts availability and engineering familiarity.
- Deterministic Real-Time Performance: Sub-millisecond Boolean scan times make the TSXP57103M suitable for motion-adjacent and high-speed discrete control without requiring a dedicated motion controller.
- Flexible Communication Architecture: Native Uni-Telway and Modbus RTU support, plus optional Ethernet and PCMCIA expansion, allows seamless integration into both legacy and modern SCADA/DCS architectures.
- IEC 61131-3 Multi-Language Programming: Unity Pro / PL7 Pro software supports all five IEC languages, enabling structured, maintainable code across multi-disciplinary engineering teams.
- Hot-Swap Rack Modularity: Compatible with the full TSX RKY rack family, allowing I/O expansion without system shutdown in many configurations.
- Robust EMC Immunity: Designed to IEC 61000-4 series immunity levels, ensuring stable operation in electrically noisy industrial environments (VFDs, welding equipment, high-current switchgear).
Complete System Bill of Materials
A typical TSXP57103M-based control panel includes the following Schneider Electric components:
- TSXP57103M — CPU Module (this item)
- TSXRKY8 — 8-slot Premium rack
- TSXPSY2600M — 26 W rack power supply (24 VDC)
- TSXDEY16D2 — 16-channel 24 VDC discrete input module
- TSXDSY16T2 — 16-channel 24 VDC transistor output module
- TSXAEY414 — 4-channel analog input module (4–20 mA / 0–10 V)
- TSXETY110 — 10/100 Mbps Ethernet TCP/IP module
- TSXMRP032P — 32 KB PCMCIA program backup memory card
- XBTN401 — Magelis HMI operator panel (optional)
Compliance & Industry Standards
- IEC 61131-2: Programmable controllers — Equipment requirements and tests
- IEC 61131-3: Programmable controllers — Programming languages
- IEC 61000-4 Series: EMC immunity (ESD, EFT, surge, conducted RF, magnetic field)
- EN 61010-1: Safety requirements for electrical equipment for measurement and control
- UL 508: Industrial control equipment (UL/cUL listed)
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive
- RoHS: Restriction of Hazardous Substances compliant
Quality Assurance & Sourcing
At Konmask.com, every TSXP57103M unit is subject to a rigorous multi-stage verification process before shipment:
- Authenticity Verification: Each module is cross-referenced against Schneider Electric’s official part numbering and date-code databases to confirm genuine origin.
- Functional Bench Test: Power-on self-test (POST) and communication port continuity checks are performed on 100% of units.
- Visual & Physical Inspection: PCB, connector pins, label integrity, and firmware version are inspected against OEM specifications.
- Anti-Static Packaging: Units are shipped in ESD-safe bags with foam cushioning inside double-wall corrugated cartons.
- Traceability: Full lot and serial number documentation is provided with every order.
How to Source This Part
Konmask.com maintains stock of the TSXP57103M for immediate dispatch. Our industrial procurement team supports:
- Single-unit emergency replacement — same-day quotation and priority shipping available
- Project BOM fulfillment — submit your full bill of materials for consolidated sourcing and volume pricing
- Long-term supply agreements — blanket orders with scheduled releases for MRO and OEM customers
- Export compliance — we handle HS code classification, commercial invoices, and customs documentation for international shipments
Contact our team: support@konmask.com | +0086 19859288691
Application-Specific FAQ
Q: Is the TSXP57103M compatible with Unity Pro software?
A: Yes. The TSX P57 103M is fully supported by Schneider Electric’s Unity Pro programming environment (v2.0 and later), as well as the legacy PL7 Pro software suite.
Q: Can this CPU communicate directly with a Modbus RTU network?
A: Yes. The onboard Uni-Telway port supports Modbus RTU master/slave operation natively. For Modbus TCP/IP, add a TSXETY110 Ethernet module to the rack.
Q: What is the maximum number of I/O points supported?
A: The TSXP57103M supports up to 1,024 discrete I/O points across local and remote racks using the TSX bus or Fipio fieldbus.
Q: Is a battery backup required for program retention?
A: The CPU includes an internal lithium battery for RAM data retention during power loss. A PCMCIA flash memory card (e.g., TSXMRP032P) is recommended for non-volatile program backup.
Q: Can this module replace a TSXP57103 (without the M suffix)?
A: The “M” suffix denotes a metal housing variant with enhanced vibration resistance. Functionally, the firmware and I/O capacity are identical, making it a direct drop-in replacement in most applications.
Q: What warranty does Konmask.com provide?
A: All units carry a 12-month warranty against manufacturing defects. Advance replacement is available for critical production environments — contact us for details.
