Siemens 6AV6648-0BC11-3AX0 KTP400 Basic Touch Panel | Replacement, Equivalent & Selection Guide
The Siemens 6AV6648-0BC11-3AX0 is a compact 4-inch Basic Key/Touch Panel (KTP400 Basic) from the SIMATIC HMI Basic Panel family. Designed for entry-level HMI applications, it combines a resistive touch screen with 4 configurable function keys, making it a cost-effective solution for machine-level visualization and operator control in industrial automation systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Order Number (MLFB) | 6AV6648-0BC11-3AX0 |
| Product Family | SIMATIC HMI KTP400 Basic |
| Display Size | 4.3″ (109 mm) TFT widescreen |
| Resolution | 480 × 272 px |
| Color Depth | 64K colors (16-bit) |
| Touch Type | Resistive single-touch |
| Function Keys | 4 configurable keys |
| Interface | PROFINET (RJ45) |
| Supply Voltage | DC 24 V (20.4–28.8 V) |
| Power Consumption | Approx. 3.6 W |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Protection Rating | IP65 (front panel) |
| Dimensions (W×H×D) | 164 × 114 × 33 mm |
| Weight | Approx. 300 g |
| Configuration Software | WinCC Basic (TIA Portal V13 SP1 and above) |
| Certifications | CE, UL, cULus, ATEX Zone 2 |
Compatible Replacement & Equivalent Models
When the 6AV6648-0BC11-3AX0 is unavailable or end-of-life, the following models are commonly evaluated as replacements or functional equivalents:
| Model | Display | Interface | Notes |
|---|---|---|---|
| 6AV2123-2DB03-0AX0 (KTP400 Basic PN, 2nd Gen) | 4.3″ TFT | PROFINET | Direct successor; same footprint, improved firmware |
| 6AV6648-0AC11-3AX0 (KTP400 Basic DP) | 4.3″ TFT | PROFIBUS DP | Same panel, PROFIBUS variant — select based on network |
| 6AV2123-2GA03-0AX0 (KTP700 Basic PN) | 7″ TFT | PROFINET | Upgrade option for larger display requirement |
| Weintek MT6071iP | 7″ TFT | Ethernet/RS-485 | Third-party alternative; requires protocol adapter for S7 |
| Kinco MT4414TE | 4.3″ TFT | Ethernet | Budget alternative; supports Siemens S7 via Ethernet driver |
⚠ Always verify communication protocol, TIA Portal version compatibility, and panel cutout dimensions before substituting.
Why Choose the Original Model
- Native TIA Portal Integration: Seamless configuration with WinCC Basic — no additional drivers or middleware required.
- Proven Reliability: Siemens SIMATIC HMI panels are rated for 24/7 industrial operation with MTBF exceeding 100,000 hours.
- IP65 Front Protection: Suitable for dusty and wash-down environments without additional enclosure modifications.
- PROFINET Native: Direct integration with S7-1200/1500 PLCs over standard Ethernet infrastructure.
- Compact Footprint: Ideal for space-constrained control panels and machine doors.
- Siemens Ecosystem: Full support for Siemens diagnostics, remote access via SINEMA, and firmware updates.
Typical Applications
- Machine-level operator interfaces for packaging, conveyor, and assembly lines
- HVAC and building automation control panels
- Pump station and water treatment monitoring
- Small-scale process visualization in food & beverage plants
- OEM machine builders requiring a compact, cost-effective HMI
- Retrofit projects replacing older OP/TP panels in existing Siemens systems
System Compatibility
| Component | Compatible Models |
|---|---|
| PLC (PROFINET) | Siemens S7-1200, S7-1500, S7-300/400 (with PN interface) |
| Configuration Software | TIA Portal V13 SP1, V14, V15, V16, V17, V18, V19 |
| WinCC Version | WinCC Basic (bundled with TIA Portal) |
| Network | PROFINET IO, standard 100 Mbps Ethernet switch |
| Power Supply | Siemens SITOP PSU100S 24V / any regulated 24 VDC supply |
Selection Guide
Use the following criteria to confirm the 6AV6648-0BC11-3AX0 is the right choice — or to identify a better-fit alternative:
| Requirement | Recommended Model |
|---|---|
| 4.3″ display + PROFINET + TIA Portal | 6AV6648-0BC11-3AX0 ✓ (this product) |
| 4.3″ display + PROFIBUS DP | 6AV6648-0AC11-3AX0 (KTP400 Basic DP) |
| Larger 7″ display + PROFINET | 6AV2123-2GA03-0AX0 (KTP700 Basic PN) |
| Advanced scripting / VB scripts needed | 6AV2124-0GC01-0AX0 (KTP700 Comfort) |
| Budget-sensitive, non-Siemens network | Kinco MT4414TE or Weintek MT6071iP |
| Hazardous area (Zone 1) | Consult Siemens SIMATIC HMI Ex-rated variants |
Quality Assurance & Sourcing
- Authentic Stock: All units sourced from authorized Siemens distributors or verified industrial surplus channels with full traceability.
- Pre-shipment Inspection: Each unit undergoes visual inspection, label verification, and packaging integrity check before dispatch.
- Warranty: 12-month warranty against manufacturing defects. Replacement or refund within warranty period.
- Counterfeit Prevention: We do not deal in cloned or remarked components. Certificates of conformity available on request.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock items: estimated lead time provided at inquiry.
How to Order
- Confirm the exact MLFB: 6AV6648-0BC11-3AX0
- Specify quantity and required delivery date
- Add to cart and proceed to checkout — or contact us for bulk/project pricing
- For urgent requirements, email support@konmask.com or call +0086 19859288691
- We accept T/T bank transfer, PayPal, and major credit cards
Replacement & Compatibility FAQ
Q: Is the 6AV6648-0BC11-3AX0 still in production?
A: This model has been superseded by the 2nd-generation KTP400 Basic PN (6AV2123-2DB03-0AX0). However, original units remain available as new-old-stock (NOS) or refurbished. Contact us for current availability.
Q: Can I use this panel with an S7-1200 PLC?
A: Yes. The KTP400 Basic PN connects natively to S7-1200 via PROFINET. Configure the connection in TIA Portal using the integrated HMI wizard.
Q: What is the panel cutout size?
A: The required cutout is 152 × 102 mm. Verify your enclosure dimensions before ordering a replacement.
Q: Can I migrate my existing project to the 2nd-gen KTP400?
A: Yes. TIA Portal supports device replacement with automatic project migration. Minor adjustments to screen layouts may be required.
Q: Do you provide a certificate of origin or conformity?
A: Yes, available upon request for all units. Please specify at time of order.
Q: Is the 6AV6648-0AC11-3AX0 (PROFIBUS) interchangeable with this model?
A: Mechanically identical, but the communication interface differs (PROFIBUS DP vs. PROFINET). They are not electrically interchangeable without network infrastructure changes.
