Precision Motion Control Solution — SIEMENS 1FK7063-2AF71-1RH1 | SIMOTICS S-1FK7 Series
Where This Product Is Used
The SIEMENS 1FK7063-2AF71-1RH1 is a compact, high-dynamic synchronous servo motor engineered for demanding industrial motion control applications. Engineers and system integrators specify this model across a wide range of industries:
- CNC Machine Tools — Feed axis and spindle drives on milling centers, lathes, and grinding machines requiring precise positioning and high repeatability.
- Robotics & Handling Systems — Joint actuators in articulated robots, SCARA arms, and gantry systems where compact form factor and high torque density are critical.
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and labeling lines demanding synchronous multi-axis coordination.
- Printing & Converting Equipment — Register control and web tension management in offset, flexo, and digital printing presses.
- Semiconductor & Electronics Manufacturing — Wafer handling, PCB drilling, and SMT placement machines requiring sub-micron positioning accuracy.
- Textile Machinery — Warp beam drives, rapier looms, and yarn tensioning systems with continuous duty cycles.
- Plastics & Injection Molding — Servo-driven injection units and clamping axes replacing hydraulic systems for energy efficiency.
Technical Specifications
| Part Number | 1FK7063-2AF71-1RH1 |
| Manufacturer | Siemens AG |
| Series | SIMOTICS S-1FK7 (Compact) |
| Motor Type | Permanent Magnet Synchronous Servo Motor |
| Rated Speed | 2,000 rpm |
| Rated Torque | ~6.0 Nm (refer to Siemens SIZER for exact operating point) |
| Stall Torque | ~7.0 Nm |
| Encoder | Absolute encoder (single-turn / multi-turn per suffix -1RH1) |
| Cooling | Natural convection (self-cooled) |
| Protection Class | IP64 (shaft end IP65 optional) |
| Insulation Class | F (155°C) |
| Shaft | Smooth shaft with feather key (suffix -1RH1) |
| Flange Size | 63 mm |
| Weight | ~12.8 kg |
| Compatible Drive | SINAMICS S120, SINAMICS V90 |
| Voltage Class | 400 V AC (DC link via drive) |
Note: Always verify final operating parameters using Siemens SIZER engineering tool or the official 1FK7 catalog (D 21.3).
Why Engineers Specify This Model
- High Torque Density — The 1FK7 Compact series delivers exceptional torque-to-volume ratio, enabling machine designs with smaller motor compartments without sacrificing dynamic performance.
- Absolute Encoder Standard — The -1RH1 suffix confirms an integrated absolute encoder, eliminating homing routines on power-up and improving machine availability.
- Seamless SINAMICS Integration — Native compatibility with SINAMICS S120 and V90 drives enables plug-and-play commissioning via DRIVE-CLiQ, reducing engineering hours.
- Proven Reliability — Siemens SIMOTICS S motors are deployed in millions of axes globally, with documented MTBF exceeding 50,000 hours in standard industrial environments.
- Scalable Architecture — The 1FK7 family spans a wide torque range, allowing engineers to standardize on one motor family across multiple machine axes.
Complete System Bill of Materials
For a fully operational servo axis using the 1FK7063-2AF71-1RH1, the following components are typically required:
- Servo Drive: SINAMICS S120 Motor Module (e.g., 6SL3120-1TE21-0AA3) or SINAMICS V90 (6SL3210-5FB10-4UA0)
- Control Unit: SINAMICS S120 CU320-2 DP/PN (6SL3040-1MA01-0AA0)
- Power Module / Line Module: SINAMICS S120 Active Line Module (size-dependent)
- Motor Cable: Siemens pre-assembled power cable (MOTION-CONNECT 500/800 series)
- Encoder Cable: DRIVE-CLiQ cable or resolver cable (MOTION-CONNECT 800PLUS)
- Brake Resistor: Required if regenerative braking energy cannot be fed back to grid
- Coupling / Gearbox: Application-dependent (e.g., SIMOGEAR bevel-helical gearbox)
- Safety Option: SMC30 or SME120 for STO/SS1 safety functions (SIL 2 / PLd)
Contact support@konmask.com for complete BOM quotation and cross-reference support.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- UL / cUL Listed — Recognized for North American markets (file reference per Siemens product documentation)
- IEC 60034 — Rotating electrical machines standard compliance
- EN ISO 13849 / IEC 62061 — Safety-related control system compatibility when paired with SINAMICS safety options
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components sourced through verified supply channels. Every unit of the 1FK7063-2AF71-1RH1 we supply undergoes the following process:
- Origin verification against Siemens factory documentation and serial number traceability
- Visual and dimensional inspection upon receipt
- Storage in ESD-safe, climate-controlled warehouse conditions
- Packaging in original or equivalent protective materials for transit
- Documentation package available: datasheet, test report, and certificate of conformity upon request
We do not sell counterfeit, refurbished-as-new, or grey-market goods. All products are sold with full disclosure of condition and origin.
How to Source This Part
- Submit an RFQ — Email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Receive Quotation — We respond within 1 business day with pricing, lead time, and available stock confirmation.
- Place Order — Add to cart directly on Konmask.com or confirm via email PO. We accept T/T bank transfer and major payment methods.
- Shipping & Export — We handle export documentation (commercial invoice, packing list, CO) for international shipments. DHL, FedEx, and sea freight available.
- After-Sales Support — Technical questions, warranty claims, and cross-reference assistance available post-delivery.
Application-Specific FAQ
Q: Is the 1FK7063-2AF71-1RH1 compatible with SINAMICS V90?
A: Yes. The 1FK7 Compact series is fully compatible with SINAMICS V90 drives. Use Siemens SIZER or the V90 selection tool to confirm the correct drive size for your load profile.
Q: What does the suffix “2AF71” indicate?
A: The suffix encodes the motor’s electrical variant — specifically the winding configuration (2A = 400V class, F = specific winding), encoder type (7 = absolute encoder), and mechanical options (1 = standard flange). Always decode the full order number using the Siemens 1FK7 catalog.
Q: Can this motor be used in a vertical axis application?
A: Yes, with appropriate consideration for holding brake requirements. The -1RH1 suffix does not include an integrated brake. If the load must be held at standstill (e.g., vertical Z-axis), specify a variant with brake suffix or add an external holding brake.
Q: What is the lead time for this part?
A: Lead time varies by stock availability. Contact us at support@konmask.com for real-time stock status. We maintain buffer stock of common 1FK7 variants for fast delivery.
Q: Do you provide a warranty?
A: Yes. We provide a 12-month warranty against manufacturing defects on all genuine Siemens products supplied by Konmask.com, subject to correct installation and operating conditions.
