SIEMENS 6AV2124-1QC02-0AX1 – High-Performance 15″ Widescreen HMI | SIMATIC TP1500 Comfort Platform
Engineering Background
The SIMATIC HMI Comfort Panel series represents Siemens’ flagship human-machine interface platform, engineered for demanding industrial automation environments where reliability, precision, and seamless SIMATIC integration are non-negotiable. The TP1500 Comfort (6AV2124-1QC02-0AX1) is the 15-inch widescreen flagship of this series, purpose-built for complex visualization tasks in process control, machine automation, and critical infrastructure.
Product Positioning
Designed for procurement engineers and system integrators who require a certified, OEM-grade HMI with native PROFINET/MPI/PROFIBUS connectivity, this unit eliminates integration risk and reduces commissioning time. As an authorized distributor, Konmask.com supplies this panel with full traceability and quality verification, serving industrial buyers across manufacturing, energy, water treatment, and building automation sectors.
Complete Technical Specifications
| Part Number / SKU | 6AV2124-1QC02-0AX1 |
| Product Family | SIMATIC HMI TP1500 Comfort |
| Manufacturer | Siemens AG |
| Display Size | 15.4″ Widescreen TFT |
| Display Resolution | 1280 × 800 px (WXGA) |
| Color Depth | 16 million colors (24-bit) |
| Touch Technology | Resistive touch, single-touch |
| Processor | 800 MHz ARM Cortex-A8 |
| RAM | 128 MB DDR2 |
| Flash Memory | 24 MB internal + SD card slot |
| Operating System | Windows CE 6.0 |
| Engineering Software | WinCC (TIA Portal) V13 SP1 and above |
| PROFINET Interface | 2× RJ45 (integrated switch, 10/100 Mbit/s) |
| MPI / PROFIBUS DP | 1× RS 485 (9-pin Sub-D) |
| USB | 2× USB 2.0 Type-A (host), 1× USB 2.0 Type-B (device) |
| Audio | Line-in / Line-out (3.5 mm jack) |
| Supply Voltage | 24 V DC (19.2–28.8 V) |
| Power Consumption | Typ. 25 W |
| Protection Rating | IP65 (front panel) / IP20 (rear) |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Relative Humidity | 10–90% (non-condensing) |
| Vibration Resistance | IEC 60068-2-6: 5–9 Hz / 3.5 mm; 9–150 Hz / 1 g |
| Shock Resistance | IEC 60068-2-27: 15 g / 11 ms |
| Certifications | CE, UL, cUL, ATEX Zone 2 (optional), DNV GL |
| Panel Cutout | 398 × 280 mm |
| Overall Dimensions (W×H×D) | 421 × 307 × 56 mm |
| Weight | Approx. 4.26 kg |
| Mounting | Panel mounting (portrait/landscape) |
| HS Code | 8537.10 |
| Country of Origin | Germany |
Proven Application Environments
- Discrete Manufacturing: Machine tool control, robotic cell HMI, assembly line supervision
- Process Industry: Chemical plant DCS visualization, batch control, reactor monitoring
- Energy & Utilities: Substation automation, power distribution SCADA front-end, wind turbine control
- Water & Wastewater: Pump station control, filtration process visualization, SCADA integration
- Building Automation: HVAC control panels, BMS operator stations, clean-room environment control
- Food & Beverage: Hygienic-design panel installations, CIP/SIP process visualization
- Oil & Gas: Wellhead control, pipeline monitoring (ATEX-rated installations)
Engineering Advantages
- Native TIA Portal Integration: Zero-configuration tag import from S7-1200/1500 PLCs; eliminates manual address mapping errors
- Dual PROFINET Ports with Integrated Switch: Enables line topology wiring without external switches, reducing panel BOM cost
- IP65 Front Protection: Suitable for wash-down environments and dusty production floors without additional enclosure
- High-Brightness WXGA Display: 1280×800 resolution supports complex P&ID diagrams and multi-window operation
- Scalable Comfort Panel Architecture: Consistent WinCC project structure across 4″, 7″, 9″, 12″, 15″, 19″, 22″ variants — one engineering template, multiple panel sizes
- Integrated Audit Trail & User Management: Meets FDA 21 CFR Part 11 and GMP documentation requirements out of the box
- SD Card Slot: Supports recipe management, data logging, and project backup without PC connection
System Architecture & Signal Flow
The 6AV2124-1QC02-0AX1 operates as a PROFINET IO Controller or IO Device within a SIMATIC automation network. Typical signal flow:
- PLC Layer: S7-1500 / S7-1200 / S7-300/400 via PROFINET or MPI/PROFIBUS DP
- HMI Layer: TP1500 Comfort reads/writes process tags in real-time via optimized S7 communication
- Supervisory Layer: Optional OPC UA server (built-in) enables connectivity to SCADA, MES, or cloud platforms
- Peripheral Layer: USB barcode scanners, printers, and RFID readers connect via USB host ports
- Remote Access: Integrated VNC server enables remote monitoring from any standard VNC client
Sourcing & Quality Verification
- ✅ Authentic OEM Units: All panels sourced through verified supply chains with full documentation traceability
- ✅ Pre-Shipment Inspection: Power-on functional test, display uniformity check, and port verification performed before dispatch
- ✅ Firmware Version Confirmed: Units shipped with factory firmware; TIA Portal compatibility verified
- ✅ Packaging Integrity: Original Siemens anti-static packaging with intact tamper-evident seals
- ✅ Condition Options: New (factory-sealed) and Refurbished (tested, 90-day warranty) available — specify at inquiry
- ✅ Export Compliance: ECCN classification and export documentation available upon request
Procurement Process
- Submit Inquiry: Contact support@konmask.com with your project requirements, quantity, and required delivery date
- Quotation: Receive a formal quotation with lead time, unit price, and shipping options within 24 business hours
- Order Confirmation: Issue PO or confirm via email; proforma invoice issued for payment processing
- Quality Check & Dispatch: Pre-shipment inspection completed; tracking number provided within 1–2 business days of payment clearance
- Delivery & Support: Post-delivery technical support available for integration and commissioning questions
Technical FAQ
Q: Is 6AV2124-1QC02-0AX1 compatible with TIA Portal V15/V16/V17/V18?
A: Yes. The TP1500 Comfort is fully supported in TIA Portal V13 SP1 and all subsequent versions including V18. Ensure your WinCC license matches your TIA Portal version.
Q: Can this panel communicate with non-Siemens PLCs?
A: Yes, via OPC UA (built-in server), Modbus TCP, and third-party drivers available through WinCC. Native performance is optimized for SIMATIC S7 controllers.
Q: What is the difference between 6AV2124-1QC02-0AX0 and 0AX1?
A: The -0AX1 suffix denotes the second hardware revision with improved EMC performance and updated firmware baseline. Both share identical software compatibility.
Q: Does the panel support multi-language operation?
A: Yes. Up to 32 languages can be configured in WinCC; runtime language switching is supported without panel restart.
Q: What warranty is provided?
A: New units carry Siemens standard warranty. Refurbished units carry a 90-day Konmask functional warranty. Extended warranty options available on request.
Q: Can I get a datasheet or STEP file?
A: Yes. Contact support@konmask.com with your request. Official Siemens datasheets, CAD drawings, and dimensional STEP files are available for qualified inquiries.
